LEG PRESS ADAPTER KIT
FOR CM3 GYM SYSTEM
CLASS H
PART# 7997101
REV.A
Version: CM3-LP5A-103
Revision: 09/26/05
USER’S GUIDE
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF
EQUIPMENT. TO MINIMIZE RISK FOLLOW THESE RULES!
1. Before us ng, read all the warn ngs and nstruct ons
on the use of th s mach ne. Use only for ntended
exerc se. DO NOT mod fy the mach ne.
2. Obta n a med cal exam before beg nn ng any
exerc se program.
3. Keep body and cloth ng free of all mov ng objects.
4. Inspect the mach ne before use. DO NOT use t f t
appears damaged. DO NOT attempt to f x a broken or
jammed mach ne. Not fy your author zed
ParaBody
dealer before use and have repa rs made by an
author zed serv ce techn c an.
5. Be certa n that we ght p n s completely nserted.
Use only the p n prov ded by the manufacturer. If
unsure, call your author zed ParaBody dealer.
6. Never p n the we ghts or prop plate nto an elevated
pos t on. DO NOT use the mach ne f found n th s
cond t on. DO NOT attempt to f x. Not fy your
author zed ParaBody dealer.
7. Inspect cables and the r connect ons before us ng
mach ne. Pay part cular attent on to the cable ends.
DO NOT attempt to f x. Not fy your author zed
ParaBody dealer before use and have repa rs made by
an author zed serv ce techn c an.
8. Make sure all spr ng loaded pull p ns are fully
engaged n the adjustment pos t on and fully t ghten
thumbscrew before use.
9. Ch ldren must not be allowed near th s mach ne.
Superv se teenagers.
.
IMPORTANT SAFETY INFORMATION
TABLE OF CONTENTS
Safety Statement.............2
General Notes..................3
Tools Required................3
NOTE: In a continual effort to improve our products, specifications are subject to change
2005 Life Fitness, a division of Brunswick Corporation. All rights reserved.
ParaBody is a trademark of Brunswick Corporation
www.parabody.com
2
Parts list..........................4
Assembly Instructions.....4-13
Insert-Registration Card
©
IMPORTANT NOTES
Please note:
Tools Required for Assembly
* Thank you for purchasing the ParaBody CM3-LP5A-101 LEG PRESS ADAPTER KIT.
Please read these instructions thoroughly and keep them for future reference. This product
must be assembled on a flat, level surface to assure its proper function.
* 9/16” wrench
* Ratchet with 9/16” socket
* Adjustable wrench
* Tape measure
3
NOTE: BOLTLENGTH IS MEASURED FROM THE UNDERSIDE OF THE HEAD OF THE BOLT.
BOLTLENGTH RULER:
* This product must be assembled on a flat, level surface to assure its proper function. DO NOT
securely tighten any frame connections until the entire frame has been assembled, unless
otherwise stated.
Bolt Length Ruler
0123 4 5 6
1/2 1/2 1/2 1/2 1/2 1/2
BOLT LENGTH
PARTS LIST
4
PART#
ACUA04-1451
ACUA04-1172
ACUP13-0168
ACUA13-0141
ACUP06-0051
ACUA06-0362
ACUDC1250100020B
ACUDB2E03811000B
KEY
1
2
3
4
5
6
7
8
QTY
1
1
1
1
6
1
10
13
PART#
ACUDA1E03813416NB
ACUDA1E03823416NB
ACUDA1E03840016NB
ACUDA1E03843416NB
ACUP08-0085
ACUP08-0076
ACUP08-0079
ACUA02-0055
DESCRIPTION
3/8 X 1-3/4” BOLT
3/8 X 2-3/4” BOLT
3/8 X 4” BOLT
3/8 X 4-3/4” BOLT
STEP SPACER 19/32’LG
STEP SPACER 1-19/32’LG
STEP SPACER 1-11/16’LG
CABLE L CLIP
QTY
4
3
2
4
2
2
2
1
DESCRIPTION
LEG PRESS ADAPTOR
PULLEY BRACKET
WEIGHT STACK CABLE
LEG PRESS CABLE
3-1/2” PULLEY
2” COVER CAP
3/8” WASHER
3/8” LOCKNUT
KEY
9
10
11
12
13
14
15
16
NOTE: The LEG PRESS ATTACHMENT (LP5) must be assembled before
connecting it to the PARABODY CM3 GYM SYSTEM
FIGURE 1
STEP 1:
• Remove the WEIGHT STACK CABLE as shown in FIGURE 1. Discard the cable.
DISCARD!
WEIGHT STACK
CABLE
5
FIGURE 2
STEP 2:
• Route the WEIGHT STACK CABLE (3) around the pulley in the BOOM PLATES as shown in FIGURE 2. (NOTE: Make sure
the cable runs in the grooves of the pulleys.)
• Assemble one 3-1/2” PULLEY (5) to the PULLEY BRACKET (2) using one 3/8 X 1-3/4” BOLT(9) and one 3/8” LOCK NUT
(8) (Note: Loop the WEIGHT STACK CABLE around the PULLEY prior to assembling the PULLEY BRACKET.)
• Screw the long threaded end of the new WEIGHT STACK CABLE (3) into the end of the WEIGHT PLATE SHAFT. See
FIGURE 2.
• Screw the short threaded end of the WEIGHT STACK CABLE (3) into the end of the PULLEY BRACKET (2). See FIGURE 2.
8
3
5
2
3/8 X 1-3/4” 9
0123 4 5 6
1/2 1/2 1/2 1/2 1/2 1/2
6
FIGURE 3
STEP 3:
• Screw the threaded end of LEG PRESS CABLE (4) to the PULLEY BRACKET (2) as shown in FIGURE 3.
4
2
FIGURE 4
STEP 4:
• If not already installed, slide one 2” SQ. COVER CAP (6) over the FRONT LEG (1) as shown in FIGURE 4.
7
FIGURE 5
STEP 5:
• Remove the 3/8 X 3-3/4” BOLTand 3/8” LOCK NUT from the BASE PLATE as shown in FIGURE 5. Discard the 3/8 X 3-3/4”
BOLT.
3/8” LOCKNUT
3/8 X 3-3/4” BOLT
1
6
0123 4 5 6
1/2 1/2 1/2 1/2 1/2 1/2
8
FIGURE 6
STEP 6:
• SECURELYassemble the LEG PRESS ADAPTOR (1) to the CM3 Gym System using two 3/8 X 4” BOLTS (11), five 3/8”
WASHERS (7), one previously removed 3/8” LOCK NUT and one 3/8” LOCK NUT (8) as shown in FIGURE 6.
1
8
7
11 3/8 X 4”
FIGURE 7
STEP 7:
1
8
• Carefully route the LEG PRESS CABLE (4) around one 3-1/2” PULLEY (5) and SECURELY assemble the 3-1/2” PULLEY (5)
to the LEG PRESS ADAPTOR (1) using one 3/8 X 1-3/4” BOLT(9) and one 3/8” LOCK NUT (8). See FIGURE 7.
4
9 3/8 X 1-3/4”
5
FIGURE 8
STEP 8:
• SECURELY attach the LP5 LEG PRESS to the LEG PRESS ADAPTOR (1) using two 3/8” X 2-3/4” BOLTS (10), two 3/8”
WASHERS (7), and two 3/8” LOCK NUTS (8). See FIGURE 8.
1
8
7
10 3/8 X 2-3/4”
9
FIGURE 9
STEP 9:
• Carefully route the LEG PRESS CABLE (4) around one 3-1/2” PULLEY (5) and SECURELY assemble the 3-1/2” PULLEY (5) to
the BRACKET (from the 100 LEG PRESS ) using one 3/8 X 1-3/4” BOLT(9), one 3/8” WASHER (7), one CABLE CLIP (16) and
one 3/8” LOCK NUT (8) as shown in FIGURE 9. Make sure the CABLE is in the grooves of all the pulleys.
SEATFRAME
8
7
4
5
9 3/8 X 1-3/4”
16
BRACKET
10
0123 4 5 6
1/2 1/2 1/2 1/2 1/2 1/2
FIGURE 11
STEP 11:
• Carefully route the LEG PRESS CABLE (4) around one 3-1/2” PULLEY (5) and SECURELY assemble the 3-1/2” PULLEY (5) to
the bracket on the SEATFRAME using one 3/8 X 1-3/4” BOLT(9) and one 3/8” LOCK NUT (8) as shown in FIGURE 11 . Make
sure the CABLE is in the grooves of all the pulleys.
3/8 X 1-3/4” 9
5
4
8
SEATFRAME
FIGURE 10
STEP 10:
12
SEATFRAME
• SECURELY attach the BRACKET (from LP5 LEG PRESS) to the SEATFRAME using two 3/8” X 4-3/4” BOLTS (12), two 3/8”
WASHERS (7), and two 3/8” LOCK NUTS (8). See FIGURE 10.
3/8” L0CK NUT
7
8
BRACKET
3/8 X 4-3/4”
