Philips AZ 9202/11 Manuale utente

Shockproof CD Player AZ9001

AZ9002

AZ9003

AZ9011

AZ9201

AZ9202

AZ9203

AZ9211

Es necesario que lea cuidadosamente su instructivo de manejo.

Descripción: Tocadiscos de CD portatil

Modelo: AZ 9001/01, /11, /16, AZ 9002/01, /11, /16,

AZ 9003/01, /11, /16, AZ 9011/01, /11, /16,

AZ 9201/01, /11, /16, AZ 9202/01, /11, /16,

AZ 9203/01, /11, /16, AZ 9211/01, /11, /16

Alimentación: 110–127/220–240 V~ 50–60 Hz

Consumo: 4 W (AY 3170)

Importador: Philips Mexicana, S.A. de C.V.

Domicilio: Norte 45, # 669, Col. Industrial Vallejo

Localidad y Telefono: C.P. 02300 México D.F., Tel. 7284200

Exportador: Philips Hong Kong, Ltd.

País de Origen: China

Nº de Serie: ______________________________

LEA CUIDADOSAMENTE ESTE INSTRUCTIVO

ANTES DE USAR SU APARATO.

No abrir, riesgo de choque eléctrico

Verifique que el voltaje de alimentación

sea el requerido para su aparato

ATENCIÓN

Para evitar el riesgo de choque eléctrico, no quite la tapa.

En caso de requerir servicio, dirijase al personal calificado.

PRECAUCIÓN - ADVERTENCIA

México

ESP

OPEN

•R

•H

PROGRAM MODE

DIGITAL DBB

LIN

English

Controls .................................................6

Quick start .............................................7

Power supply...................................8–10

Headphones.........................................10

General information ............................11

CD play..........................................12–13

Features.........................................14–18

In-car connection.................................19

Troubleshooting.............................20–21

Français

Commandes.........................................22

Mise en service rapide........................23

Alimentation électrique ................24–26

Ecouteurs.............................................26

Informations générales .......................27

Lecture CD.....................................28–29

Caractéristiques ............................30–34

Raccordement en voiture ....................35

Pannes et remèdes .......................36–37

Español

Controles .............................................38

Encendido rápido.................................39

Alimentación eléctrica..................40–42

Auriculares ..........................................42

Información general ............................43

Reproducción de un CD.................44–45

Características ..............................46–50

Conexión al automóvil.........................51

Localización de averías.................52–53

Guarantees

Polizia de garantía

Mexico.........................................70–71

Philips product warranty for

Australia......................................72–73

Guarantee and service for

New Zealand ....................................74

∑FrançaisEspañol

CONTROLS, refer to the illustration on page 3

19.....................stops CD play, clears a program or switches the player off

2DIGITAL DBB ...DIGITAL DYNAMIC BASS BOOST switches the bass enhancement

on and off

3§....................skips and searches CD tracks forwards

42;...................switches the player on, starts or pauses CD play

5........................display

6∞....................skips and searches CD tracks backwards

7PROGRAM.......programs tracks and reviews the program

8MODE..............selects the different playing possibilities: SHUFFLE,

SHUFFLE REPEAT ALL, REPEAT, REPEAT ALL and SCAN

9RESUME..........stores the last position of a CD track played

HOLD..............locks all buttons

OFF ..................switches RESUME and HOLD off

0LINE OUT/p....3.5 mm headphone socket, socket to connect the player to another

analogue audio input of an additional appliance, remote control

socket (not on all versions)

!VOL E.........adjusts the volume

@OPEN 2...........opens the CD lid

#4.5V DC...........socket for external power supply

$........................typeplate

%ESP..................ELECTRONIC SKIP PROTECTION ensures continuous CD playback

regardless of vibrations and shocks

English

This set complies with the radio interference requirements of the

European Community.

English

OPEN

•R

•H

ESP

PROGRAMMODE

DIGITALDBB

OPEN

•R

•H

ESP

PROGRAMMODE

DIGITALDBB

OPEN

1OPEN 2

3CD 4 5

HOLD➟OFF

6PLAY 7VOLUME

!!!

OPEN

•R

•H

LIN

ESP

PROGRAM MODE

DIGITALDBB

LR6

UM3

OPEN

•R

•H

•R

•H

PROGRAMMODE

ESP

PROGRAM MODE

DIGITAL DBB

2. 2.

OPEN

•R

•H

LIN

ESP

PROGRAMMODE

DIGITALDBB

LIN

QUICK START

English

POWER SUPPLY

With this player you can use either:

• normal batteries type LR6, UM3 or AA (preferably Philips), or

• alkaline batteries type LR6, UM3 or AA (preferably Philips).

Notes: – Old and new or different types of batteries

should not be used in combination.

– Remove batteries if they are empty or if the

player is not going to be used for a long time.

Inserting batteries

1Push OPEN 2to open the CD lid.

2Open the battery compartment and insert either

2 normal or alkaline batteries.

Battery indication

The battery symbol on the display is divided into

3 sections which indicate the approximate power

capacity of the batteries.

• If Ais flashing and bAtt is displayed, the

batteries are empty.

Average playing time of batteries under normal conditions

Battery type ESP on ESP off

Normal 7 hours 6 hours

Alkaline 20 hours 18 hours

ECO-PLUS NiMH batteries (not on all versions) 10 hours 9 hours

Batteries contain chemical substances, so they should be disposed of

properly.

Batteries (supplied or optionally available)

POWER SUPPLY

Recharging works only on players with supplied rechargeable

ECO-PLUS NiMH batteries AY 3362.

Recharging the ECO-PLUS NiMH batteries on board

1Make sure you insert the rechargeable ECO-PLUS NiMH

batteries AY 3362.

2Connect the mains adapter to the 4.5V DC socket of

the player and to the wall socket.

yAfilled with 0–3 sections (depending on the

level of charge) is shown and ChArGE is

displayed.

• Recharging stops when you start playback or when

approximately 7 hours have passed by.

3When the batteries are fully recharged, is

shown and FULL is displayed.

Notes: – It is normal for the batteries to become warm

during recharging.

– If the batteries become too warm, recharging will be interrupted for

approximately 30 minutes and Hot is displayed.

– To ensure proper recharging on board, take care that contacts are clean, and

you are using only the ECO-PLUS NiMH batteries AY 3362.

Rechargeable ECO-PLUS NiMH battery handling

• Recharging already charged or half-charged batteries will shorten their lifetime.

Therefore, after using the rechargeable ECO-PLUS NiMH batteries a few times,

discharge them completely before recharging.

• To avoid a short circuit, the batteries should not touch any metal objects.

• When the batteries quickly become empty after recharging, the contacts are dirty

or the end of their lifetime has been reached.

ECO-PLUS NiMH battery information (for versions supplied with

rechargeable ECO-PLUS NiMH batteries AY 3362 only)

English

POWER SUPPLY/HEADPHONES

Use only the AY 3170 adapter (4.5 V/300 mA direct

current, positive pole to the centre pin). Any other

product may damage the player.

1Make sure that the local voltage corresponds to the

mains adapter´s voltage.

2Connect the mains adapter to the 4.5V DC socket

of the player and to the wall socket.

Note: Always disconnect the adapter when you are not using it.

• Connect the supplied headphones to the LINE OUT/p

socket.

Note: LINE OUT/pcan also be used for connecting your

HiFi system (signal lead) or your car radio (cassette

adapter or signal lead). In both cases, the volume

of the player must be set to position 8.

LIN

Headphones AY 3677

Mains adapter (supplied or optionally available)

English

Use your head when using headphones

Hearing safety: Do not play your headphones at a high volume. Hearing experts

advise that continuous use at high volume can permanently damage your hearing.

Traffic safety: Do not use headphones while driving a vehicle. It may create a hazard

and it is illegal in many countries. Even if your headphones are an open-air type

designed to let you hear outside sounds, do not turn up the volume so high that you

cannot hear what is going on around you.
