Pantech Laser Manuale utente

Thank you for choosing the Pantech Laser, our latest touch

with QWERTY slide mobile phone.

The Pantech Laser has many features designed to enhance

your mobile experience. From its unique, stylish design and full

touch with QWERTY keypad, we know you will enjoy the entire

Laser experience. This User Guide contains important and

useful information that will maximize your familiarity with all

that the Pantech Laser has to offer.

User Guide

Specifications

Design

Touch QWERTY Slider

Displays

• 262k colors AMOLED with 3.1” display

• 480*800 (WVGA) pixels in resolution

Melodies

MP3, AAC, AAC+, eAAC+ and WMA.

Camera

Integrated 3M CMOS Camera

• Resolution up to 2048 x 1536 (3,145,728 pixels)

• Mpeg4 Video recording/playing up to 15f/s(VGA size)

• Self-timer function (5 seconds or 10 seconds)

• Photo album and video album

Dimensions & Weight

• Weight: 115g/4.06oz. (with standard battery)

• Dimensions: 113 x 57.9 x 9.95mm

4.45” x 2.28” x 0.39”

Power Management (Performance)

Battery Type Capacity Standby

Time

Talk Time

Standard

Lithium-Ion

(Li-ion)

1000 mAh Minimum

250 hours

Minimum

3 hours

Operating Frequency

• GSM/GPRS/EDGE 850/900/1800/1900 MHz, UMTS/HSDPA

850/1900 MHz networks in North America, South America,

Europe, Africa, and Asia-Pacific where these networks are

supported.

• Automatic band switching.

Earpiece

Clear key

Return to

previous screen

Power/ End key

End calls, exit

menus

Send key

Press to make

and answer

calls

Proximity

sensor Camera

Charging/Data jack

Lock Key

Lock the touch screen

Volume control key

Volume up and down

Speaker

Internal antenna

area

Microphone

Phone overview

Touch mode view

note: Using metal accessories (stickers) on the phone, or holding the

device by the internal antenna area while changing a data and talking on

the phone might affect the quality of all calls.

Incorrect

Correct

Keys Functions

Lock the touch screen.

Return to the previous menu.

Access Recent Calls or dial the last number if

pressed twice.

End the current call. Turn on/off the phone if

pressed and held.

Cancel user input and return to main screen while

in Menu mode.

Adjust the earpiece volume while making a call.

Control Ringtone volume, vibrate mode and silent

all mode in standby.

Mute the ringtone of an incoming call.

note: To use the QWERTY keypad hold the phone horizontally and slide the screen up.

QWERTY mode view

CAPS key

To type a single uppercase

letter, press this key then enter

a letter

Function key

Press with corresponding key

to enter a number or symbol.

Vibrate key

Delete key

Press to delete a

character/symbol

Enter key

Press to move to the next row

Symbol key

Press to enter a symbol

Space key

Press to enter a space

Your phone has a QWERTY keypad which provides a superior

typing experience on a small handheld device for easy and

comfortable texting. You can use all of the phone functions with

the QWERTY keypad.

Keys Functions

Press to change Abc ABC abc on the text editing

screen

(first letter caps/all

caps/lowercase)

Press to enter a special character or number.

To enter symbols and numbers continually,

press until

displays

Press to enter a space in text input mode

Move to the next row in text input mode

]

Delete a character to the left of the text cursor in

the text editing screen

Press to type a special character that is not on

the keypad

Quickly connect to the voice mail server if

pressed and held while in standby mode.

Keys Functions

Enter numbers, letters or special characters.

Go to the dial screen if pressed in standby mode.

Enter or exit from vibrate mode if pressed and

held in standby mode.

Enter an international dialing prefix if pressed in

standby mode.

Menu overview

Mobile Email

RKDDADFGAFGA

ADFDFHDGJKLK;’KJHGFDSFSDSFG

FHJGHKJFHSSERYTUTYJFGHKKDFY

RSYGHJDGHJFGHJDGJDGHDFGJHG

SDFHGJFGJHDGF

RSY

GJFG

Messages

Conversations

Create Message

Mobile Email

Outbox

Drafts

Voice Mail

Settings

Templates

Memory

IM Mobile Video

AppCenter AT&T Music AT&T GPS

AT&T Navigator

Maps

Shop GPS

AT&T FamilyMap

Where

AllSport GPS

Mobile Web

YPmobile Camera Address Book

Contacts

Groups

Favorites

My Settings

Fixed Dial Numbers

My Phone Number

Service Numbers

Settings

Profiles

Display

Call

Phone

Touch

Connectivity

Security

AT&T Software Update

Reset

TTY

Phone Information

Facebook AT&T Social Net MySpace Twitter
