Pari Vortex Manuale utente

Short instruction

1

3

4

Instructions for Use (for use at home)

Carefully read this entire manual before the VORTEX®is used

2

7

6

5

Before every use, inspect the VORTEX®for damage and make

sure there are no foreign bodies in.

Remove the sealing cap of the spray / MDI (= Metered Dose Inhaler).

Shake the spray vigorously. Observe the operating instructions for

your spray.

Place the mouthpiece between your teeth and enclose it with your lips.

Alternatively, place the VORTEX®with mask gently on the face.

Mouth and nose must be covered.

If you need more than one medication pulls

Wait shortly, then repeat steps 4 and 5 (or 6) in the instructions.

Using VORTEX®with mask

Make sure the mask fits tightly against the face.

Slowly breath in the medication.

For children under 18 months, hold the mask tightly against the child‘s

face for 4-6 breaths and for children over 18 months for 2-4 breaths.

Using VORTEX®with mouthpiece

Trigger the medication pull and take a deep, slow breath.

Hold your breath briefly.

Breathe out slowly into the mouthpiece.

Ensure that only one pull is sprayed into the VORTEX®at a time.

Insert the mouthpiece of the spray into the blue connecting ring of

the VORTEX®.

Pull the protective cap off.

Short instruction

Distributör: Active Care Sverup AB

Uggledalsvägen 47 · 427 40 Billdal

Tel: 031-917525 · Fax: 031-917505

E-post: [email protected]

hemsida: www.activecare.se

© PARI GmbH · Spezialisten für effektive Inhalation · 051D1026 · 11/2015

PARI GmbH

Spezialisten für effektive Inhalation

Moosstraße 3 · D-82319 Starnberg

10

Cleaning

13

12

11

9

8Remove the connecting ring and mask (if present).

Do not remove the mouthpiece and the protective cap.

Thoroughly clean all parts thoroughly in warm tap water and

dishwashing liquid.

Rinse all parts thoroughly under clean running water and then

shake to remove excess water.

Drying

The VORTEX®and the accessories must be dried completely.

Due to its antistatic properties it can also be dried with a

clean tea towel.

Alternatively, in boiling water

Place the individual parts of the VORTEX®and the accessories

(e.g. mask) in boiling water for at least 5 minutes.

Use a clean pot and fresh drinking water and ensure that there

is sufficient water in the pot.

Disinfection

Recommended method

With vaporisator or disinfector.

Be sure to clean VORTEX®

The VORTEX®must be cleaned thoroughly before the first use.

If contamination is visible VORTEX®must be cleaned immediately.

The VORTEX®can be cleaned as follows (see Figure 8-13)
