INSTRUCTION MANUAL
Travel System Stroller
PG8500
To see our full line of products, visit us online at: www.petgearinc.com
CUSTOMER SERVICE HELP DESK
Toll-Free 877-752-9123 - Eastern Standard Time 8am-3pm, Monday through Friday
For The ON-THE-GO Pet™
For Pets
Only
Travel System Stroller PG8500
2
WARNING!
•For pets only.
•Do not carry additional bags, goods, or accessories in or on stroller except as recommended
in the manufacturer's instructions.
•Recommended use of an approved safety restraint correctly fitted and adjusted.
•Do not leave pet unsupervised in stroller.
•Before making adjustments to stroller ensure that pet’s body is clear of any moving parts.
•This stroller is designed for one pet only.
•Do not hang bags from handles as this may cause the product to become unstable.
•Do not use on escalator or stairs; fold stroller and carry.
•Put on brake whenever you park the stroller.
•Ensure stroller is completely erected and check that all locks are engaged before placing pet
in stroller.
•Do not overload as stroller may become unstable; maximum weight of pet using this stroller
should not exceed 15 lbs.
•Any goods carried in the basket not to exceed 6 lbs.
•Do not use near an open or exposed flame.
•To clean and lubricate front and rear wheels, push out locking lever under wheel housing
to release rear wheel.
•To ensure ease of maneuverability and to minimize wear and tear, keep all moving parts
clean and lubricated with WD40® or light machine oil.
•Push wheel sets back on until they click and lock in position;
pull on wheel housings to ensure they are secure.
•Push stroller back and forth and rotate swivels around to work in lubricant.
•Clean the rear wheel assembly and the rest of the frame with warm, soapy water;
clean off with warm water and dry thoroughly.
NOTE: Do not lubricate brake components.
WHEEL MAINTENANCE
For Pets Only. Not intended to be used as a restraining device for
aggressive or dangerous animals that dig, chew or paw aggressively.
Do not leave your pet unattended for long periods of time. Pet Gear is not liable for
any damage caused by aggressive, destructive, immature or untrained animals.
Failure to follow these warnings and the instructions could result in serious injury or death.
For Pets
Up To
15 lbs
3
Travel System Stroller PG8500
PARTS LIST
Check that you have all the parts shown BEFORE assembling your product.
If any parts are missing, call Customer Service.
STROLLER FRAME BACK TRAY
REAR AXLE ASSEMBLIES REAR WHEELS (2)
FRONT WHEEL
ASSEMBLY (2)
RETAINER WASHER RETAINER CAP HUB CAP
TO OPEN STROLLER
TO ASSEMBLE FRONT WHEELS
4Travel System Stroller PG8500
Step 1. Release locking latch.
Step 2. Unfold as shown. Make sure both
locks snap into place.
Step 1. Turn stroller over as shown.
Step 2. Push wheel assembly onto stroller
leg until it snaps into place. Tug firmly on
wheel assembly to be sure that wheel is
securely in place. Repeat for other wheel.
NOTE: To remove, squeeze tab and pull
wheel off.
Note Direction
of Arrow
TO ASSEMBLE REAR WHEELS
5
Travel System Stroller PG8500
Step 1. Remove and discard the protective sleeve
from the ends of the rear axle assembly and the
rear leg tubes.
Step 2. Position the rear axle assemblies onto the
rear leg tubes at the same time.
Step 3. Slide the wheel onto the axle.
Step 4. To Install Retainer Washer: Snap the
retainer washer onto the axle. Make sure that the
larger end of retainer washer is toward the wheel
and the slot in the washer lines up with the rib on
the axle. You may need to twist the washer until it
locks into place. (Figures A, B.)
Step 5. To Install Retainer Cap: Snap the retainer
cap over the retainer washer. (Figure C.)
NOTE: If Retainer Cap does not snap completely
over Retainer Washer, Wheel Assembly is NOT
secure and Wheel may come off.
Step 6. Repeat for other side.
Axel Retainer Washer Retainer Cap
Figure A
Figure B
Figure C
TO ATTACH CARRIER TO FRAME
TO USE IN VEHICLE
TO USE AS CARRIER
6Travel System Stroller PG8500
Attach with Velcro-2 places on each side.
Place seat belt through strap and adjust seat belt.
Attach with clips-2 places on
each side.
(Optional)
Attach accessory holder.
TO OPERATE BRAKES
TO FOLD STROLLER
7
Travel System Stroller PG8500
UNLOCK
LOCK
Step 1. Push levers on both rear wheels down to lock.
Step 2. Pull levers up to unlock.
Step 1. Before folding, Lock brakes and close canopy.
Step 2. Standing behind stroller, pull up on both side latches.
Step 3. Fold as shown.
NOTE: fold stroller so wheels straddle frame.
DO NOT allow wheels to press against frame as this
may damage tires.
Step 4. Engage locking latch.
8Travel System Stroller PG8500
PO Box 99
West Rutland, VT 05777
877-752-9123
www.petgearinc.com
•Always store product in a clean, dry place.
•Not recommended for use on the beach.
•Do not put heavy items on top of the stroller.
•Clean frame by wiping with a lightly oiled cloth.
•Do not use detergent or abrasives. Spot clean fabric with dry cleaning fluid or mild soap
and warm water.
•To ensure easy maneuverability and to minimize wear and tear, (especially wheels, axles,
and swivels), keep all moving parts clean and lubricated with WD40® or light machine oil.
•NOTE: Do not lubricate brake components or swivel locks.
•Regularly check stroller for loose parts. These should be tightened or replaced.
LOOKING AFTER YOUR STROLLER
REPLACEMENT PARTS
Please have your model number ready before calling. Use only Pet Gear replacement parts.
