Pantech EDGE C530 Manuale utente
Your phone is designed to make it easy for you to access a wide variety of content. For your protection, we want you to be aware that
some applications that you enable may involve the location of your phone being shared. For applications available through AT&T, we
offer privacy controls that let you decide how an application may use the location of your phone and other phones on your account.
However, the AT&T privacy tools do not apply to applications available outside of AT&T. Please review the terms and conditions
and the associated privacy policy for each location-based service to learn how location information will be used and protected. In
addition, your AT&T phone may be used to access the Internet and to download, and/or purchase goods, applications, and services
from AT&T or elsewhere from third parties. AT&T provides tools for you to control access to the Internet and certain Internet content.
These controls may not be available for certain devices which bypass AT&T controls.
Pantech_SLATE™
User Manual
Thank you for choosing the Pantech Slate (C530), our latest EDGE
mobile phone.
The Pantech Slate has many features designed to enhance your
mobile experience. From its sleek, stylish design, we know you will
enjoy the entire Slate experience.
This User Guide contains important and useful information that
will maximize your familiarity with all that the Pantech Slate has
to offer.
™
2
Specifications
Design
Bar type phone with single display and QWERTY keypad
Displays
• 260k colors TFT LCD with 2.2” internal display
• 176x220 resolution
• 7 lines for text in basic mode with 16-point font
• Two soft keys and four-way scroll and selection
@
keys
Melodies
MP3, AAC, AAC+, WMA, AMR-NB, MIDI, SP-MIDI
Camera
Integrated 1.3M CMOS Camera
• Resolution up to 1280 x 960 (1,228,800 pixels))
• Mpeg4 Video recording/playing up to 15f/s (QCIF size)
• Self-timer function (5 seconds or 10 seconds)
• Photo album and video album
Dimensions & Weight
• Weight: 132g (with standard battery)
• Dimensions: 107 mm x 64 mm x 9.9 mm
Power Management (Performance)
Battery Type Capacity Standby Time Talk Time
Standard
Lithium-Ion
(Li-ion)
Up to
930 mAh
Up to
250 hours
Up to
3 hours
Operating Frequency
• GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz, and PCS
1900Mhz networks in North America, South America, Europe,
Africa, and Asia-Pacific where these networks are supported.
• Automatic band switching.
3
Earpiece
Display
Left/Right Soft key
Perform the functions shown
at the bottom line of the display
OK key
or access
MEdia Net
Press to enter menu system
Clear key
Returns to previous screen
or deletes characters in text
mode.
Power on&off/Menu exit
key/End key
Turns phone on/off, ends calls,
exits menus
Microphone
Menu features
Email & IM Messaging
YELLOWPAGES.COM
MEdia Net MEdia Mall Games & Apps
My Stuff Address Book Settings
note:
Holding device at internal
antenna area might affect call quality
reception.
Charger slot/Ear mic
Side key
Camera
Internal antenna
Navigation key
Scroll through the
menu options
Speaker key
Send key
Prefix
International
call key
Vibrate mode
Camera
key
Phone overview
Number pad view
Voicemail
4
QWERTY keyboard view
Left/Right Soft key
Perform the functions
shown at the bottom line of
the display.
Function key
To enter a number or a symbol,
press the function key, and press
the corresponding key.
CAPS/Shift key
To type a single uppercase letter,
press this key then a letter
Clear/Back key
Returns to previous screen or
deletes characters in text mode.
Delete key
Press to delete a number or letter.
Enter key
Press to create new line while
writing a message.
Space key
Press to enter a space.
5
Numbered menu items, such as menus, sub-menus, and
options can be quickly accessed by using their shortcut
numbers. In Menu mode, Main Menus can be accessed by
pressing the number keys (1 to 9) corresponding to their
location on the screen.
Example: Accessing the Language menu.
1. Press the Menu.
2. Press the
9
for Settings.
3. Press the
4
for Phone.
4. Press the
1
for Language.
5. Press Select for Screen Text.
6. Press the
U
or
D
scroll key to display the list of available
languages.
Using shortcuts Menu overview
Email & IM
Mobile Email
IM
Messaging
Create Message
Inbox
Sent
Outbox
Drafts
Voice Mail
Templates
Settings
Memory Info
6
MEdia Mall
Shop Tones
Shop Games
Shop Graphics
Shop Multimedia
Shop Applications
MEdia Net
Games & Apps
Games
Applications
YELLOWPAGES.COM MEdia Net
MEdia Net Home
Bookmarks
Go to URL
Profiles
Options
Security
Version
7
My Stuff
Audio
Graphics
Video
Tools
Other Files
Memory Info
Address Book
Contacts
New Contact
Speed Dial
Groups
My Business Card
Memory in Use
Delete All
Copy All
My Phone Number
Memory Info
Service NumbersS
Settings
Sounds & Alerts
Display
Call
Phone
Flight Mode
Connectivity
Security S
Software Version
Reset
TTY
S SIM dependent N Network dependent
8
Quick & easy
Keys Functions
< > Perform the functions shown at the bottom line of the display by using these soft keys.
Scroll through the menu options in Menu mode. In standby mode,
Left: Access Mobile Email menu
Right: Access IM menu
Up: Access Create Message menu
Down: Access Contacts menu
@
Select a menu function or store user-input information, such as names.
Also use this key for confirmation as the [OK] key.
Launch the MEdia Net directly if pressed in standby mode.
NTurn the speaker mode on.
CDelete characters from the display, or return to previous menu.
SMake or receive a call. Show the recent call list in standby mode.
Re-dial the last call number if pressed and held in standby mode.
EComplete the current call. Turn on/off the phone if pressed and held.
Cancel user input and return to main screen while in Menu mode.
