Mousr User Guide

Version 1.0 [Rev. 6/04/18]

Petronics, Inc.

60 Hazelwood Dr.

Champaign, IL 61820

www.petronics.io

Mousr User Guide i Version 1.0 [Rev. 6/04/18]

IMPORTANT SAFETY INFORMATION

The information contained in this section is intended to highlight important safety, handling, and

usage information for Mousr and other Petronics products. It is not intended to represent a

complete agreement or list of legal rights. For more information, please review our Terms of Use,

INTENDED USE FOR PRODUCTS

PETRONICS DOES NOT INTEND FOR ITS PRODUCTS TO BE USED BY CHILDREN OR

OUTDOORS. PRODUCTS SHOULD BE USED IN THE PRESENCE OF AN ADULT, EVEN

WHEN SET IN THE AUTOMATIC NAVIGATION MODE, AND ONLY WITH DOMESTIC

HOUSE CATS (DUE TO THE BITE STRENGTH OF OTHER ANIMALS). PETRONICS IS

NOT RESPONSIBLE FOR ANY LOSS OR DAMAGE CAUSED BY CHILD OPERATORS,

UNSUPERVISED USE, OUTDOOR USE, OR USE WITH PETS OTHER THAN DOMESTIC

HOUSE CATS, INCLUDING, WITHOUT LIMITATION, DOGS OF ANY SIZE.

LIPO BATTERY WARNING

•Lithium-ion polymer (LiPo) batteries include hazardous materials that can cause serious

injuries to persons, pets, or property if used or disposed improperly. It is important for the

user of any Mousr robot (“User”) to read and follow the instructions below. By using the

Mousr robot, User accepts sole liability for the proper use and disposal of the Mousr robot’s

LiPo battery.

•User should immediately discontinue use of the battery if, while using, charging, or storing

the battery, it emits an unusual smell, feels hot, changes color or shape, or appears otherwise

deformed in any other way.

•In the event of battery leakage or puncture, User should avoid personal or pet contact with the

battery or battery liquid. In case of contact with the skin, thoroughly wash area with soap and

water and consult a doctor or veterinarian. In case of contact with the eyes, rinse thoroughly

with cold water and consult a doctor or veterinarian.

CHARGING

•Never overcharge a LiPo battery. Never “trickle” charge a LiPo battery.

•Do not use a charger with damage to the cord, plug, enclosure, or other parts. Use only the

supplied USB cable plugged into the USB port on your computer or a UL-certified USB wall

charger. Misuse can cause damage to the Mousr robot or cause electrical shock.

•Do not use the Mousr robot’s charger to charge any battery other than the rechargeable battery

provided with the Mousr robot.

•Do not charge the battery near flammable materials.

•Do not leave the Mousr robot unattended during charging.

•Do not charge the Mousr robot immediately after use while the battery is still hot. Allow

battery sufficient time to cool to an ambient temperature before charging.

•Batteries are only to be charged under adult supervision.

•Never store, use, or charge a battery pack inside your in extreme temperatures. Ensure battery

exposure is limited to temperatures between 0ºC - 40ºC (32ºF - 104ºF).

•Do not cover the Mousr robot or its charger while the battery is charging.

Mousr User Guide Version 1.0 [Rev. 6/04/18]ii

USE, MAINTENANCE, AND STORAGE

•Keep pets away from an exposed battery.

•Do not store the Mousr robot or battery in your pet’s crate or bedding.

•Do not use the Mousr robot if its battery cover has been broken or the battery’s casing has

been damaged in any way.

•Do not store the battery inside vehicles.

•Do not expose the battery to excessive physical shock or impact.

•Do not expose the Mousr robot or its battery to a heat source or dispose of it in a fire.

•Do not expose the Mousr robot or its battery to water or salt water, or allow the battery to get

wet.

•Do not put the battery in a microwave oven, inductive cookware, or in a pressurized container.

•Do not attempt to modify, dismantle, pierce, distort, or cut the battery or charger and do not

attempt to repair a damaged battery or charger.

•Do not place any heavy objects on the Mousr robot or its battery.

•Disconnect the charger when you are not charging the battery.

PRODUCT DISPOSAL

At the end of the Mousr robot’s life, do not dispose of the Mousr robot’s LiPo battery with other

household waste. Dispose or recycle the battery separately in accordance with local laws and

regulations. Contact User’s local municipality for disposal or recycling information.

BATTERY DISPOSAL

Damaged or unusable batteries must be properly disposed of. When disposing of the battery,

follow appropriate local guidelines and regulations. For further information, contact User’s local

solid waste authority.!

Mousr User Guide Version 1.0 [Rev. 6/04/18]iii

TABLE OF CONTENTS

IMPORTANT SAFETY INFORMATION II.................................................................................

TABLE OF CONTENTS IV..............................................................................................................

GETTING STARTED 1.....................................................................................................................

Check what’s in the box 1

Download the Mousr app 1

Get to know your Mousr 2

Operating modes 2.........................................................................................................................

Pushbutton functions 2................................................................................................................

LED color and ﬂashing indications 3........................................................................................

Connect your smartphone to Mousr 4

Disconnect and sleep mode 4

CHARGING MOUSR 5....................................................................................................................

Using the charging dock 5

Checking Mousr’s battery level 6

CHANGING TAILS 6........................................................................................................................

UPDATING FIRMWARE 7.............................................................................................................

USING THE MOUSR APP 8...........................................................................................................

Home screen 8

Remote control 8

Getting started 9.............................................................................................................................

Menu 10..............................................................................................................................................

Settings 10.........................................................................................................................................

One-handed mode 11....................................................................................................................

Two-handed mode 11....................................................................................................................

Auto play 12

Getting started 12..........................................................................................................................

Mousr’s brain 13..............................................................................................................................

Auto play parameters 13..............................................................................................................

User assistance 13..........................................................................................................................

DEVICE RECOVERY 13..................................................................................................................

Rebooting Mousr 14

Reloading ﬁrmware 14

TROUBLESHOOTING 15...............................................................................................................

CONTACT US 20...............................................................................................................................

Mousr User Guide Version 1.0 [Rev. 6/04/18]iv

GETTING STARTED

Check what’s in the box

Your package should include one Mousr, its special charging dock home, a Micro-

USB cable, and two tail attachments (colors of the tail attachments may vary from

those in the image below). If you didn’t receive all the items listed please get in

touch with us!

Download the Mousr app

Download our free Mousr companion app by clicking the button below that

matches the operating system on your smartphone.

In order to use the Mousr app, your smartphone must meet the following minimum

technical requirements:

•iOS 8 or later

•Android 4.4 (KitKat) or later

•Hardware support for Bluetooth 4.0 or later and Bluetooth Low Energy

In rare cases, a smartphone device that satisﬁes these minimum requirements

many not work with Mousr, so we cannot guarantee full compatibility will all

smartphones . However, our experience is that these minimum requirements are a

good indicator of compatibility.

Mousr User Guide Version 1.0 [Rev. 6/04/18]1

##############

Get to know your Mousr

The ﬁgures below illustrate important Mousr features that will be referenced

throughout this document.

Operating modes

Listed below are Mousr’s operating modes and short description of each.

Normal operation

Normal operation encompasses all of Mousr’s behaviors and functions under

regular use, including remote control, auto play, and sleep modes.

Charging

Mousr charges inside his supplied charging dock. More detail can be found in the

section titled Charging Mousr.

Updating firmware

Mousr periodically receives free device updates over-the-air when connected to

the Mousr companion app. See the section titled Updating Firmware for more

details.

Device recovery

If something goes wrong with Mousr and it cannot be ﬁxed by putting him into

sleep mode or restarting your smartphone, device recovery mode lets you reboot

Mousr or reinstall a fresh version of Mousr’s ﬁrmware. See the section titled

Device Recovery for more details.

Pushbutton functions

Listed below is the key to pushbutton functions in each of Mousr’s operating

modes:

Mousr User Guide Version 1.0 [Rev. 6/04/18]2

Normal operation

Single click—Flash battery level as follows:

Green—Battery has good charge and can continue to be used

Yellow—Battery is low and will need to be charged soon

Red—Battery is critically low and Mousr needs to be charged (cannot pair)

Double click—Start auto mode with most recent settings

Long click (hold 2 seconds and release)—Enter sleep mode

Click and hold 15+ seconds—Enter device recovery mode

Charging

The pushbutton is non-functional while Mousr is charging.

Updating firmware

The pushbutton is non-functional while Mousr is updating ﬁrmware.

Device recovery mode

Single click—Reboot Mousr into normal operating mode.

LED color and flashing indications

Normal operating mode

When Mousr is in normal operation mode, the LED indicator communicates with

you using different colors and patterns of ﬂashing as described below:

Breathing blue—Connected to phone and in remote control mode

Breathing green—In auto play mode

Breathing / ﬂashing pink

•Auto play—High alert (e.g. caught by cat or stuck on clutter)

•Remote control—Driver assist activated

Slow breathing multiple colors—In need of assistance

Charging

While Mousr is recharging, his LED indicates the battery charge status using the

following colors and ﬂashing patterns:

Flashing red—Low charge

Flashing yellow—Mid charge

Flashing green—Mostly charged

Solid (unﬂashing) green—Fully charged; green light turns off after one minute

Mousr User Guide Version 1.0 [Rev. 6/04/18]3

Updating firmware

During ﬁrmware updates, the LED indicator glows purple with no ﬂashing.

Device recovery mode

When Mousr is in device recovery mode, the LED indicator glows white with no

ﬂashing.

Connect your smartphone to Mousr

After unboxing Mousr, press the pushbutton on his chin and open the Mousr app to

begin the Bluetooth pairing process. After pressing his pushbutton, Mousr’s LED

indicator will blink blue and your Mousr will appear in the device list inside the app.

Tap the icon associated with your device to connect. Once connected, you can

change your robot’s name by clicking the pencil icon on the Mousr info card. Note: if

you have more than one Mousr robot, it is recommended that you pair them one at a time

and give them each a unique name to help distinguish them in the device list. If you use

multiple smart devices to control Mousr, you will need to provide a name for Mousr

separately on each one.

The images below show screenshots of the pairing process. When the app is

opened, it begins searching for nearby Mousr robots. Once found, each robot is

populated in the device list. Tapping a robot’s icon will turn it blue and initiate the

connection process.

Disconnect and sleep mode

There are two main ways to disconnect from Mousr and put him into sleep mode:

•Pushbutton—Press and hold Mousr’s pushbutton for 2 seconds until his LED

ﬂashes white, and then release. Mousr’s LED go dark after it is released.

Mousr User Guide Version 1.0 [Rev. 6/04/18]4

•In the app—Press the blue power icon in the top-right corner of the Mousr info

card.

Note: Mousr will disconnect automatically after being connected for 10 minutes with no

activity.

While in sleep mode, Mousr remains discoverable via bluetooth, so you can

reconnect without using his physical pushbutton. Mousr can hold a charge in sleep

more for about one week.

CHARGING MOUSR

Using the charging dock

Before playing with Mousr for the ﬁrst time, we recommend that you make sure he

is fully charged. To charge Mousr, do the following:

•Plug the supplied Micro-USB cable into the back of Mousr’s charging dock.

•Plug the other end of the cable into the USB!port on your computer or a UL-

certiﬁed USB wall charger.

•Lift the charging dock’s hinged lid

•Place Mousr on the dock’s base so that his wheels are seated inside the rear

indents and his charging pads mate with the metal plates on the base.

•Lower the hinged lid of the charger until it snaps into the base.

The picture below illustrates this procedure.

Mousr User Guide Version 1.0 [Rev. 6/04/18]5

As described previously, the LED indicator will signal the battery charge status in

different colors by blinking during the charging phase and glowing solid green

when the charge is completed. Mousr charges from 0—100% in about 30 minutes.

Once Mousr has been fully charged for one minute, his green LED will shut off.

Checking Mousr’s battery level

When Mousr is not on the charger, you can single click his pushbutton to check his

current battery level on the LED indicator. Alternatively, while connected in the

app, the battery icon shows the percentage of charge remaining, as shown below.

CHANGING TAILS

Petronics makes a variety of interchangeable tail styles and lengths to ﬁt all kinds

of feline play preferences.

Important: When installing or removing a tail attachment, always set Mousr down

on a stable surface. Grip Mousr’s tail base with one hand and the rigid end of the

tail attachment with the other.

How to Install a Tail

While gripping Mousr and the tail as described above, ﬁrmly push the tail

attachment into the slot until you hear it click into place.

How to Remove a Tail

While gripping Mousr and the tail base as described above, pull the rigid end of the

tail attachment directly away from the tail base until the tail attachment pops out.

Mousr User Guide Version 1.0 [Rev. 6/04/18]6

Altri manuali per Mousr

Indice

Altri manuali Petronics Robotica

Petronics

Petronics Mousr Manuale utente

Manuali Robotica popolari di altre marche

STEMCenter USA

STEMCenter USA Pi-Bot v2.00 Manuale utente

SunFounder

SunFounder PiDog Manuale utente

Universal Robots

Universal Robots UR5 Manuale utente

Universal Robots

Universal Robots E Series Manuale utente

YASKAWA

YASKAWA MOTOMAN-MPL80 II Manuale utente

EFORT

EFORT ECR5 Manuale di istruzioni

Epson

Epson C8 Series Manuale utente

WowWee

WowWee ROBOQUAD Manuale utente

Milvus Robotics

Milvus Robotics SEIT 100 Manuale utente

RoboMaster

RoboMaster AI Robot 2020 Standard Version Manuale utente

fischertechnik

fischertechnik Mini Bots Manuale utente

YASKAWA

YASKAWA MA2010 Manuale

Abicor Binzel

Abicor Binzel iCAT mini Manuale utente

ABB

ABB OmniCore E10 Manuale utente

YASKAWA

YASKAWA Motoman DX200 Manuale utente

pitsco

pitsco Tetrix Max Manuale utente

ECOVACS

ECOVACS DEEBOT R95 Manuale utente

Feng Yuan

Feng Yuan Interstellar Warrior Manuale utente
