Patton electronics MODEL 552 Manuale utente

USER

MANUAL

MODEL 552 Series

High Speed Telco Surge

Protectors

SALES OFFICE

(301) 975-1000

TECHNICAL SUPPORT

(301) 975-1007

http://www.patton.com

Part# 07M552-E

Rev. G

Revised 01/27/10

CERTIFIED

An ISO-9001

Certified Company

1.0 WARRANTY INFORMATION

Patton Electronics warrants all Model 552 components to be free

from defects, and will—at our option—repair or replace the product

should it fail within one year from the first date of shipment.

This warranty is limited to defects in workmanship or materials, and

does not cover customer damage, abuse or unauthorized modification.

If this product fails or does not perform as warranted, your sole

recourse shall be repair or replacement as described above. Under no

condition shall Patton Electronics be liable for any damages incurred

by the use of this product. These damages include, but are not limited

to, the following: lost profits, lost savings and incidental or

consequential damages arising from the use of or inability to use this

product. Patton Electronics specifically disclaims all other warranties,

expressed or implied, and the installation or use of this product shall be

deemed an acceptance of these terms by the user.

1.1 SERVICE

All warranty and non-warranty repairs must be returned freight

prepaid and insured to Patton Electronics. All returns must have a

Return Materials Authorization number on the outside of the shipping

container. This number may be obtained from Patton Electronics

Technical Service at: (301) 975-1007; http://www.patton.com; or,

[email protected].

NOTE: Packages received without an RMA number will not be

accepted.

Patton Electronics' technical staff is also available to answer any

questions about the installation or use of your Model 552. Technical

Service hours are: 8AM to 5PM EST, Monday through Friday.

1.2 CE NOTICE

The CE symbol on your Patton Electronics equipment indicates

that it is in compliance with the Electromagnetic Compatibility (EMC)

directive and the Low Voltage Directive (LVD) of the Union European

(EU). A Certificate of Compliance is available by contacting Technical

Support.

1.3 FCC COMPLIANCE

The 552 Series of surge protectors have been tested and found to

comply with FCC Parts 15 and 68. A label on the device bears the

Part 68 registration number. 12

1. This equipment complies with Part 68 of the Federal

Communications Commission Rules. On the outside surface of this

equipment is a label that contains, among other information, the

FCC registration number. This information must be provided to the

telephone company.

2. If this equipment causes harm to the telephone network, the

telephone company will notify you in advance that temporary

discontinuance of service may be required. But, if advance notice

is not practical, the telephone company will notify the customer as

soon as possible. Also, you will be advised of your right to file a

compliant with the FCC if you believe it is necessary.

3. The telephone company may make changes in its facilities,

equipment, operations, or procedures that could affect the

operation of the equipment. If this happens, the telephone

company will provide advance notice in order for you to make

necessary modifications in order to maintain uninterrupted service.

4. If trouble is experienced with any of the Model 552 Series, please

contact Patton Electronics Company at 301-975-1000. If the

equipment is causing harm to the network, the telephone company

may request you to remove the equipment from the network until

the problem is resolved.

5. Repairs are to be made only by Patton Electronics Company or its

licenses. Unauthorized repairs void registration and warranty.

6. This equipment cannot be used on public coin service provided by

the telephone company. Connection to Party Line Service is subject

to state tariffs. (Contact the state public utility commission, public

service commission or corporation commission for information).

1.4 INDUSTRY CANADA NOTICE

NOTICE: The Industry Canada label identifies certified equipment.

This certification means that the equipment meets telecommunications

network protective, operational and safety requirements as prescribed

in the appropriate Terminal Equipment Technical Requirements

document(s). The Department does not guarantee the equipment will

operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is

permissible to be connected to the facilities of the local

telecommunications company. The equipment must also be installed

using an acceptable method of connection. The customer should be

aware that compliance with the above conditions may not prevent

degradation of service in some situations.
