Aus IFM-“QD” Interface Installation Manual December 2018 Version 1.2 RDCCO_2124_E_IN 2
The interface module “QD” works in conjunction with the PM1048, designed to
communicate from the Alarm panel using Serial Data compatible with -
EDM Bosch Solution 16 alarm panel.
DAS: DL100, DL150, DL200, DL250, DL300, 100L, 150L, 208L, 250L, 300L.
Reporting Serial Data from panel to PM1048 interface.
Monitors and reports Serial Data failure.
Monitors and reports status of the alarm panel Serial Data lead.
Various LED status indicators for easy onsite diagnostics.
LED Activity Indication
HB Blinking* When the CPU has completed a power up test and is
working properly
Off Unit is faulty
RX
Blinking * Connectivity between the PM1048 and the IFM “QD”
Off Indicates fault between PM1048 and IFM QD
DATA Blinking * Serial Data transmission
Off No Serial Data transmission
CLOCK Blinking * Indicates Serial Data transmission
Off No Serial Data transmission
HB
RX
DATA
CLOCK
Flashing
together
Indicates that the PM1048 has not been activated
correctly
for use with a IFM - QD module.
* Normal operation
Introduction
Introduction to the
Features
LED Status indicators
Aus
Aus IFM-“QD” Interface Installation Manual December 2018 Version 1.2 RDCCO_2124_E_IN 3
The IFM - QD module is designed to operate with the PM1048 and provides Serial
Data from the PM1048’s RX & TX terminals. The “QD” interface option MUST be
selected on activation otherwise this module will not operate.
Remove jumpers from JP1 and insert the module.
Insert diagram for IFM-QD
-VE
+VE
R1 R T T1
IP
PM1048
Permaconn
JP1
Jumpers in as shipped
Remove the 2 jumpers on
JP1
Plug IFM-QD board
onto sockets
HB
RX
DATA
CLOCK
IFM-QD inserted into PM1048
-VE
+VE
R1 R T T1
IP
PM1048
Permaconn
Jumpers in as shipped
HB
RX
DATA
CLOCK
+
12V
DC
RX
TX
IFM - “QD” interface
IFM-QD status LED’s
Aus
Aus IFM-“QD” Interface Installation Manual December 2018 Version 1.2 RDCCO_2124_E_IN 4
NB: Must have a common –ve between the alarm panel and the PM1048
Bosch Panels: EDM Bosch Solution 16
The alarm panel must be programmed for Securitel communication back to
base.
The four digit account number must be programmed into the alarm panel.
DAS panels:
The panel must be programmed to use Smart Bus Mode (check keypad
compatibility) to ensure detailed events are sent back to the central station.ie to
report user and partition information.
Panels that are not programmed to use Smart Buss mode will report limited
events back to Base. i.e. general closing with no user ID.
The four digit account number must be programmed into the alarm panel.
Trigger an event on the alarm panel. Verify with the monitoring centre that a
tamper was received with the correct CID account number.
INSTALLATION MUST BE CARRIED OUT BY SERVICE PERSONNEL ONLY
Australian Standard AS2201 requires regular service by qualified and licensed
technicians and regular testing.
This product may not perform as expected if not correctly installed.
ANY LIABILITY FOR CONSEQUENTIAL AND INCIDENTAL DAMAGES IS EXPRESSLY
DISCLAIMED. RADIO DATA COMMS AND PERMACONN LIABILITY IN ALL EVENTS IS
LIMITED TO, AND SHALL NOT EXCEED, THE PURCHASE PRICE PAID.
While every effort has been taken to ensure the accuracy of this document, Radio Data Comms assumes no
responsibility or liability for any errors or omissions. Radio Data Comms reserves the right to make changes to
this manual due to ongoing development.
Warning
Liability
Setup of Alarm Panel
Wiring of Alarm Panel to PM1048
Solution Panel 16 PM1048
Output 2 RX
Neg
-
DL & L Panel PM1048
DATA TX
CLK RX
Neg
-
