Pantech BreEZe C520 Manuale utente

Thank you for choosing the Pantech Breeze C520,

our latest mobile phone.

The Pantech Breeze C520 has many features

designed to enhance your mobile experience. From

its EZ to read menus, to its sleek, stylish design,

we know you will enjoy the entire Breeze C520

experience.

This User Guide contains important and useful

information that will maximize your familiarity with all

that the Pantech Breeze C520 has to offer.

Breeze C520

User Manual

Speciﬁcations

Design

Clamshell phone with internal and external display

Displays

•

260k colors TFT LCD with 2.2” internal display

•

65k colors STN LCD with 1.04” external display

•

7 lines for text in basic mode with 16 point font

•

Two soft keys and four-way scroll and selection

keys

Melodies

MP3, AAC, AAC+, WMA, AMR-NB, MIDI,

SP-MIDI

Camera

Integrated VGA (300k) CMOS Camera

• Resolution up to 640x480 (330,000 pixels)

•

Mpeg4 Video recording/playing up to 15f/s (QCIF size)

• Self-timer function (5 seconds or 10 seconds)

• Photo album and video album

Dimensions & Weight

• Weight: 96g (with standard battery)

• Dimensions: 99.3 mm x 50 mm x 19.6 mm

Power Management (Performance)

Battery Type Capacity Standby Time Talk Time

Standard

Lithium-Ion

(Li-ion)

Up to

920 mAh Up to

250 hours Up to

3 hours

Operating Frequency

• GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz,

and PCS 1900Mhz networks in North America,

South America, Europe, Africa, and Asia-Paciﬁc

where these networks are supported.

• Automatic band switching.

1 Address Book

2 Messaging

3 My Stuff

4 Tools

5 Settings

6 Phone Status

Phone overview

Earpiece

Internal display

Navigation key

Scroll through the menu options

Left/Right Soft key

Perform the functions shown

at the bottom line of the display

OK key

or access

MEdia Net

Press to enter menu system

Camera key

Power on&off/Menu exit

key/End key

Turns phone on/off, ends calls,

exits menus

Clear key and Calendar

Returns to previous screen or

deletes characters in text mode.

Access Calendar menu

One-touch

Quick Call

Speaker Mode

Send key

Voicemail

Vibrate mode

Microphone

Menu features (Breeze Mode)

Address Book Messaging My Stuff

Tools Settings Phone Status

note:

Holding device at internal antenna

area might affect call quality reception.

Camera

Speaker

Side

key

External

display

Internal antenna

Example: Accessing the

Phone Mode menu.

1. Press the Menu.

2. Press the

for

Settings.

3. Press the

for

Phone Mode.

4. Press the

scroll key to select

the mode.

Numbered menu

items, such as menus,

sub-menus, and

options can be quickly

accessed by using

their shortcut numbers.

In Menu mode,

Main Menus can be

accessed by pressing

the number keys

(1 to 0) corresponding

to their location on the

screen.

Address Book

Contact List ¦P28

New Contact ¦P28

Speed Dial ¦P27

My Phone Number

Messaging

Write New ¦P38

Inbox ¦P36

Sent ¦P38

Voice Mail ¦P42

Email ¦P43

IM ¦P43

Settings ¦P41

My Stuff

Photo Album ¦P51

Video Album ¦P52

Audio ¦P72

Graphics ¦P51

Games & Apps ¦P54

Using Shortcuts Menu overview

Breeze mode menu

NOTE: The steps vary by mode and that throughout

the manual it will be notated by [EZ] for EZ Mode or

[ADV] for Advanced Mode.

S SIM dependent N Network dependent

Tools

Phone Status ¦P62

Camera ¦P46

Alarm ¦P58

Calendar ¦P58

Notepad ¦P60

Voice Memo ¦P60

Calculator ¦P59

Settings

Phone Mode ¦P18

Sounds & Alerts

¦P72

Ring Volume ¦P72

Wallpaper ¦P72

Backlight Timer

¦P73

Answer Type ¦P25

Phone Status

My Phone Number

Signal Strength

Battery Remaining

Sound & Alerts

Alarm

New Messages

Email & IM

Mobile Email ¦P43

IM ¦P43

Messaging

Write New ¦P37

Inbox ¦P36

Sent ¦P38

Outbox

Voice Mail ¦P42

Settings ¦P41

Memory Info ¦P53

Advanced mode menu

Recent Calls

Missed Calls ¦P26

Received Calls

¦P26

Dialed Calls ¦P26

Delete Call ¦P26

Logs

Call Time ¦P26

GPRS Info ¦P27

MEdia Net

MEdia Net ¦P68

Home

Bookmarks ¦P68

Go to URL ¦P68

Proﬁles ¦P68

Options

Security ¦P68

Version

AT&T Mall

Shop Tones

Shop Games

Shop Graphics

Shop Multimedia

Shop Applications

MEdia Net Home

Games & Apps

S SIM dependent N Network dependent

My Stuff

Audio ¦P72

Graphics ¦P51

Photo Album ¦P51

Video Album ¦P52

Other Files ¦P53

Tools

Memory Info ¦P53

Address Book

Contact List ¦P28

New Contact ¦P28

Speed Dial ¦P27

Groups ¦P29

My Business Card

¦P61

My Phone Number

¦P62

Memory Info ¦P36

Service NumbersS

Settings

Phone Mode ¦P18

Sounds & Alerts

¦P72

Display ¦P72

Call

Phone

Flight Mode ¦P81

Connectivity ¦P66

SecurityS ¦P30

Software

Reset ¦P74

TTY ¦P75

Quick & easy

Keys Functions

< > Perform the functions shown at the bottom line of the display by using these Soft keys.

Scroll through the menu options in Menu mode. In standby mode,

Left Scroll: Access My Stuff menu

Right Scroll: Access Alarm menu

Up Scroll: Access Write New menu

Down Scroll: Access Contact List menu

Select a menu function or store user-input information, such as names. Also use this key for

conﬁrmation (as the [OK] key).

Launch the MEdia Net directly if pressed in standby mode.

CDelete characters from the display, or return to previous menu.

Open Calendar view if pressed quickly in standby mode.

SMake or receive a call. Show the recent call list in standby mode.

Re-dial the last call number if pressed and held in standby mode.

Keys Functions

EComplete the current call. Turn on/off the phone if pressed and held.

Cancel user input and return to standby mode while in Menu mode.

1Quickly connect to the voice mail server if pressed and held in standby mode.

0~9Enters numbers, letters or special characters. Go to the dial screen if pressed in standby mode.

Enter or exit from vibrate mode if pressed and held in standby mode.

Show the symbol input screen if pressed and held in text input mode.

Work in Word search mode if pressed in the Predictive text input mode.

0Enter the + sign preﬁx for international dialing if pressed and held.

Enter the space character in text input mode.

#Change various text input modes if pressed and held at the text-editing screen.

Adjust the earpiece volume while making a call.

Control the Ringtone volume, vibrate mode and silent all mode in standby.

Mute the ringtone of an incoming call.

Reject the incoming call if pressed and held when you receive an incoming call.

QTurn camera capture mode on. Work as a camera shutter in capture mode.

NTurn the speaker mode on.

Contents

Speciﬁcations.............................2

Phone overview ..........................3

Using Shortcuts .........................4

Menu overview ...........................4

Quick & easy ...............................8

1. Getting started

Package contents .................14

SIM card and battery ............15

Turn on/off the phone ...........16

Keypad lock ..........................16

Essential display indications

..17

Setting theme .......................18

EZ quick call keys .................19

Updating software ................19

2. Calls & address book

Making, receiving and

ending a call .........................22

Options during a call .............23

Call setting ............................25

Checking all calls ..................26

Speed dialing ........................27

Using address book ..............28

Caller identiﬁcation...............29

Using your headset ..............29

Service number and

ﬁxed dialing...........................30

3. Messaging

Entering text .........................34

Messaging ............................35

Receiving messages ............36

Creating and sending

text message ........................37

Creating a multimedia

message ............................... 38

Message template ................41

Message settings ................41

Setting voice message .........42

Email .....................................43

Using instant messenger ......43

4. Multimedia

Camera .................................46

Photo album .........................51
