Pars ABL GIANT 3.0 Manuale utente
Introduction
We congratulate to the choice of ABL GIANT 3.0 Sweeping machine
The manual book will make you familiar with the machine.
The machine has been designed and developed using the latest technology,
combined with many years of production experience.
It is important that drivers and service people read and understand how the
machine is working before the machine is put into operation.
The manual provides information on the following points.
-The advantages of the sweeper
-Safety
-Service adjustments
-Technical information
-Warranty conditions
When ordering brushes, wear and spare parts always state
-Machine type
-Serial number
-Year
In our quest to always develop and improve all ABL products. It may
happen that the latest changes are not included in the manual book
If you have any questions, please contact us in one of the following ways.
-Mobile +46(0)38 267 600
-Email [email protected]
-Web www.abl.se
TABLE OF CONTENTS
GENERALLY
4
WARRANTY
5
ASSEMBLY DRAWING
6-7
TOWING VEHICLE
8
SECURITY AND WARNING LABELS
9
POSITIONING OF SAFETY AND WARNINGS LABELS
10
SAFETY
11-14
AFTER FIRST 8 HOUR
15
CONNECTION OF MACHINE BEHIND TRUCK
16
DRIVING FUNCTION
17-19
SWEEPING
20-21
LUBRICATION AND MAINTENANCE
22-39
REPLACEMENT OF WEAR PARTS
40-43
SETTINGS
44-52
TROUBLESHOOTING
53
TECHNICAL INFORMATION
54-56
EC DECLARATION
57
3
GENERALLY
ABL GIANT 3.0 is a truck towed mechanical elevator sweeper with its own diesel engine for
hydraulic operation. This machine has a wheel axle with spring leaf suspension which is
specially adapted for this machine, it allows to transport the machine at 80 km/h on the
roads.
To maintain vehicle operation and road safety, maintenance work shall be
performed at the specified intervals, that are specified in this book
The towing vehicle should be a tipping truck, with an approved trailer coupling and electrical
socket for lighting and right and left turn indicators. All sweepers functions are controlled
with one touch easy control display in drivers’ cabin.
Sweeping principle
The side brushes sweep the material into the centre of the machine, back brushes throw the
debris further up into the elevator. The conveyor belt moves the thrash up on the truck
platform, the water spray bar prevent the dust binding.
The ABL GIANT 3.0 sweeper is suitable for sweeping sand, gravel, paper on streets and
squares roads and industrial areas. Avoid sweeping up packaging strips, large stones and
pieces of wood that can damage elevator rakes in the elevator.
4
WARANTY
ABL provides a 12-month factory warranty on each new machine. Warranty applies to
material defects and improper work of up to a maximum of 1000 operating hours and
provided that the prescribed service and maintenance has been performed.
In the event of a design failure, ABL assumes all costs. Otherwise only incorrect parts and
freight are replaced in one direction. Please always indicate the machine type, year model
and serial number. These details are stated on the machine plate
5
ASSEMBLY DRAWING
Main dimension - Front view / Back view
6
ASSEMBLY DRAWING
Main Dimension –Side view / Component view
7
TOWING VEHICLE
The vehicle should be a tipping truck and should be equipped with the following
-Rotating warning lights
-Adapted towing device
-Connectors for connecting lighting, brakes, left and right turn indicators
Towing bracket
When connecting a machine to the truck, the tow bar must be adjusted so that it is
horizontal between the truck and the sweeper. Height adjustment is done by changing the
drawbar attachment (A).
Remote Control box
Remote box is mounted stable and clearly visible in the cab of the towing vehicle, and within
easy reach of the driver. It should not be loose, Power should be taken from the trucks 12-
volt electrical system, fuse is connected to the remote box.
Connectors
Cable with remote control switch must be mounted at the rear of the truck in connection
with the sweeper.
8
SECURITY AND WARNING LABELS
Warning!
Serious person or property damage can be caused if the warning instructions are not
followed, always read the instructions manual.
Read this manual before using the machine
Engine must always be stopped before work
Warning rotating brushes
Do not stand between Truck and machine
Maximum hydraulic pressure 150 Bar
9
POSITIONING OF SAFETY AND WARNINGS LABELS
10
