SmartNode™ 4120
Single/Dual-Port ISDN BRI
VoIP Gateway
Quick Start Guide
Important
—
This is a Class B device and is intended for use in a light industrial or residential
environment. It is not intended nor approved for use in an industrial environment
.
Part Number: 07MSN4120-QS, Rev. B
Revised: February 9, 2012
Sales Office: +1 (301) 975-1000
Technical Support: +1 (301) 975-1007
E-mail: support@patton.com
www.patton.com
2SmartNode Model 4120 Quick Start Guide
1.0 Power up the SmartNode
1. Connect the SmartNode to a power source using the included power supply and cable.
2. When the Power LED stops blinking and remains lit, the SmartNode is ready to configure.
• Do not open the device when the power cord is connected. For sys-
tems without a power switch and without an external power
adapter, line voltages are present within the device when the power
cord is connected.
• For devices with an external power adapter, the power adapter shall
be a listed Limited Power Source The mains outlet that is utilized to
power the device shall be within 10 feet (3 meters) of the device,
shall be easily accessible, and protected by a circuit breaker in compli-
ance with local regulatory requirements.
• For AC powered devices, ensure that the power cable used meets all
applicable standards for the country in which it is to be installed.
• For AC powered devices which have 3 conductor power plugs (L1, L2
& GND or Hot, Neutral & Safety/Protective Ground), the wall outlet
(or socket) must have an earth ground.
• For DC powered devices, ensure that the interconnecting cables are
rated for proper voltage, current, anticipated temperature, flammabil-
ity, and mechanical serviceability.
• WAN, LAN & PSTN ports (connections) may have hazardous voltages
present regardless of whether the device is powered ON or OFF.
PSTN relates to interfaces such as telephone lines, FXS, FXO, DSL,
xDSL, T1, E1, ISDN, Voice, etc. These are known as “hazardous net-
work voltages” and to avoid electric shock use caution when working
near these ports. When disconnecting cables for these ports, detach
the far end connection first.
• Do not work on the device or connect or disconnect cables during peri-
ods of lightning activity.
WARNING
SmartNode Model 4120 Quick Start Guide 3
2.0 Configuring your SmartNode
Refer to the SmartNode Model 4120 User Manual available online at www.patton.com/manuals/
SN4120.pdf for detailed information about:
•
Installing, configuring, operating, and troubleshooting the SmartNode
•
Warranty, trademark & compliance
A.0 Customer and Technical Support
Online support: www.patton.com
Telephone support:
•
Standard: +1 (301) 975-1007 (USA), Monday–Friday: 8:00 am to 5:00 pm EST (1300 to
2200 UTC/GMT)
•
Alternate: +41 (0)31 985 25 55 (Switzerland), Monday–Friday: 9:00 am to 5:30 pm CET (08:00 to 16:30
UTC/GMT)
Fax: +1 (253) 663-5693 (USA) or +41 (0)31 985 25 26 (Switzerland)
B.0 Appendix—Factory default settings
Username: administrator
Password: (blank)
IP Address: DHCP
Network Mask: n/a
4SmartNode Model 4120 Quick Start Guide
C.0 Compliance Information
C.1 Compliance
EMC Compliance:
•
EN55022, Class B
•
EN55024
Safety Compliance:
•
IEC 60950-1
•
EN60950-1
PSTN Compliance:
•
AS/ACIF S003:2008
C.2 CE Declaration of Conformity
Product: SN4120
We certify that the apparatus described above conforms to the requirements of the following directives:
2004/108/EC on the approximation of the laws of the member states relating to electromag-
netic compatibility.
2006/95/EC on the approximation of the laws of the member states relating to electrical equip-
ment designed for use within certain voltage limits
.
The safety advice in the documentation accompanying this product shall be
obeyed. The conformity to the above directives are indicated by the CE sign on
the device.
SmartNode Model 4120 Quick Start Guide 5
C.3 EG-Konformitätserklärung
Produktbezeichnung: SN4120
Die bezeichneten Produkte stimmen in der von uns in Verkehr gebrachten Ausführung mit den Vorschriften fol-
gender Richtlinie überein:
2004/108/EG
Richtlinie des europäischen Parlaments und des Rates vom 15. Dezember 2004 zur Angleichung der
Rechtsvorschriften der Mitgliedstaaten über die elektromagnetische Verträglichkeit und zur Aufhe-
bung der Richtlinie 89/336/EWG.
2006/95/EG
Richtlinie des europäischen Parlaments und des Rates vom 12. Dezember 2006 zur Angleichung der
Rechtsvorschriften der Mitgliedstaaten betreffend elektrische Betriebsmittel zur Verwendung innerh-
alb bestimmter Spannungsgrenzen.
Die unterzeichnete Konformitätserklärung kann heruntergeladen werden von: www.patton.com/
certifications/.
C.4 Authorized European Representative
D R M Green, European Compliance Services Limited.
Oakdene House, Oak Road , Watchfield, Swindon, Wilts SN6 8TD, UK
Die Sicherheitshinweise in der mitgelieferten Produktdokumentation sind zu beachten.
Die Konformität mit der oben erwähnten Richtlinie wird durch das CE-Zeichen auf dem
Gerät bestätigt.
6SmartNode Model 4120 Quick Start Guide
Copyright statement
Copyright © 2012, Patton Electronics Company. All rights reserved.
The information in this document is subject to change without notice. Patton Electronics assumes no
liability for errors that may appear in this document.
Trademarks statement
The term SmartNode is a trademark of Patton Electronics Company. All other trademarks presented in this docu-
ment are the property of their respective owners.
Warranty
For warranty information, refer to the SmartNode Model 4120 User Manual available online
at www.patton.com/manuals/SN4120.pdf.
In accordance with the requirements of council directive 2002/96/EC on Waste of
Electrical and Electronic Equipment (WEEE), ensure that at end-of-life you separate
this product from other waste and scrap and deliver to the WEEE collection system in
your country for recycling.
SmartNode Model 4120 Quick Start Guide 7
