TABLE OF CONTENTS
SectionPage
1.0Warranty Information.............................................................2
1.1Radio and TV Interference
1.2. CE Notice
1.3Service
2.0General Information...............................................................4
2.1Features
2.2Description
2.3 SNMP
3.0Configuration..........................................................................6
3.1Configuring the Hardware DIP Switches
3.1.1 Configuration DIP Switch Set “S1”
3.1.2 Configuration DIP Switch Set “S2”
3.2 Configuring the Software Switches
3.2.1 Configuring the LOCAL 1092A
4.0Installation.............................................................................20
4.1Connecting the Twisted Pair Interface
4.2 Connecting the Serial Port
4.2.1 Changing QuikConnect™ Modules
4.2.2 Connecting to a “DTE” Device
4.2.3 Connecting a to “DCE” Device
4.2.4 Configuring the X.21 QuikConnect™Module
4.3 Connecting Power
4.3.1 Connecting to an AC Power Source
4.3.2 Connecting to a DC Power Source
5.0Operation..............................................................................26
5.1Power- Up
5.2LED Status Monitors
5.3Test Modes
5.3.1 Using Local Line Loopback (LLB)
5.3.2 Using Remote Digital Loopback (RDL)
5.3.3 Using the V.52 (BER) Test Pattern Generator
Appendix A - Specifications.........................................................30
Appendix B - Factory Replacement Parts and Accessories.........31
Appendix C - Interface Pin Assignments.................................32-34
Appendix D - Control Port Pin Assignment...................................35
Appendix E - Model 1092A Quick Start Guide..............................36
1
1.0 WARRANTY INFORMATION
Patton Electronicswarrants all Model 1092A components to be
free from defects, and will—at our option—repair or replace the product
should it fail within one year from the first date of shipment.
This warranty is limited to defects in workmanship or materials,
and does not cover customer damage, abuse or unauthorized
modification. If this product fails or does not perform as warranted,
your sole recourse shall be repair or replacement as described above.
Under no condition shallPatton Electronicsbe liable for any damages
incurred by the use of this product. These damages include, but are
not limited to, the following: lost profits, lost savings and incidental or
consequential damages arising from the use of or inability to use this
product. Patton Electronicsspecifically disclaims all other warranties,
expressed or implied, and the installation or use of this product shall be
deemed an acceptance of these terms by the user.
1.1 RADIO AND TV INTERFERENCE
The Model 1092A generates and uses radio frequency energy, and
if not installed and used properly—that is, in strict accordance with the
manufacturer's instructions—may cause interference to radio and
television reception. The Model 1092A has been tested and found to
comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are
designed to provide reasonable protection from such interference in a
commercial installation. However, there is no guarantee that
interference will not occur in a particular installation. If the Model
1092A does cause interference to radio or television reception, which
can be determined by disconnecting the unit, the user is encouraged to
try to correct the interference by one or more of the following measures:
moving the computing equipment away from the receiver, re-orienting
the receiving antenna and/or plugging the receiving equipment into a
different AC outlet (such that the computing equipment and receiver are
on different branches).
1.2 CE NOTICE
The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the European Union
(EU). A Certificate of Compliance is available by contacting Technical
Support.
2
