Phase Technologies FL-10 Manuale utente
T E C H N O L O G Y
Serious Bass Response
Serious Subwoofers, Serious Punch
Phase Tech’s all-new high-performance
Power FL subwoofers deliver uncompro-
mised bass output from proprietary 8,
10 and 12 inch high-excursion subwoof-
ers. To maximize output, Phase Tech has
integrated a proprietary butyl rubber sur-
round design that is virtually double the
size of conventional surrounds for
a significant increase in excursion.
Monstrous Woofer, Minimal Distortion
The combination of an oversized sur-
round with an ultra long-throw, mineral-
filled polypropylene woofer and a down-
ward-firing bass radiator delivers serious
bass response and output. To minimize
distortion, this monstrous woofer/sur-
round configuration is attached to a .75”
to 1” MDF baffle and mated to curved
architectural cabinets.
Powered Subs, Dynamic Control
Driving the powered woofers is an
all-new 250 Watt servo-controlled
amplifier that monitors and adjusts
output for dynamic and undistorted
response. Power FL Series subwoof-
ers also include gain control, a phase
switch, variable crossover frequen-
cies, line/level inputs, a separate LFE
inputs and speaker level.
BASS
Power FL-8
8” Powered
high-excursion
subwoofer
Power FL-10
10” Powered
high-excursion
subwoofer
Power FL-12
12” Powered
high-excursion
subwoofer
Integrated amp
T E C H N O L O G Y
P#217-1017
Serious Bass Response
Woofer
Frequency
Amp Power
(Watts, Continuious)
Amp Power
(Watts, Peak)
Dimensions*
Finish
POWER FL-8 POWER FL-10
8” Polypropylene, mineral filled
32 Hz - 150 Hz
250
400
11 1/8” W x 14 5/8” H 16 3/4” D
Black Rosewood Laminate
POWER FL-12
All Phase Tech speakers come with a transferable 10-year factory warranty.
BASS
10” Polypropylene , mineral filled
26 Hz - 150 Hz
250
400
12 1/2” W x 16 3/8” H x 18” D
Black Rosewood Laminate
12” Polypropylene, mineral filled
25 Hz - 150 Hz
250
400
15 1/4” W x 18” H x 20 3/4” D
Black Rosewood Laminate
* Add 1” for for depth connections
