Philips AZALIS 238 Manuale utente

Division of Philips France

Printed in France

Memory Jogger Card

Switch on/off: Long press

Enter PIN: 1. Enter PIN code on keypad

2. Press to confirm.

Make a call: 1. Enter phone number on keypad

2. Press to dial

Answer a call: Press

End a call: Press

Use Names List: 1. Press to access

2. Press to select name

3. Press to dial

Enter a Name: Select <New> from the Names list

Access and tour the menu: 1. Press

2. Press to select a menu

3. Press to confirm

4. Press to select a sub-

5. Press to confirm

Return to previous menu: Press

Return to idle screen: Press

Visit our site and register on line @ http://www.pcc.philips.com

Service numbers

Messages Send SMS

Mailboxes

Read SMS

Settings

Security

Main

PHILIPS

* Subscription dependent.

Broadcast SMS

Display

Time and Date

Hotkeys

Call settings

Names

Call list

Extras

Access settings

Settings

Help

Sounds

SMS settings

Oper. services*

Voice command

Launch

Network Services

WAP Last page

Favourites

Table of contents

Introduction 3

Symbols used in this guide 3

Before your first

call 4

The SIM card 4

PIN and PUK codes 4

Insert the SIM card 5

The battery 6

Insert the battery 6

Attach the battery cover 6

Remove the battery 7

Charge the battery 7

Discover your

Phone 8

Screen 9

Phone Functions 10

Switch on/off 10

Idle Screen 10

Make a call 10

Answer a call 11

End a call 12

Emergency call 12

Text Entry 12

The Carousel 15

Main Menus 15

Names 16

<New> 16

Send SMS 17

Voice Dial 17

Change or Delete 17

Messages 18

Send SMS or Reply 19

Read SMS 19

SMS Settings 20

Signature 20

SMS Centre 20

Broadcast SMS 20

Reception 20

Topics 20

District code 20

Mailboxes 20

Call List 21

Extras 22

Call counters 22

Accumulated call timers 22

Accumulated cost 22

Last Call Information 23

-> Euro 23

<- Euro 23

Euroconverter 23

Brick game 24

Calculator 24

Alarm Clock 24

Settings 25

Sounds 25

Ringer volume 25

Ringer 26

Key tones 27

New SMS tone 27

Vibra alert 27

Display 27

Zoom 27

Contrast 27

Security 28

Public names 28

Change codes 28

PIN protection 29

Time and date 29

Clock display 29

Set date and time 29

Hotkeys 29

Voice command 30

Network 31

Call settings 31

Call forward 31

Caller ID 32

Network Services 33

Touchtones (DTMF) 33

Make a second call 33

Autoredial 34

Call waiting 34

Answer a second call 34

Conference call 34

Answer up to 5 calls 35

Operator services 36

WAP 36

Launch the

Browser 36

Favourites 38

Last Page 39

Settings 39

Images 39

Status icons 39

Access settings 40

Phone Number 40

Password 40

Gateway 41

Security 41

Home page 41

Glossary 42

Precautions 43

Environmental care 47

Troubleshooting 48

Index 50

Declaration of

conformity 53

Philips Authentic

Accessories 54

Introduction

Thank you for purchasing your Philips Azalis 238.

This guide will help you to learn easily and quickly how to use your phone.

Symbols used in this guide

Ringer volume A function displayed on your phone screen.

Represents a key on your phone keypad.

Represent a function on the compass key.

Long press: Press and hold the key for 2 seconds.

Activate/deactivate Pressing the same key (called a toggle key) or using

/ will alternate between different options:

ex. Activate and Deactivate.

Press ->

Settings -> Call settings -> Call forward

This represents a series of commands to tour the menu until you

reach the specific function being discussed. The most important

point to remember is the necessity to press key AFTER EACH

LEVEL before you can tour the next level. So, the above example is:

Press ->

Settings ->

Call settings

-> Call forward

Before your first call

The SIM card

To use your phone, you must insert a valid SIM card for your GSM

subscription.

This card contains your telephone number. It also has memory to store the

phone numbers and messages you wish to retain. If you use this card on

another phone, you still have the same phone number, stored numbers and

messages.

PIN and PUK codes

The PIN code is a secret code in your SIM card to protect it from abusive

use. If you or anyone else enters a wrong PIN code 3 times, your SIM card is

blocked. To unblock it, you must request the PUK code from your Network

Operator.

Read the safety instructions in the

Precautions section before use.

Insert the SIM card

1Remove the SIM card from

your card.

2Remove the

battery cover.

3Push the metal retaining clip

to the left and lift the

cardholder.

4Slide the SIM card into its slot until it stops.

Be careful that the clipped corner is in the identical

position as on the drawing.

5Close the cardholder and push the clip to

the right.

The battery

Your phone is powered by a rechargeable battery.

• To optimize the battery capacity, please allow the battery to fully discharge

the 3 first times before recharging.

• To maintain optimal battery capacity, do not wait until the battery indicator

reaches low. This level is reached when only one bar is displayed in the

battery indicator, see page 9.

• If you do not use the phone for several days, you should disconnect the

battery.

• For a full recharging please allow the charger to be connected for 1h40.

Insert the battery

Attach the battery cover

1Plug the connector into the socket. If you

cannot plug the connector, try again

reversing the plug.

2Slide the battery in its housing.

1Hook the battery cover onto the

hinges on the bottom of the phone.

2Press the top down until latch

catches.

Remove the battery

LNOTE:

* When disconnecting the battery, the settings for date and time will be lost.

Charge the battery

With the battery inside the phone:

LNOTE

The only way to turn off the charger is to unplug it, so use an easily accessible AC

power socket.

Bars moving ➨battery is charging

Bars steady ➨battery is fully charged

Battery outline flashing (see Troubleshooting page 48).

1Remove the battery cover.

2Lift the bottom of the battery out of the phone and slide

it out.

3Unplug the connector from its slot.

1Plug the connector into the

right socket at the base of the

phone.

2Plug the transformer unit into

an easily accessible AC

power socket.
