pathway VIA PWVIA RM P12 Manuale utente

User Guide
July 2021
Rack-mount
Ethernet Switches
PWVIA RM P12 Models
Running firmware 6.1 or later
© 2021 Acuity Brands, Inc. • One Lithonia Way, Conyers GA 30012
Pathway Connectivity | #103 - 1439 17th Ave SE Calgary, AB Canada T2G 1J9
Phone: + 1 866 617 3074
TM

Copyright © Pathway Connectivity
A Division of Acuity Brands Lighting Canada (“Pathway”) and its licensors.
All rights reserved.
This software and, as applicable, associated media, printed materials and “on-line” or electronic
documentation (the “Software Application”) constitutes an unpublished work and contains valuable trade
secrets and proprietary information belonging to Pathway and its licensors.
WARNING ABOUT INSECURE PROTOCOLS
Enabling an open protocol that does not use encryption or authentication - these protocols could be
eavesdropped or spoofed by malicious parties. You are strongly encouraged to secure access to your
network, both physically and technologically. To continue, you must acknowledge that you have read
this statement and accept these risks.

CONTENTS
ABOUT VIA RACK-MOUNT ETHERNET SWITCHES - PWVIA RM .1
INSTALLATION INSTRUCTIONS........................................................2
OPTIONAL MOUNTING ACCESSORIES ..............................................2
PANEL LAYOUTS ................................................................................4
FRONT PANEL........................................................................................4
MODELS PWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] [NONPOE/
POE] ����������������������������������������������������������������������������������������������������������������������4
MODEL PWVIA RM P12 RJ45EC [DUO/QUAD] POE ������������������������������������������4
REAR PANEL ..........................................................................................4
MODEL PWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] NONPOE �������4
MODEL PWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] POE ���������������5
MODEL PWVIA RM P12 RJ45EC DUO POE��������������������������������������������������������5
MODEL PWVIA RM P12 RJ45EC QUAD POE �����������������������������������������������������5
SFP+ PORTS���������������������������������������������������������������������������������������������������������6
opticalCON PORTS ����������������������������������������������������������������������������������������������6
POWER CONNECTIONS ��������������������������������������������������������������������������������������6
CONFIGURATION ...............................................................................6
SECURITY ...........................................................................................7
BACKGROUND INFORMATION ............................................................7
WHAT THIS MEANS TO YOU ................................................................7
SECURITY DOMAINS ............................................................................8
RED PADLOCK - “Ready to Secure” device (previously “Unsecured”)��������8
AMBER PADLOCK - “Other Domain” name showing device������������������������8
AMBER PADLOCK - “Read Only” (previously “Locally Secured”) ����������������8
GREEN PADLOCK - “My Domain” shows devices in the current domain����9
NO PADLOCK - “Disabled By User” – Firmware version 6�1 or later - rackmount

devices with front panel UI only���������������������������������������������������������������������������9
EMPTY SECURITY DOMAIN CELL – Firmware version prior to 5�0 - device
shipped prior to January 1, 2020 �������������������������������������������������������������������������9
CREATING A SECURITY DOMAIN......................................................10
ADMINISTERING A DOMAIN ..............................................................15
MANAGE SECURITY DOMAIN���������������������������������������������������������������������������15
MANAGE DEVICES���������������������������������������������������������������������������������������������19
RECOVERING A DOMAIN ...................................................................21
RETAINING DEVICE SETTINGS FROM UNKNOWN DOMAINS........23
USING OLDER VERSIONS OF PATHSCAPE WITH NEW DEVICES..23
LOCAL CONFIGURATION ONLY - Using PWVIA RM without Pathscape
...............................................................................................................24
DISABLING SECURITY ........................................................................25
PATHWAY ssACN (Secure sACN) .......................................................26
DOMAIN AUTO ssACN PASSWORD������������������������������������������������������������������26
CUSTOM ssACN PASSWORD ���������������������������������������������������������������������������26
USING PATHWAY ssACN WITH VIA....................................................27
NOTES ABOUT PATHWAY ssACN ���������������������������������������������������������������������28
SOFTWARE (PATHSCAPE) CONFIGURATION................................29
NETWORK SETUP ...............................................................................29
DEVICE PROPERTIES..........................................................................30
PATHWAY SECURITY DOMAIN��������������������������������������������������������������������������30
BASIC PROPERTIES ������������������������������������������������������������������������������������������31
DEVICE INFO ������������������������������������������������������������������������������������������������������31
DEVICE TIME SETTINGS������������������������������������������������������������������������������������32
NETWORK PROPERTIES �����������������������������������������������������������������������������������32
ADVANCED FEATURES ��������������������������������������������������������������������������������������33
VLAN PROPERTIES ��������������������������������������������������������������������������������������������34
Art-Net TRAP AND CONVERT����������������������������������������������������������������������������34
REMOTE MONITORING AND MANAGEMENT ��������������������������������������������������34

RING PROTECT PROPERTIES (EAPS) ��������������������������������������������������������������35
PoE PROPERTIES (POE Models)�����������������������������������������������������������������������37
ADVANCED PROPERTIES����������������������������������������������������������������������������������37
VLAN CONFIG ......................................................................................38
VLAN GLOBAL PROPERTIES ����������������������������������������������������������������������������39
WARNING �������������������������������������������������������������������������������������������������40
VLAN PROPERTIES/SERVICES �������������������������������������������������������������������������41
RESOLVING VLAN CONFLICTS ..........................................................44
PORT PROPERTIES AND CONFIGURATION .....................................46
BASIC PROPERTIES ������������������������������������������������������������������������������������������47
LINK DETAILS �����������������������������������������������������������������������������������������������������47
NETWORK PARTNER (LLDP) �����������������������������������������������������������������������������48
VLAN PROPERTIES ��������������������������������������������������������������������������������������������49
Art-Net TRAP AND CONVERT����������������������������������������������������������������������������49
POE PROPERTIES (NOT SHOWN ON NONPOE Model)�����������������������������������50
UPGRADING DEVICE FIRMWARE......................................................52
FACTORY DEFAULT..........................................................................53
FRONT PANEL LOCKOUT...................................................................54
FRONT PANEL UI AND MENU .........................................................55
SETTING SECURITY MODE ................................................................55
MAIN DISPLAY MESSAGES ................................................................57
USING THE FRONT PANEL UI ............................................................57
MENUS..................................................................................................58
NETWORK SETUP����������������������������������������������������������������������������������������������58
DEVICE INFO/STATUS����������������������������������������������������������������������������������������60
ADVANCED SETTINGS���������������������������������������������������������������������������������������61
ADMIN/SECURITY����������������������������������������������������������������������������������������������72
PORT STATUS AND CONFIGURATION MENU ��������������������������������������������������74
PORT 13 & 14: CONFIGURATION/STATUS: SFP+ PORTS��������������������������������79
APPENDIX 1: SFP/SFP+ FIBER ADAPTER SELECTION................83

APPENDIX 2: VIRTUAL LOCAL AREA NETWORK (VLAN).............84
DEFINITIONS ������������������������������������������������������������������������������������������������������84
SOFTWARE CONFIGURATION OF VLANs ��������������������������������������������������������84
VLAN GUIDELINES ���������������������������������������������������������������������������������������������84
APPENDIX 3: PLANNING CHARTS .................................................85
VLAN PLANNING CHART�����������������������������������������������������������������������������������85
SWITCH PLANNING CHARTS����������������������������������������������������������������������������87
APPENDIX 4: EAPS & RSTP - “RING PROTECTION” ....................89
Requirements and Limitations ���������������������������������������������������������������������������89
Definitions for EAPS �������������������������������������������������������������������������������������������89
Software Configuration of Ring��������������������������������������������������������������������������90
APPENDIX 5: QoS SETTINGS ..........................................................91
APPENDIX 6: ELECTRICAL AND COMPLIANCE INFORMATION.92
ELECTRICAL INFORMATION..............................................................92
MODEL PWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] NONPOE �����92
MODEL PWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] POE �������������92
MODEL PWVIA RM P12 RJ45EC [DUO/QUAD] POE ����������������������������������������92
COMPLIANCE ......................................................................................92
ENVIRONMENTAL................................................................................92
PHYSICAL.............................................................................................93
PPWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] NONPOE�����������������93
PPWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] POE�������������������������93
PPWVIA RM P12 RJ45EC [DUO/QUAD] POE ���������������������������������������������������93


July 2021 1
PWVIA RM P12 Ethernet Switches - Manual
ABOUT VIA RACK-MOUNT ETHERNET SWITCHES - PWVIA RM
VIA™ Gigabit Ethernet Switches are designed for live entertainment Ethernet systems, including audio, video and DMX-over-
Ethernet networks. This manual covers models PWVIA RM P12 RJ45EC [SFPSLOT/1GSFP/10GSFPP] [NONPOE/POE],
and PWVIA RM P12 RJ45EC [DUO/QUAD] POE
VIA Ethernet Switches are intended specifically for signal routing between Pathport DMX-over-Ethernet gateways, or similar
equipment, and Ethernet-aware lighting and audio control products, such as consoles and controllers and end equipment. A
VIA is a routing device and is not a source of the control protocols or the data being passed. Switches only provide management
control over the data path.
The PWVIA RM P12 family is easily configured and upgraded using the freely available software tool, Pathscape. They are also
configurable using the Front Panel UI, which consists of the LCD and rotary pushbutton encoder.
IMPORTANT: VIA model PWVIA RM P12 RJ45EC [xxxx] NONPOE does not provide
hardware support for IEEE 802.3af Power-over-Ethernet (PoE). It does not provide a way to
connect an external PoE supply.
VIA models PWVIA RM P12 RJ45EC [xxxx] POE feature an integrated 100W PoE supply for
powering compatible external devices.
If you connect PoE-enabled devices to a NONPOE model they will not receive power.

PWVIA RM P12 Ethernet Switches - Manual July 2021
2
INSTALLATION INSTRUCTIONS
PWVIA RM P12 switches are intended for desktop use, or to be mounted in a standard 19” equipment rack, using the integral
rack ears (models PWVIA RM P12 RJ45EC [DUO/QUAD] POE) or the included rack ear accessories (models PWVIA RM P12
RJ45EC[SFPSLOT/1GSFP/10GSFPP] [NONPOE/POE]).
Rack ears included with the PWVIA RM P12 RJ45EC[SFPSLOT/1GSFP/10GSFPP] [NONPOE/POE] models for attaching unit to 19” equipment rack
Use the included machine screws (2 per side) to attach the rack ears to the either side of the metal chassis (PWVIA RM P12
RJ45EC[SFPSLOT/1GSFP/10GSFPP] [NONPOE/POE] models).
POE
LINK/ACT
PORT 1 PORT 2 PORT 3 PORT 4 PORT 5 PORT 6 PORT 7 PORT 8 PORT 9 PORT 10
TM
If using the PWVIA RM P12 on a desktop permanently, you may wish to apply the included adhesive rubber feet pads to the
bottom of the unit. Simply peel them off the adhesive backing and apply to the bottom of the metal enclosure, with one on
each corner.
OPTIONAL MOUNTING ACCESSORIES
Wall-mount kits (PWACC WMLG) and Truss-mount adapters (PWACC TMLG) are available as accessories.
POE
LINK/ACT
PORT 1 PORT 2 PORT 3 PORT 4 PORT 5 PORT 6 PORT 7 PORT 8 PORT 9 PORT 10
TM
POE
LINK/ACT
PORT 1 PORT 2 PORT 3 PORT 4 PORT 5 PORT 6 PORT 7 PORT 8 PORT 9 PORT10
TM
PWACC WMLG Wall-mount Kit PWACC TMLG Truss-mount Kit

July 2021 3
PWVIA RM P12 Ethernet Switches - Manual
All PWVIA RM P12 Switches are intended for installation in a dry, indoor location. Ambient operating conditions are 14°F to
122°F (-10°C to 50°C); 5-95% relative humidity, non-condensing.
Warning: The AC socket outlet shall be installed near the equipment and shall be easily
accessible.
Warning: This equipment relies on building installation primary overcurrent protection.
Warning: Except for the chassis plug marked for AC input, all ports on the PWVIA RM P12
models are intended for low voltage and/or data lines only. Attaching anything other than low
voltage sources to the data ports may result in severe equipment damage, and personal injury
or death.
Altri manuali per VIA PWVIA RM P12
1
Indice
Altri manuali pathway Hardware di rete
Manuali Hardware di rete popolari di altre marche

Matrix Switch Corporation
Matrix Switch Corporation MSC-HD161DEL Manuale utente

B&B Electronics
B&B Electronics ZXT9-IO-222R2 Manuale utente

Yudor
Yudor YDS-16 Manuale utente

D-Link
D-Link ShareCenter DNS-320L Manuale utente

Samsung
Samsung ES1642dc Istruzioni per l’uso

Honeywell Home
Honeywell Home LTEM-PV Istruzioni per il montaggio
