User Manual
Tel: (RSA) 010 140 4900 / Email: [email protected]
www.parrot.co.za
Laminating Machine 2 Roller A3
- LF9041
Product Description
LED
Switch Button
Entry
Specification
Voltage: 220 -240V/50 Hz Current: 1.2A
Ready time: 1.5 minutes Entry width: 330mm
Thickness: 0.6 mm Pouch: 80 and 125mic
Speed: 400 mm/min Rollers: 2
Size: N.W.: 0.9 Kg
Read this manual carefully before use. Keep it safe for future reference.
Thank you for buying this high-performance laminator! This laminator features
a slim and compact design. It accepts pouches ranging from 80mic to 125mic
in thickness, with size from name card to A3 size.
470 x 100 x 60mm
Utility
It laminates both 80mic and 125mic thermal pouches from name card size to A3 size.
To get a better lamination performance, the suitable room temperature is
18℃~25℃ (namely 65℉~77℉).
Operation
POWER ON and OFF
Connect the plug to mains power, press the rocker switch to turn on the machine.
The Power LED will turn red. If you press rocker switch to "Cold" position,
the machine is under cold lamination status. If you press rocker switch onto
"Hot" position , the machine is under hot lamination status for thermal pouches.
To turn off this laminator, press switch button back to "Off" position, power will be cut
off and laminator is shut off.
THERMAL LAMINATION
To laminate the document, you would have to wait for about 1.5 minutes until the
Green Ready LED turns on. Then place the paper into a laminating pouch, and insert
the pouch through the laminator entry. The sealed edge of the laminating pouch should
always be inserted first.
During the lamination process, the “READY LED” may go out, it will not influence
lamination.
Note:
Clear the Jammed Pouch
This laminator is designed with creative anti-jamming structure. Normally speaking,
the pouch would not be jammed inside. In case a mis-feed occurs, first turn off the
laminator, and then pull the pouch out by hand.
Maintenance and Warning
1. To clean or move around, make sure that this laminator is turned off.
2. Do not laminate dirty pouches, clean it before lamination.
3. Do not use this laminator in damp conditions.
4. Do not laminate anything that is more than 0.6mm thickness for best seal.
5. Do not laminate heat sensitive paper.
6. This laminator should only use power 220-240V/50Hz and be used indoors only.
Warranty
This product comes with 2 year limited warranty
NEVER OPEN THIS LAMINATOR WHILE IN USE
