Philips AC2887/31 Manuale utente

G I J L MK ON PH

EN User manual 1 ZH-T 使用手冊 17

4241 210 96242

AC2887

25 2624

1EN

English

Contents

1 Important 2

Safety 2

2 Your air purier 5

Product overview (g.a) 5

Controls overview (g.b) 5

3 Getting started 6

Installing lters 6

4 Using the appliance 6

Understanding the air quality light 6

Switching on and o 6

Changing the Auto mode setting 7

Changing the fan speed 7

Setting the timer 8

Using the light on/o function 8

5 Cleaning 9

Cleaning schedule 9

Cleaning the body of the

appliance 9

Cleaning the air quality sensor 9

Cleaning the pre-lter (g.v) 9

6 Replacing the lter 10

Understanding the healthy air

protect lock 10

Replacing the lter (g.y) 10

7 Troubleshooting 12

8 Guarantee and service 14

Order parts or accessories 14

9 Notices 14

Electromagnetic elds (EMF) 14

Recycling 15

2EN

1 Important

Safety

Read this user manual carefully before

you use the appliance, and save it for

future reference.

Danger

• Do not let water or any

other liquid or flammable

detergent enter the

appliance to avoid electric

shock and/or a fire

hazard.

• Do not clean the

appliance with water,

any other liquid, or a

(flammable) detergent to

avoid electric shock and/

or a fire hazard.

• Do not spray any

flammable materials

such as insecticides or

fragrance around the

appliance.

Warning

• Check if the voltage

indicated on the

appliance corresponds to

the local power voltage

before you connect the

appliance.

• If the power cord is

damaged, you must have

it replaced by Philips, a

service center authorized

by Philips, or similarly

qualified persons in order

to avoid a hazard.

• Do not use the appliance

if the plug, the power

cord, or the appliance

itself is damaged.

• This appliance can be

used by children aged

from 8 years and above

and persons with reduced

physical, sensory or

mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and understand the

hazards involved. Child

shall not play with the

appliance. Cleaning and

maintenance shall not be

made by children without

supervision.

• Do not block the air inlet

and outlet, e.g. by placing

items on the air outlet or

in front of the air inlet.

3EN

English

• Make sure that foreign

objects do not fall into the

appliance through the air

outlet.

Caution

• This appliance is not

a substitute for proper

ventilation, regular

vacuum cleaning, or use

of an extractor hood or

fan while cooking.

• If the power socket used

to power the appliance

has poor connections,

the plug of the appliance

becomes hot. Make

sure that you plug the

appliance into a properly

connected power socket.

• Always place and use the

appliance on a dry, stable,

level, and horizontal

surface.

• Leave at least 20cm free

space behind and on both

sides of the appliance

and leave at least 30cm

free space above the

appliance.

• Do not place anything on

top of the appliance.

• Do not sit or stand on

the appliance. Sitting or

standing on the appliance

may lead to potential

injuiry.

• Do not place the

appliance directly below

an air conditioner to

prevent condensation

from dripping onto the

appliance.

• Make sure all filters

are properly installed

before you switch on the

appliance.

• Only use the original

Philips filters specially

intended for this

appliance. Do not use any

other filters.

• Combustion of the filter

may cause inreversible

human hazard and/or

jeopardize other lives. Do

not use the filter as fuel or

for similar purpose.

• Avoid knocking against

the appliance (the air inlet

and outlet in particular)

with hard objects.

• Always lift or move the

appliance by the handle

on back side of the

appliance.

4EN

such as TVs, radios, and

radio-controlled clocks.

• The appliance is only

intended for household

use under normal

operating conditions.

• Do not use the appliance

in wet surroundings or in

surroundings with high

ambient temperatures,

such as the bathroom,

toilet, or kitchen.

• The appliance does

not remove carbon

monoxide (CO) or radon

(Rn). It cannot be used

as a safety device in

case of accidents with

combustion processes

and hazardous chemicals.

• If you need to move the

appliance, disconnect the

appliance from the power

supply first.

• Do not move the

appliance by pulling its

power cord.

• Always cleanse your

hands after changing the

filters.

• Do not insert your fingers

or objects into the air

outlet or the air inlet to

prevent physical injury

or malfunctioning of the

appliance.

• Do not use this appliance

when you have used

indoor smoke-type insect

repellents or in places

with oily residues, burning

incense, or chemical

fumes.

• Do not use the appliance

near gas appliances,

heating devices or

fireplaces.

• Always unplug the

appliance after use

and before cleaning,

or carrying out other

maintenance or replacing

the filters.

• Do not use the appliance

in a room with major

temperature changes,

as this may cause

condensation inside the

appliance.

• To prevent interference,

place the appliance at

least 2 meters away from

electrical appliances that

use airborne radio waves

5EN

English

Controls overview (g.b)

GOn/Off button

HLight dimming button

IAuto mode button

JDisplay screen

KPollution mode icon

LAllergen mode icon

MBacteria&Virus mode icon

NFan speed button

OTimer button

PReset button

2 Your air purifier

Congratulations on your purchase, and

welcome to Philips!

To fully benefit from the support that

Philips offers, register your product at

www.philips.com/welcome.

Product overview (g.a)

AControl panel

BAir quality light

CAir quality sensors

DNanoProtect Pro S2 (FY2428)*

EPre-filter

FFront panel

* Hereinafter referred to as air

purification filter

6EN

4 Using the

appliance

Understanding the air

quality light

Air quality light

color

Air quality level

Blue Good

Blue-violet Fair

Red-purple Unhealthy

Red Very unhealthy

The air quality light automatically goes

on when the appliance is switched on,

and lights up all colors in sequence.

In a short time the air quality sensors

select the color that corresponds to the

ambient air quality.

Switching on and o

1 Put the plug of the appliance in the

power socket.

2 Touch to switch on the appliance

(fig.i).

»The appliance beeps.

»The appliance operates under

the pollution mode by default.

»After measuring the air quality

for a short time, the air quality

sensor automatically selects the

color of the air quality light.

»" " displays on the screen

when the appliance is warming

up. After measuring the particle

matters in the air, the appliance

goes to auto mode with

displayed on the screen

(fig. j).

3 Getting started

Installing lters

Note

• Make sure that the appliance is

unplugged before installing the filters.

Before using the appliance, remove all

packaging materials of the filters and

place the filters into the appliance as

described as follows.

Note

• Make sure that the side with the tag is

pointing towards you.

1 Remove all packaging materials of

the air purification filters (fig.c).

2 Pull the bottom part of the front

panel to remove it from the

appliance (fig.d).

3 Press the two clips down and pull

the pre-filter towards you (fig.e).

4 Put the unpacked air purification

filters back into the appliance

(fig.f).

5 Put the pre-filter back into the

appliance (fig.g).

Note

• Make sure that the side with the two

clips is pointing towards you, and that

all hooks of the pre-filter are properly

attached to the purifier.

6 To reattach the front panel, mount

the panel onto the top of the

appliance first (1). Then, gently push

the panel against the body of the

appliance (2) (fig.h).

7EN

English

3 Touch and hold for 3 seconds to

switch off the appliance.

Note

• After the appliance is switched off by

the on/off button , if the plug is still

in the power socket, the appliance will

operate under the previous settings

when it is switched on again.

Changing the Auto mode

setting

You can choose the Pollution mode

( ), the Allergen mode ( ) and the

Bacteria&Virus mode ( ).

Pollution mode

The specially designed pollution

mode can effectively remove airborne

pollutants such as PM2.5.

• Touch the Auto mode button to

select the Pollution mode (fig.k).

»Auto (A) and display on the

screen.

Allergen mode

The specially designed allergen mode

can effectively remove common

allergens such as pollen and pet

dander.

• Touch the Auto mode button to

select the Allergen mode (fig.l).

»Auto (A) and display on the

screen.

Bacteria&Virus mode

The specially designed bacteria&virus

mode can effectively remove bacteria

& viruses such as staphylococcus albsp

and H1N1.

• Touch the Auto mode button

to select the Bacteria&Virus mode

(fig.m).

»Auto (A) and display on the

screen.

Changing the fan speed

There are several fan speeds available.

You can choose the sleep mode (SL),

speed 1, 2, 3 or turbo mode (t).

Sleep (SL)

In sleep mode, the appliance operates

quietly under very low speed.

• Touch the fan speed button to

select the sleep mode (SL) (fig.n).

Note

• In sleep mode, "SL" displays on the

screen for one minute. After that,all the

lights will go off and the display screen

will be dimmed with " " displayed.

• You can turn on the lights manually by

touching .

Manual

• Touch the fan speed button

repeatedly to select the fan speed

you need (fig.p).

Turbo (t)

In turbo mode, the appliance operates

under the highest speed.

• Touch the fan speed button to

select the turbo mode (t) (fig.o).

8EN

Setting the timer

With the timer, you can let the

appliance operate for a set number of

hours. When the set time has elapsed,

the appliance will automatically switch

off.

• Touch the timer button

repeatedly to choose the number

of hours you want the appliance to

operate (fig.q).

»The timer is available from 1 to

12 hours.

To deactivate the timer, touch the

timer button repeatedly until "---"

displays on the screen.

Note

• If you have set the timer once, next

time when you use the timer, it starts

from the previous setting time.

Using the light on/o

function

With the light dimming button, you can

switch on or off the air quality light,

the display screen and the function

indicators if needed.

1 Touch the light dimming button

once, the air quality light will be

dimmed.

2 Touch the light dimming button

again, the air quality light will go off.

The display screen and the function

indicators will still be on, but the

lights will be dimmed with " "

displayed on the screen.

3 Touch the light dimming button

for the third time, all lights will be on

again.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Philips Purificatore d'aria

Philips

Philips AC3033 Manuale utente

Philips

Philips AC2885/40 Manuale utente

Philips

Philips AC2887 Manuale utente

Philips

Philips MicroCube AC5659 Manuale utente

Philips

Philips AC0820/10 Manuale utente

Philips

Philips AC4055 Manuale utente

Philips

Philips AC1213 Manuale utente

Philips

Philips AC4072 Manuale utente

Philips

Philips Air Performer 8000i Series Manuale utente

Philips

Philips AC4012 Manuale utente

Philips

Philips AC4012 Manuale utente

Philips

Philips 600i Series Manuale utente

Philips

Philips HR4335/00 Manuale utente

Philips

Philips AC3737 Manuale utente

Philips

Philips AC4558 Manuale utente

Philips

Philips AC4004 Manuale utente

Philips

Philips AC2889 Manuale utente

Philips

Philips AC4012 Manuale utente

Philips

Philips 4222.002.7127.1 Manuale utente

Philips

Philips UVCA110 Manuale tecnico

Philips

Philips AurAir Manuale utente

Philips

Philips 3000i Series Manuale utente

Philips

Philips AC2889/90 Manuale utente

Philips

Philips AC4012 Manuale utente

Manuali Purificatore d'aria popolari di altre marche

IKEA

IKEA UPPÅTVIND Manuale utente

Nash

Nash AP-1 PureSmart Manuale utente

LG PH-U450 Series Manuale utente

DeLonghi

DeLonghi DDSX 220WFA Manuale utente

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuale utente

Sharp

Sharp FU-40SE Manuale utente

Hitachi

Hitachi EP-A3000 Manuale utente

TruSens

TruSens Z-2000 Manuale utente

Motorola

Motorola MBP87SN Manuale utente

Beko

Beko ATP 7100I Manuale utente

Carrier

Carrier INFINITY 1620 Manuale utente

AtmosAir

AtmosAir P2002 Manuale utente

Winix

Winix NK300 Manuale utente

Friedrich

Friedrich C-90A Istruzioni per l'uso e l'installazione

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuale utente

Base aire

Base aire 555 Pro Manuale utente

Champion

Champion CP25 Manuale utente

vollara

vollara Air & Surface Pro+ Manuale utente
