PEUGEOT Expert Tepee Manuale utente

Handbook

APP_EXPERT_TP_ANGLAIS_CAG_CHAPA_couv1 couv1

05/02/2010 16:28:04

PRESENTATION

Within the chapters symbols draw your attention to specific

information:

This handbook is designed to familiarise you with the new vehicle

from the moment you get behind the wheel and to describe

the operating features.

Reading the handbook is made easy by a content consisting of

10 identified chapters which can be located by means of a colour

code specific to each one. Its sections cover, by theme, all of the

functions of the vehicle in its most complete specification.

PEUGEOT COMMUNICATION

PUTS AN INTERNET SITE AT YOUR DISPOSAL

http://public.servicebox.peugeot.com, select:

- your model,

- the body type: saloon, CC, SW, estate, van…,

- the period corresponding to the date of first registration,

- the "Latest Information" section.

The technical data, equipment and accessories may change during

the year. To obtain this new data, refer to the "Latest Information"

section on the SERVICE BOX Internet site free of charge.

Chapter 8 indicates all of the technical data relating to your

vehicle. At the end of the document, diagrams of the outside

and inside of the vehicle will assist you in locating equipment or

functions and page numbers refer you to the relevant section of

the handbook.

directs you to the chapter and section which contains detailed

information concerning a function,

indicates important information relating to use of the equipment,

alerts you to the safety of individuals and equipment on board.

AP_Expert-TP_02_2009_anglais_cag4 4

05/02/2010 16:20:24

Exterior

FAMILIARISATION

136

Key

: chapter identification

: page identification

Key - Remote control

Complete locking of the vehicle, cab

and rear doors.

Complete unlocking of the vehicle,

cab and rear doors.

Sliding side door

Pull the handle towards you then

towards the rear and open the door

guiding the rearward sliding until the

point of resistance has been passed.

If fitted on your vehicle, do not open the

left-hand side door while filling with fuel

as this could damage the fuel filler flap.

Usable dimensions

Door open warning light

If this comes on, a door has not been

closed correctly.

AP_Expert-TP_02_2009_anglais_cag5 5

05/02/2010 16:20:25

Exterior

Hinged rear doors

This control permits opening to

approximately 180°.

Parking assistance

Rear suspension

Two functions:

- Automatic correction.

- Manual correction. 117

Repairing a wheel

In bad weather or in winter, check

that the sensors are not covered with

mud, ice or snow.

118

Changing a wheel

AP_Expert-TP_02_2009_anglais_cag6 6

05/02/2010 16:20:29

Exterior

FAMILIARISATION

Opening the bonnet

107

Diesel engines Petrol engine

108

133

Towing eye

106

Partially open the bonnet, lift the control and

raise the bonnet. Secure the strut in one of the two notches,

according to the height required, to hold the

bonnet open.

Lift the cover at the foot of the left-hand

seat and pull the control upwards.

At the front, unclip the cover by pressing it

at the bottom.

At the rear, unclip the cover using a coin or

the flat part of the towing eye.

Take care when working under the bonnet.

Refer to the "Levels" section of chapter 6 for advice on use of the fluids.

AP_Expert-TP_02_2009_anglais_cag7 7

05/02/2010 16:20:34

Interior

INSTRUMENTS AND CONTROLS

1. Lights and direction indicators stalk.

2. Instrument panel with display.

3. Wipers, wash-wipe, trip computer

controls.

4. Gear lever.

5. Ignition.

6. Audio equipment controls.

7. Driver's air bag, horn.

8. Steering wheel height and depth

adjustment.

9. Headlamp beam adjustment.

10. Cruise control, speed limiter switch.

11. 12 volt accessories socket

(120 W max) of the lighter type.

12. Ashtray.

13. Glove box, auxiliary socket,

passenger air bag disarming switch.

AP_Expert-TP_02_2009_anglais_cag8 8

05/02/2010 16:20:40

Interior

FAMILIARISATION

CENTRE CONSOLE AND OVERHEAD STORAGE UNIT

1. Location of the controls:

- locking of the electric child lock,

- central locking/unlocking.

2. Heating and/or air conditioning

controls.

3. Location of the ticket/card storage or

controls:

- deactivation of the ESP,

- disarming of the interior protection

alarm, alarm diode,

- deactivation of the parking

assistance.

4. CD changer or storage compartment.

5. Audio equipment or storage

compartment.

6. Central adjustable vents.

7. Hazard warning lights button.

8. Display or storage compartment.

9. Courtesy light.

10. Passenger air bag disarmed warning

light.

11. Location of the ticket/card storage,

rear ventilation deactivation switch,

heated seat controls.

ADJUSTING THE TIME

- a centre console with display: refer

to the "Adjusting the date and time"

section of chapter 9,

- a centre console without display:

refer to the "Instruments and controls"

section of chapter 2.

Depending on the configuration of your

vehicle, you have either:

AP_Expert-TP_02_2009_anglais_cag9 9

05/02/2010 16:20:45

Interior

Driver's seat

SIT COMFORTABLY

1. Forwards-backwards adjustment.

2. Angle.

3. Height.

4. Lumbar.

5. Head restraint height. 60

AP_Expert-TP_02_2009_anglais_cag10 10

05/02/2010 16:20:46

Interior

FAMILIARISATION

Steering wheel Electric windowsMirrors

Seat belts

Adjust the height and depth of the steering

wheel. Manual adjustments.

Electric adjustments, electric folding/

unfolding.

Height adjustment.

Fastening.

AP_Expert-TP_02_2009_anglais_cag11 11

05/02/2010 16:20:51

Interior

SEE CLEARLY

Lights off.

Side lights.

Main beam headlamps (blue).

Dipped headlamps (green).

Wipers stalk

2fast.

1normal.

Iintermittent.

0off.

Èsingle wipe.

AUTO, press the stalk down.

AUTO, automatic switching

on of the lights.

Lights stalk

Changing bulbs

123

In bad weather or in winter, check that

the lights are not covered with mud or snow.

AP_Expert-TP_02_2009_anglais_cag12 12

05/02/2010 16:20:56
