Philips AZT9240/05 Manuale utente

Portable CD Player AZT9240

CLOCK

RADIO•BAND

PROGRAM

SET•

•MODE

DIGITAL DBB

DIGITAL AUDIO

COMPACT

DBB

FM ST PERSET MIN

ESP

DIGITAL DYNAMIC BASS BOOST

DBB

FM ST PERSET MIN

AZT9240/00 deu 3/1/01 12:51 Page 1

OPEN

•R

•H

ESP

PROGRAM

CLOCK

RADIO·BAND

DIGITAL DBB

(

SET·

·MODE

AZT9240/00 deu 3/1/01 12:52 Page 3

CONTROLS, refer to the illustration on page 3

1DIGITAL DBB...DIGITAL DYNAMIC BASS BOOST switches the bass enhancement

on and off

22;...................switches the player on, starts or pauses CD play

39.....................stops CD play, clears a CD program or switches the player off

4§....................skips and searches CD tracks forwards, selects the next preset

radio station

∞....................skips and searches CD tracks backwards, selects the previous

preset radio station

5·MODE.............selects the different playing possibilities: SHUFFLE,

SHUFFLE REPEAT ALL, REPEAT, REPEAT ALL and SCAN

6........................display

73.....................tunes to radio stations upwards, sets the time upwards

4.....................tunes to radio stations downwards, sets the time downwards

8SET·.................activates/confirms the current time setting, activates/confirms the

alarm time setting

9CLOCK .............switches to clock or alarm clock display

0PROGRAM.......programs CD tracks and radio stations, reviews the program

!RADIO·BAND...switches the radio on, selects a waveband

@RESUME..........stores the last position of a CD track played

HOLD..............locks all buttons

OFF ..................switches RESUME and HOLD off

#LINE OUT/p....3.5 mm headphone socket, socket to connect the player to another

analogue audio input of an additional appliance, remote control socket

$VOL E.........adjusts the volume

%OPEN 2...........opens the CD lid

^4.5V DC...........socket for external power supply

&........................belt clip holder

*........................typeplate

(ESP..................ELECTRONIC SKIP PROTECTION ensures continuous CD playback

regardless of vibrations and shocks, switches the alarm function on

and off

English

AZT9240/01 eng 23/2/01 17:28 Page 6

English

ESP

PROGRAM

CLOCK

RADIO ·BAND

DIGITAL DBB

OPEN

•R

•H

ESP

PROGRAM

CLOCK

RADIO·BAND

DIGITAL DBB

OPEN

•R

•H

ESP

PROGRAM

CLOCK

RADIOBAND

DIGITALDBB

OPEN

•R

•H

ESP

PROGRAM

CLOCK

RADIO·BAND

DIGITALDBB

OPEN

1OPEN 2

3CD 4 5

HOLD➟OFF

6PLAY 7VOLUME

!!!

LR6

UM3

OPEN

•R

•H

OUT

PROGRAM

RADIO·BAND

•R

•H

PROGRAM

CLOCK

RADIO·BAND

ESP

DIGITAL DBB

OPEN

•R

•H

ESP

PROGRAM

CLOCK

RADIOBAND

DIGITALDBB

8RADIO / BAND

ESP

PROGRAM

RADIO BAND

DIGITAL DBB

9TUNING

RADIO·BAN

SET·

·MODE

QUICK START

AZT9240/01 eng 23/2/01 17:28 Page 7

English

POWER SUPPLY

With this player you can use either:

• normal batteries type LR6, UM3 or AA (preferably Philips), or

• alkaline batteries type LR6, UM3 or AA (preferably Philips).

Notes: – Old and new or different types of batteries

should not be used in combination.

– Remove batteries if they are empty or if the

player is not going to be used for a long time.

Inserting batteries

1Push OPEN 2to open the CD lid.

2Open the battery compartment and insert either

2 normal or alkaline batteries.

Battery indication

The approximate power level of your batteries is shown

in the display.

Battery full

Battery two-thirds full

Battery one-third full

Battery dead or empty. When the batteries are

dead or empty, the symbol A flashes,

bAtt is displayed, and the beep tone sounds repeatedly.

Average playing time of batteries under normal conditions

Battery type ESP on ESP off

Normal 7 hours 6 hours

Alkaline 22 hours 19 hours

ECO-PLUS NiMH batteries (not on all versions) 10 hours 9 hours

Batteries contain chemical substances, so they should be disposed of

properly.

Batteries (supplied or optionally available)

AZT9240/01 eng 23/2/01 17:28 Page 8

POWER SUPPLY

Recharging works only on players with supplied rechargeable

ECO-PLUS NiMH batteries AY 3362.

Recharging the ECO-PLUS NiMH batteries on board

1Make sure you insert the rechargeable ECO-PLUS NiMH

batteries AY 3362.

2Connect the mains adapter to the 4.5V DC socket of

the player and then to the wall socket.

yAis shown and ChArGE is displayed for 5

seconds.

• Recharging stops after a maximum of 7 hours, or

when you start playback.

3When the batteries are fully recharged, and

FULL appear briefly in the display, before the

display switches off.

Notes: – It is normal for the batteries to become warm

during recharging.

– If the batteries become too warm, recharging will be interrupted for

approximately 30 minutes and

Hot

is displayed.

– To ensure proper recharging on board, take care that contacts are clean, and

you are using only the ECO-PLUS NiMH batteries AY 3362.

Rechargeable ECO-PLUS NiMH battery handling

• Recharging already charged or half-charged batteries will shorten their lifetime.

Therefore, after using the rechargeable ECO-PLUS NiMH batteries a few times,

discharge them completely before recharging.

• To avoid a short circuit, the batteries should not touch any metal objects.

• When the batteries quickly become empty after recharging, the contacts are dirty

or the end of their lifetime has been reached.

ECO-PLUS NiMH battery information (for versions supplied with

rechargeable ECO-PLUS NiMH batteries AY 3362 only)

English

AZT9240/01 eng 23/2/01 17:28 Page 9

POWER SUPPLY/HEADPHONES

Use only the AYT 3170 adapter (4.5 V/300 mA direct

current, positive pole to the centre pin). Any other

product may damage the player.

1Make sure that the local voltage corresponds to the

mains adapter´s voltage.

2Connect the mains adapter to the 4.5V DC socket

of the player and to the wall socket.

Note: Always disconnect the adapter when you are not using it.

1To attach the belt clip to the CD-player, position the

shaped grip (found on the back of the belt clip) so that

it fits into the belt clip hole of the CD-player.

2Turn the clip to LOCK as indicated on the set.

3To detach, gently lift the belt clip and turn

to RELEASE as indicated on the set.

• All redundant packing material has been omitted. We have done our utmost to

make the packaging easily separable into two mono materials: cardboard (box) and

polyethylene (bags, protective foam sheet).

• Your set consists of materials which can be recycled if disassembled by a

specialized company. Please observe the local regulations regarding the disposal of

packing materials, exhausted batteries and old equipment.

Environmental information

LIFT LOCK

RELEASE

BELT CLIP

Belt Clip (not on all versions)

4.5

VDC

Mains adapter (supplied or optionally available)

English

AZT9240/01 eng 23/2/01 17:28 Page 10

GENERAL INFORMATION

• Do not touch the lens Aof the CD player.

• Do not expose the set, batteries or CDs to humidity,

rain, sand or excessive heat (caused by heating

equipment or direct sunlight).

• You can clean the CD player with a soft, slightly

dampened, lint-free cloth. Do not use any cleaning

agents as they may have a corrosive effect.

• To clean the CD, wipe it in a straight line from the

centre towards the edge using a soft, lint-free cloth. A cleaning agent may damage

the disc! Never write on a CD or attach a sticker to it.

• The lens may cloud over when the set is moved suddenly from cold to warm

surroundings. Playing a CD is not possible then. Leave the CD player in a warm

environment until the moisture has evaporated.

• Active mobile phones in the vicinity of the CD player may cause malfunctions.

• Avoid dropping the set as this may cause damage.

• Connect the supplied headphones to the LINE OUT/p

socket.

Note:

LINE OUT/p

can also be used for connecting the

player to your HiFi system (with a signal lead) or to

your car radio (with a cassette adapter or signal

lead). In both cases, the volume of the player must

be set to position 8.

LIN

Headphones HE 545 (or HL 350)

CD player and CD handling

English

Use your head when using headphones

Hearing safety: Do not play your headphones at a high volume. Hearing experts

advise that continuous use at high volume can permanently damage your hearing.

Traffic safety: Do not use headphones while driving a vehicle. It may create a hazard

and it is illegal in many countries. Even if your headphones are an open-air type

designed to let you hear outside sounds, do not turn up the volume so high that you

cannot hear what is going on around you.

AZT9240/01 eng 23/2/01 17:28 Page 11

CD PLAY

This CD player can play all kinds of Audio Discs such

as CD-Recordables and CD-Rewritables. Do not try to

play a CD-ROM, CDi, VCD, DVD or computer CD.

1Push the OPEN 2slider.

yThe lid opens.

2Insert an audio CD, printed side up, by pressing

gently on the CD centre so that it fits onto the hub.

Close the lid by pressing it down.

3Press 2; to switch the player on and start playback.

yThe current track number and elapsed playing

time are displayed.

• You can pause playback by pressing 2;.

yThe time where playback was paused is flashing.

• Continue playback by pressing 2; again.

4Press 9 to stop playback.

yThe total number of tracks and the total playing

time of the CD are displayed.

5Press 9 again to switch the player off.

• To remove the CD, hold it by its edge and press the

hub gently while lifting the CD.

Note: If there is no activity, the set will automatically

switch off after a while to save energy.

ESP

DIGITAL DBB

·MODE

OPEN

Playing a CD

English

AZT9240/01 eng 23/2/01 17:28 Page 12

CD PLAY

• If a recordable CD (CD-R) or a rewritable CD (CD-RW) is not recorded

properly, nF dISC is displayed. In that case use FINALIZE on your

CD recorder to complete the recording.

• If you want to play a rewritable CD (CD-RW), it takes 3–15 seconds for

sound reproduction to start once you have pressed 2;.

• Playback will stop if you open the CD lid.

• While the CD is read, 1 -:- is displayed.

Volume adjustment

• Adjust the volume by using VOL E.

Bass adjustment

You can choose between the bass enhancement levels

dbb1 and dbb2.

1Press DIGITAL DBB as often as necessary to select

the desired bass intensity.

ydbb1 or dbb2 is displayed for 2 seconds and

is shown.

2To switch dbb1 or dbb2 off, press DIGITAL DBB

repeatedly.

ygoes off.

DIGITAL DBB

Volume and bass

Playback information

English

This set complies with the radio interference requirements of the

European Community.

AZT9240/01 eng 23/2/01 17:28 Page 13

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Philips Lettore CD

Philips

Philips Soundmachine AZ3831 Manuale utente

Philips

Philips Soundmachine AZ382/12 Manuale utente

Philips

Philips CDI 220 Manuale del proprietario

Philips

Philips AZ1550/05 Manuale utente

Philips

Philips CD6660/00 Manuale utente

Philips

Philips MPC270 Manuale utente

Philips

Philips SACD900A Manuale utente

Philips

Philips AZ1316 Manuale utente

Philips

Philips AZ1834/55 Manuale utente

Philips

Philips FW 25 Manuale utente

Philips

Philips AZT3202/17 Manuale utente

Philips

Philips AZ6831 - Cd Portable Manuale utente

Philips

Philips AZ1840/12 Manuale operativo

Philips

Philips EXPANIUM EXP2565/02 Manuale utente

Philips

Philips AZ302/05 Manuale utente

Philips

Philips ACT7580 Manuale utente

Philips

Philips AZ320 Manuale utente

Philips

Philips EXP7361 Manuale utente

Philips

Philips AX2400 Manuale utente

Philips

Philips Soundmachine AZB500/79 Manuale utente

Philips

Philips AZ 8060 Manuale utente

Philips

Philips AZ7166 - Cd Portable Manuale utente

Philips

Philips Jogproof AX5101 Manuale utente

Philips

Philips MCS235 Manuale utente

Manuali Lettore CD popolari di altre marche

RCA

RCA RP-7923 Manuale utente

Pioneer

Pioneer DEH-P3550MP XM Manuale utente

Lasonic

Lasonic MSU-2020 Manuale utente

THOMSON

THOMSON RCD150 Manuale utente

Denon

Denon DCD-1420 Manuale utente

Panasonic

Panasonic SJ-MR100 Manuale utente

Onkyo

Onkyo DX-7210 Manuale utente

Sony

Sony MZ-R3 Manuale utente

Denon

Denon DVM-4800 Manuale utente

JBL

JBL MR-32 Manuale utente

RCA

RCA RCD152 Manuale utente

Technics

Technics SL-PS770A Manuale utente

Clarion

Clarion compact disc Manuale utente

Sony

Sony MZ-M10 Manuale utente

Rotel

Rotel RCD 975 Manuale utente

Pioneer

Pioneer CLD-D790 Manuale utente

Optimus

Optimus CD-8250 Manuale utente

Audiovox

Audiovox CE101A - annexe 1 Manuale utente
