S P E C I F I C A T I O N S

ARCHITECTURAL ACOUSTICS

™

-8a

MIDI System

Control Interface

ARCHITECTURAL &

ENGINEERING

SPECIFICATIONS

The MIDI system control interface input

shall be a standard 5-pin DIN style jack.

The unit shall have LED indicators to

show Power and preset status. The unit

shall have eight front panel buttons.

The unit shall be packaged in a rugged

metal chassis 19″wide by 1.75″high by

9.625″deep. The unit shall mount in a

standard19″rackrequiring1.75″ofheight.

The unit shall operate from 120 V AC,

60 Hz, domestic; 230 V AC 50/60 Hz,

export. The unit shall be capable of two

operating modes. The unit shall have

EEPROM nonvolatile memory for: MIDI

channel, mode, active buttons and last

preset recalled. The unit shall have

connections for external switches as well

asconnectionsforexternalLEDindicators.

The unit shall be called the Peavey

Architectural Acoustics Division

model SC™-8a.

FEATURES

• Allows Easy Customer recall of MIDI

controlled system configurations

• Two operating modes

• Provides easy user recall of up to eight

systempresetsinsinglechannelmode

• EEPROM nonvolatile memory of MIDI

channel, mode, active buttons and last

preset recalled

• Connections for external switches

• ConnectionsforexternalLEDindicators

DESCRIPTION

TheSC™-8aisaneightbuttonMIDISystem

ControlInterfacethatallowsuserstoeasily

recall different system configurations

storedinprogrammableproductssuchas

the CEX™4La and CEQ™equalizers.

TheSC-8ahastwomodesofoperation.

The eight buttons in the first mode each

recall a different configuration. In the

second mode, each button can control a

separate piece of equipment, or system

segment, and toggle it between two

presets.

The SC-8a has screw terminal

connections for remote switches and

indicators, and a MIDI input for merging

other MIDI data.

SPECIFICATIONS

MIDI

In, Out/Thru

UserInterface

Eight front-panel push buttons/LEDs

PowerSupplyRequirements

Domestic: 12 W, 120 V AC, 60 Hz

Export: 12 W, 230 V AC, 50/60 Hz

Dimensions

Width: 19 inches (48.3 cm)

Height: 1.75 inches (4.4 cm)

Depth: 9.625 inches (24.5 cm)

Weight

Net: 6.6 lbs. (3 kg)

Shipping: 8.7 lbs. (4 kg)

ARCHITECTURAL ACOUSTICS

Features and specifications subject to change without notice.

A Division of Peavey Electronics Corporation

711 A Street / Meridian, MS 39301 / U.S.A. / (601) 483-5376 / Fax 486-1154

LIMITED WARRANTY

Peavey Electronics Corporation warrants to the original purchaser of this new Architectural Acoustics product that it is free from

defectsinmaterial and workmanship. Ifwithinone (1) year from dateofpurchase a properly installed productprovesto be defectiveand

Peaveyisnotified,Peaveywillrepairorreplaceitatnocharge.(Note:Batteriesandpatchcordsnotcovered.)“Originalpurchaser”means

the customer for whom the product is originally installed.

Damage resulting from improper installation, interconnection of a unit or system of another manufacturer, accident or unreasonable

use, neglect or any other cause not arising from defects in material and workmanship is not covered by this warranty. The warranty is

valid only as to products purchased and installed in the United States and Canada.

THIS LIMITED WARRANTY IS IN LIEU OF ANY AND ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE. UNDER NO CIRCUMSTANCES WILL PEAVEY BE

LIABLEFORANYLOSTPROFITS,LOSTSAVINGS,INCIDENTALDAMAGESORCONSEQUENTIALDAMAGESARISINGOUTOFTHEUSE

OR INABILITY TO USE THE PRODUCT, EVEN IF PEAVEY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. THIS LIMITED

WARRANTY IS THE ONLY EXPRESSED WARRANTY ON THIS PRODUCT, AND NO OTHER STATEMENT, REPRESENTATION, WAR-

RANTY, OR AGREEMENT BY ANY PERSON SHALL BE VALID OR BINDING UPON PEAVEY.

Peavey’s liability to the original purchaser for damages for any cause whatsoever and regardless of the form of action is limited to

the actual damages up to the greater of Five Hundred Dollars ($500) or an amount equal to the purchase price of the product that caused

thedamageorthatisthesubjectoforisdirectlyrelatedtothecauseofaction.Thislimitationofliabilitywillnotapplytoclaimsforpersonal

injury or damage to real property or tangible personal property allegedly caused by Peavey’s negligence. For information on service

under this warranty, call a Peavey customer service representative at (601) 483-5376.
