SmartLink M-ATA

Micro-Analog Telephone Adapter

Quick Start Guide

Figure 1. SmartLink M-ATA installation diagram

Phone LED

Power LED

System LED

LAN LED

Gaithersburg, Maryland

M-ATA

Micro-Analog

Telephone Adapter

PHONE

LAN

SYSTEM

POWER

Power jack

Power adapter

LAN port

3

PC or

LAN --or-- LAN

Hub/Switch

Phone

Phone jack

2 4

Front

view

Rear

view

Part Number: 07MSLMATA-QS, Rev. C

Revised: February 9, 2012

Sales Office: +1 (301) 975-1000

Technical Support: +1 (301) 975-1007

E-mail: [email protected]

WWW: www.patton.com

2SmartLink M-ATA Quick Start Guide

1.0 Quick Start

• The M-ATA contains no user serviceable parts. The equipment shall be

returned to Patton Electronics for repairs, or repaired by qualified

service personnel.

• The external power adapter shall be a listed Limited Power Source.

Ensure that the power cable used with this devise meets all applicable

standards for the country in which it is to be installed, and that it is

connected to a wall outlet which has earth ground. The mains outlet

that is utilized to power the devise shall be within 10 feet (3 meters)

of the device, shall be easily accessible, and protected by a circuit

breaker.

• Do not work on the system or connect or disconnect cables during

periods of lightning activity.

The interconnecting cables shall be acceptable for external use and shall be rated for

the proper application with respect to voltage, current, anticipated temperature, flam-

mability, and mechanical serviceability.

The unit should be installed in a dry environment with at least 2 inches (5 cm) of clearance at the sides

and front of the unit to allow air circulation for cooling.

Plug in the telephone (see figure 1 on page 1).

Plug in the PC or LAN, or a LAN hub/switch.

Plug the power adapter into the power jack on the SmartLink M-ATA (see figure 1 on page 1). Connect

the other end of the power cord to an appropriate AC power outlet.

Wait 30 seconds after powering the SmartLink M-ATA on, then verify that the green Power LED is lit (see

figure 1 on page 1).

By default, the M-ATA will automatically request IP network settings from the LAN using DHCP. To deter-

mine the IP address of the SmartLink, lift the handset off the attached analog phone and dial ****.

Dial 1 0 0 #, listen to and record the IP address of the SmartLink. (To manually set the IP address, see

appendix B.2 “Existing voice prompt configuration” on page 4 for details).

Use a web browser to connect to the SmartLink M-ATA. The URL will be http://<ip address>. For exam-

ple, if the M-ATA IP address was 10.10.10.2, the URL would be http://10.10.10.2.

The default password is “root ”.

WARNING

CAUTION

1

2

3

4

5

6

7

SmartLink M-ATA Quick Start Guide 3

2.0 Additional information

For detailed information about configuring and operating guidance, set up procedures, and troubleshooting,

refer to the SmartLink M-ATA User Manual available online at www.patton.com/manuals/M-ATA.pdf.

A.0 Compliance Information

A.1 Compliance

EMC: Safety:

FCC Part 15, Class B EN 60950-1

EN55022, Class B

EN55024

A.2 Radio and TV Interference (FCC Part 15)

This equipment generates and uses radio frequency energy, and if not installed and used properly—that is, in

strict accordance with the manufacturer's instructions—may cause interference to radio and television recep-

tion. This equipment has been tested and found to comply with the limits for a Class B computing device in accor-

dance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable

protection from such interference in a commercial installation. However, there is no guarantee that interference

will not occur in a particular installation. If the equipment causes interference to radio or television reception,

which can be determined by disconnecting the cables, try to correct the interference by one or more of the fol-

lowing measures: moving the computing equipment away from the receiver, re-orienting the receiving antenna,

and/or plugging the receiving equipment into a different AC outlet (such that the computing equipment and

receiver are on different branches).

A.3 CE Notice (Declaration of Conformity)

We certify that the apparatus identified in this document conforms to the requirements of Council Directive

1999/5/EC on the approximation of the laws of the member states relating to Radio and Telecommunication

Terminal Equipment and the mutual recognition of their conformity.

The safety advice in the documentation accompanying this product shall be obeyed. The conformity to the above

directive is indicated by the CE sign on the device.

Follow the directions of your voice service provider to set up voice services.

IMPORTANT

4SmartLink M-ATA Quick Start Guide

B.0 Voice prompt configuration

The M-ATA provides the ability to review and set the network configuration parameters using the handset of an

attached analog telephone handset.

By default from the factory, DHCP is enabled and an IP address is not configured.

The M-ATA must be power cycled or reloaded after changing any of the network settings. Menu selection item

Network Status will not reflect setting changes until after M-ATA is reloaded or power cycled.

Note Configuration of these settings can result in loss of connectivity to the M-ATA on the local LAN.

B.1 Accessing the voice prompt

Dial **** from the analog handset to reach the main menu.

B.2 Existing voice prompt configuration

On hook the analog phone.

Access

Code Main Menu

Selection Announcement/Function Voice Prompt User input

**** Main Menu Plays main menu selections SmartLink Configuration

Main Menu Enter selection code

100# Network status Plays DHCP setting, IP address,

gateway IP address and IP net-

work mask setting

100# Network status None.

110# DHCP setting Enables or Disables DHCP 110# DHCP Settings 1# to enable DHCP

2# to disable DHCP or “#” to return

to the main menu

120# IP address setting Sets IP address of

the M-ATA 120# Set IP Address Use “*” to instead of .“.”, and “#”

to end.

Ex: 172*16*230*227# or “#” to

return to the main menu

130# Gateway setting Sets the gateway router IP

address 130# Set gateway router

IP address Use “*” to instant of “.”, and “#” to

end or “#” to return to the main

menu

140# Net mask setting Set the IP network mask 140# Set IP

network mask Use “*” to instant of “.”, and “#” to

end or “#” to return to the main

menu

150# Reload Immediately reloads

the SmartLink None None

SmartLink M-ATA Quick Start Guide 5

Copyright statement

The information in this document is subject to change without notice. Patton Electronics assumes no

liability for errors that may appear in this document.

Trademarks statement

The term SmartLink is a trademark of Patton Electronics Company. All other trademarks presented in this docu-

ment are the property of their respective owners.

Warranty, Trademark, & Compliance Information

For warranty, trademark and compliance information, refer to the SmartLink M-ATA User Manual located online

at www.patton.com/manuals.

In accordance with the requirements of ouncil directive 2002/96/EC on Waste of Elec-

trical and Electronic Equipment (WEEE), ensure that at end-of-life you separate this

product from other waste and scrap and deliver to the WEEE collection system in your

country for recycling.
