Peavey M1 Manuale utente

EElleemmeenntt TTyyppee::

Pressure Gradient Transducer

PPoollaarr PPaatttteerrnn::

Cardioid (unidirectional)

FFrroonntt--ttoo--bbaacckk RReejjeeccttiioonn::

2 dB

RRaatteedd OOuuttppuutt IImmppeeddaannccee::

2 Ohms

RReeccoommmmeennddeedd LLooaadd IImmppeeddaannccee::

1 Ohms

FFrreeqquueennccyy RReessppoonnssee::

3 – 2 , Hz

SSeennssiittiivviittyy::

16 mV/pascal at 1 kHz, 1k Ohm load

SSeellff NNooiissee ((EEqquuiivvaalleenntt SSPPLL))::

18 dB SPL typical, A-weighted

(per IEC 651)

MMaaxxiimmuumm SSPPLL ffoorr ..55%% TTHHDD::

14 dB at 1 kHz

PPoowweerr RReeqquuiirreemmeennttss::

48 Volts

CCuurrrreenntt CCoonnssuummppttiioonn::

2.7 mA

CCoonnnneeccttoorr::

3-pin XLR

PPoollaarriittyy::

Positive pressure on diaphragm

produces positive voltage at pin 2

relative to pin 3

DDiimmeennssiioonnss::

2.28 inches (57.91 mm) maximum

body diameter, 7.8 inches (198.12

mm) long

PPaacckkaaggiinngg::

Compact carrying case

NNeett WWeeiigghhtt::

1.2 pounds (545 grams)

OOppttiioonnaall AAcccceessssoorryy::

Studio Pro Shock Mount

FFeeaattuurreess

• Large gold-plated microphone

diaphragm

• Pressure-gradient transducer

• Switchable low frequency roll-off

• Switchable 1 dB pre-attenuation

• Ideal as main and as support

microphone in most recording

situations

AApppplliiccaattiioonn HHiinnttss

• Announcer’s studio, vocal, and

instrument mic for broadcasting,

dubbing, voice-over

• Overhead

• Spot mic for

- wind instruments

- strings

- piano

- percussion

DDeessccrriippttiioonn

The Studio Pro M1 is a large format

side-address condenser microphone

with a unique frequency and

transient response. Users will

recognize the quality of the

microphone immediately by its

distinctive studio sound. It is an

excellent choice for most

applications in studios, for

broadcasting, film and television.

SPECIFICATIONS Peavey Studio Pro™M1

SPECIFICATIONS Studio Pro™M1

The Studio Pro M1 can be used as a main

microphone for orchestra recordings, as

a spot mic for single instruments, and as

a vocal microphone for all types of music

and speech.

The frequency response of the cardioid

characteristic is very flat for frontal

sound incidence, even in the upper

frequency range. The microphone can be

used very close to a sound source

without the sound becoming unnaturally

harsh. By means of a switchable high-

pass filter, interference through subsonic

and low frequencies are reduced

remarkably. As such, this switch cuts the

low frequency response reducing the

proximity effect.

An additional switch is added for use in

high sound pressure level applications.

This 1 dB attenuation switch enables

the microphone to handle sound

pressure levels up to 14 dB.

OOppeerraattiioonn

Position the microphone so that the side

with the LED and Peavey logo faces the

source. The M1 is equipped with two

switches, one for high SPL applications

and the other for reduction in proximity

effect or to reduce low frequencies that

can make an instrument sound dull or

muddy. The M1 is equipped with a swivel

mount to secure the microphone to a

floor or boom stand. The internal shock

mount provides good isolation, but for

greater reduction of noise from external

vibrations use the optional elastic shock

mount which can be purchased from

your local authorized Peavey dealer.

33 ++ 22 YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY

NNOOTTEE::For details, refer to the

warranty statement. Copies of

this statement may be obtained

by contacting Peavey Electronics

Corporation, P.O. Box 2898, Meridian,

Mississippi 393 1-2898.

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

-20

-10

Amplitude Response

Figure 1. Frequency Response Studio Pro M1 Front to Back

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

-20

-10

Amplitude Response

Figure 2. Frequency Response Studio Pro M1 On-axis and Low cut

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

-20

-10

Amplitude Response

Figure 3. Frequency Response Studio Pro M1 On-axis and -10 dB Pad

SPECIFICATIONS Studio Pro™M1

125 Hz 250 Hz 500 Hz

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

1 kHz 2.5 kHz 5 kHz

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

-90o

-60o

-30o

30o

60o

90o

10 kHz

-90o

-60o

-30o

30o

60o

90o

Features and specifications subject to change without notice.

Peavey Electronics Corporation • 711 A Street • Meridian • MS • 393 1 (6 1) 483-5365 • FAX (6 1) 486-1278 • www.peavey.com
