Parkside 96233 Manuale utente

FINE SOLDERING IRON SET PLBS 30 A1

FINE SOLDERING IRON SET

Operation and Safety Notes

JUOTOSKOLVISARJA

Käyttö- ja turvaohjeet

LÖDKOLVSET

Bruksanvisning och säkerhetsanvisningar

FEINLÖTKOLBEN-SET

Bedienungs- und Sicherheitshinweise

FINLODDEKOLBE-SÆT

Brugs- og sikkerhedsanvisninger

IAN 96233

GB/IE Operation and Safety Notes Page 5

FI Käyttö- ja turvaohjeet Sivu 19

SE Bruksanvisning och säkerhetsanvisningar Sidan 31

DK Brugs- og sikkerhedsanvisninger Side 45

DE/AT / CH Bedienungs- und Sicherheitshinweise Seite 59

Before reading, unfold the page containing the illustrations and familiarise yourself with all

functions of the device.

Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.

Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant

med apparatens/maskinens funktioner.

Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend

mit allen Funktionen des Gerätes vertraut.

A B

C D

10 3

119

5GB/IE

Table of contents

Introduction

Proper use ............................................................................... Page 6

Features and equipment......................................................... Page 7

Included items......................................................................... Page 7

Technical information ............................................................. Page 7

Safety advice

1. Workplace safety............................................................... Page 8

2. Electrical safety.................................................................. Page 8

3. Personal safety ................................................................... Page 9

4. Careful handling and use of electrical power tools........ Pag e 11

Original accessories/attachments....................................... Pa ge 11

Before first use

Fitting the helical spring ......................................................... Page 12

Inserting/replacing soldering tips........................................ Page 12

Operation

Switching on and off .............................................................. Page 13

Third hand ............................................................................... Page 13

Solder sponge......................................................................... Page 13

Soldering................................................................................. Page 14

Maintenance and cleaning.................................. Page 15

Service centre ................................................................. Page 16

Warranty ............................................................................ Page 16

Disposal................................................................................ Page 17

6 GB/IE

IntroductionIntroduction

Fine soldering iron set PLBS 30 A1

Q Introduction

We congratulate you on the purchase of your new device. You have

chosen a high quality product. The instructions for use are part of the

product. They contain important information concerning safety, use

and disposal. Before using the product, please familiarise yourself with

all of the safety information and instructions for use. Only use the unit as

described and for the speciﬁed applications. If you pass the product on

to anyone else, please ensure that you also pass on all the documen-

tation with it.

Q Proper use

The appliance is intended for electronic soldering for leisure and DIY

purposes. It is designed for uses such as soldering work, wood-engrav-

ing, welding and gluing plastics and the application of decorations.

Use the device only as described and for the indicated purposes. The

device is not intended for commercial use. Any other use or modiﬁca-

tion to the device shall be considered as improper use and could give

rise to considerable dangers. The manufacturer will not accept liability

for loss or damage arising from improper use.

7GB/IE

IntroductionIntroduction

Q Features and equipment

1Soldering pencil

2Soldering tip

3Helical spring

4Clips

5Third hand

6Holder for copper attachments

7Multifunctional holder

8Soldering sponge

9Universal attachment

10 Pointed attachment

11 Conical attachment

12 Tin solder

Q Included items

1 Fine soldering iron set PLBS 30 A1

1 Multifunctional holder

2 Rolls of soldering tin (10 grams each)

2 Soldering tips (1x installed)

4 Copper attachments (engraving tips)

1 Solder sponge

1 Operating instructions

Q Technical information

Electricity supply: 230V AC

Nominal frequency: 50Hz

Rated power: 30W

8 GB/IE

Safety adviceSafety advice

Q Safety advice

CAUTION! Failure to observe the instructions and advice given be-

low may result in electric shock, ﬁre and/ or serious injury.

1. Workplace safety

a) Keep your working area clean and well lit. Untidy or

poorly lit working areas can lead to accidents.

b) Do not work with the device in potentially explosive

environments in which there are inflammable liquids,

gases or dusts. Electrical power tools create sparks, which can

ignite dusts or fumes.

c) Keep children and other people away while you are

operating the electrical tool. Distractions can cause you to

lose control of the device.

2. Electrical safety

To avoid danger to life from electric shock:

The mains plug on the device must match

the mains

socket. The plug must not be modified in any way.

Do not use an adapter plug with devices fitted with

a protective earth. Unmodiﬁed plugs and matching sockets

reduce the risk of electric shock.

b) Keep the device away from rain or moisture. Water

entering an electrical device increases the risk of electric shock.

c) Use a residual current device (RCD) for protection if

operating the electrical power tool in a moist envi-

9GB/IE

Safety adviceSafety advice

ronment is unavoidable. The use of an RCD reduces the risk

of electric shock.

d) Do not use the mains lead for any purpose for which

it was not intended, e.g. to carry the device, to hang

up the device or to pull the mains plug out of the

mains socket. Keep the mains lead away from heat,

oil, sharp edges or moving parts of the device. Dam-

aged or tangled mains leads increase the risk of electric shock.

e) D

o not operate the device if the mains lead or mains plug is damaged.

A damaged mains lead presents a serious

danger to life from electric shock.

f) Always keep the mains lead out of the operating area and run it

away from the rear of the device.

g) Always pull out the mains plug if you are about to leave the device

unattended or wish to carry out any tasks on the device.

3. Personal safety

a) This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

b) Remain alert at all times, watch what you are doing

and always proceed with caution. Do not use the

device if you are tired or under the influence of drugs,

alcohol or medication. One moment of carelessness when

using the device can lead to serious injury.

10 GB/IE

Safety adviceSafety advice

DANGER OF BURNS! Never touch the hot soldering tip or the

molten solder. You could suﬀer burn injuries. Always let the device

cool before you replace components on the device, clean it or check

its condition.

After use let the soldering pencil cool down in air only. Under no

circumstances quench the tip in water!

CAUTION! DANGER OF FIRE! Place the soldering pencil

down only in the special multifunctional holder or on a ﬁre-resist-

ant pad.

Place the soldering pencil in the multifunctional holder during

pauses in your work.

Keep the device away from combustible material.

Never leave the device switched on and unattended.

CAUTION! DANGER OF INJURY! Keep your hands away

from the hot workpiece. The heat from soldering can be conducted

through the workpiece. For this reason you should use the third

hand to hold small workpieces.

Avoid placing the hot soldering tip in contact with the plastic parts

of the multifunctional holder. Failure to observe this advice may

result in damage to the device.

If a dangerous situation arises, pull the mains plug immediately

out of the mains socket.

CAUTION! DANGER OF POISONING! Do not breathe air

contaminated with soldering fumes.

When working with the device for long periods do not allow the

fumes from soldering to build up. They may be hazardous to

health. Always provide adequate ventilation of your working area.

In addition, it is recommended

that you wear protective gloves, a

face mask and a protective

apron.

Do not eat, drink or smoke in rooms where soldering is carried

out. Otherwise your hands may transfer any adhering traces of

lead via food or cigarettes into your body.
