Philips Azalis 288 Manuale utente

GB€• 4311 255 50571

Discover your Phone

* The keypad automatically unlocks when you receive a call. You can still place an emergency

call.

NOTE:

Philips continuously strives to improve its products, and the information and specifications

described in this user manual are subject to change without notice.

Philips tries to ensure that all information in this user manual is correct, but does not accept

liability for any error, omission or discrepancy between this user manual and the product

described.

Earpiece

Green "Pick up" key D

- Press to answer a call.

- Press to dial a number, or

name displayed on the screen.

- In WAP mode, corresponds to a

softkey.

WAP @

- Press to access WAP browser.

Alphanumeric keypad

- Press keys to enter numbers

and text.

- Long press on a key to activate

hotkey function.

Microphone

Antenna

Screen

Idle screen displays the time,

date and network name.

Red "Hang up" Rand

"On/Off" key

- Long press to switch your

phone on/off.

- Press to end a call.

- In WAP mode, corresponds to a

softkey.

Menu M

- Press to enter carousel menu.

- Press to return to idle screen.

WAP mode:

- Press to open the browser

menu.

Compass key

Use this key to navigate in the

menus, the OK key is used to

validate information.

Cancel/back key C

Idle mode:

- Long press to lock/unlock the

keypad*.

Navigation mode:

- Press to return to previous

menu.

Edit mode:

- Press to delete a character.

- Long press to delete all

characters.

WAP mode:

- Press to go back one page.

- Long press to exit browser.

Language

- Long press

0 to choose a language in which the

telephone functions will be displayed.

OK O

Idle mode:

- Long press for voice dial or

voice command.

Quick Reference

Switch on/off: Long press r

Enter PIN: 1. Enter PIN code on keypad

2. Press oto confirm

Make a call: 1. Enter phone number on keypad

2. Press dto dial

Answer a call: Press d

End a call: Press r

Use Names List: 1. Press >to access

2. Press < > to select name

3. Press dto dial

Enter a Name: Select <New> from the Names list

Access and tour the menu: 1. Press M

2. Press < > to select a menu

3. Press oto confirm

4. Press < > to select a sub-

5. Press oto confirm

Return to previous menu: Press C

Return to idle screen: Press M

Visit our site and register on line @ http://www.pcc.philips.com

Service numbers

Messages Send SMS

Mailboxes

Read SMS

Settings

Security

Main

PHILIPS

* Subscription dependent. Please contact your operator for further details.

Broadcast SMS

Display

Time and Date

Hotkeys

Call settings

Names

Call list

Extras

Access settings

Settings

Help

Sounds

SMS settings

Oper. services*

Voice command

Launch

Network Services

WAP Last page

Favourites

Organiser

Table of contents

Discover your Phone 1

Introduction 3

Symbols used in this

guide 3

Before your first call 3

The SIM card 3

PIN and PUK codes 3

Insert the SIM card 4

The battery 5

Insert the battery 5

Attach the battery cover 5

Remove the battery 6

Charge the battery 6

Screen 7

Phone Functions 8

Switch on/off 8

Idle Screen 8

Make a call 9

Answer a call 9

End a call 10

Emergency call 10

Text Entry 10

The Carousel 13

Main Menus 13

Names 14

<New> 14

Send SMS 15

Voice Dial 15

Change or Delete 15

Messages 16

Send SMS or Reply 17

Read SMS 18

SMS Settings 18

Signature 18

Delivery report 18

Auto save SMS 18

Broadcast SMS 18

Reception 19

Topics 19

District code 19

Mailboxes 19

Call List 20

Organiser 21

Events 21

Day view, Week view and

Month view 21

Extras 22

Call counters 22

Accumulated call timers 22

Accumulated cost 22

Show 22

Reset 22

Cost limit 23

Show balance 23

Cancel cost limit 23

Charge rate 23

Last Call Information 23

-> Euro 23

<- Euro 24

Brick game 24

Calculator 24

Alarm Clock 25

Voice memo 25

Settings 26

Sounds 26

Ringer volume 26

Ringer 27

Key tones 28

New SMS tone 28

Vibra alert 28

Organiser alerts 28

Display 29

Zoom 29

Contrast 29

Security 29

Keypad lock 29

Public names 29

Call barring 29

Call restriction 29

Change codes 30

PIN protection 30

Time and date 30

Clock display 30

Set date and time 30

Hotkeys 31

Voice command 33

Network 34

Preferred list 34

Call settings 34

Call forward 34

Any key answer 35

Call waiting 35

Caller ID 35

Network Services 36

Touchtones (DTMF) 36

Make a second call 36

Autoredial 37

Answer a second call 37

Conference call 37

Operator services 39

WAP 39

Launch the Browser 40

Favourites 42

Last Page 42

Settings 42

Images 42

Status icons 43

Access settings 43

Gateway 43

Security 43

Home page 43

Phone Number 44

Password 44

Glossary 45

Precautions 46

Environmental care 50

Troubleshooting 51

Index 53

Declaration of

conformity 56

Philips Authentic

Accessories 58

Introduction

Thank you for purchasing your Philips Az@lis 288.

This guide will help you to learn easily and quickly how to use your phone.

Symbols used in this guide

Ringer volume A function displayed on your phone screen.

1Represents a key on your phone keypad.

C < > o Represent a function on the compass key.

Long press: Press and hold the key for 2 seconds.

Activate/deactivate Pressing the same key (called a toggle key) or using

</ >will alternate between different options:

ex. Activate and Deactivate.

Press M -> Settings -> Call settings -> Call forward

This represents a series of commands to tour the menu until you

reach the specific function being discussed. The most important

point to remember is the necessity to press okey AFTER EACH

LEVEL before you can tour the next level. So, the above example is:

Press M-> Settings o-> Call settings o

-> Call forward o

Before your first call

The SIM card

To use your phone, you must insert a valid SIM card for your GSM

subscription.

This card contains your telephone number. It also has memory to store the

phone numbers and messages you wish to retain. If you use this card on

another phone, you still have the same phone number, stored numbers and

messages.

PIN and PUK codes

The PIN code is a secret code in your SIM card to protect it from abusive

use. If you or anyone else enters a wrong PIN code 3 times, your SIM card is

blocked. To unblock it, you must request the PUK code from your Network

Operator.

Read the safety instructions in the

Precautions section before use.

Insert the SIM card

1Remove the SIM card from

your card.

2Remove the battery

cover.

1Press on the battery

cover latch at the

back of the phone.

2Lift off the battery

cover.

3Push the metal retaining clip to

the left and lift the cardholder.

4Slide the SIM card into its slot until it stops.

Please ensure that the clipped corner is in the

identical position as on the drawing.

5Close the cardholder and push the clip to

the right.

The battery

Your phone is powered by a rechargeable battery.

• To optimise the battery capacity, please allow the battery to fully discharge

3 times in a row. To then maintain optimal battery capacity, do not wait

until the battery indicator reaches low. This level is reached when only one

bar is displayed in the battery indicator, see page 7.

• If you do not use the phone for several days, you should disconnect the

battery.

• For a full recharging please allow the charger to be connected for 53 mns.

Insert the battery

Attach the battery cover

1Plug the connector into the socket. If you

cannot plug the connector, try again

reversing the plug.

2Tilt battery and press lightly against the

battery latch.

3Press the battery downwards.

1Hook the battery cover onto the

hinges on the bottom of the phone.

2Press the top down until latch

catches.

Remove the battery

When disconnecting the battery, the settings for date and time will be lost.

Charge the battery

With the battery inside the phone:

NOTE:

The only way to turn off the charger is to unplug it, so use an easily accessible AC

power socket. You can connect the charger to an IT supply (Belgium only).

Bars moving ➨battery is charging

Bars steady ➨battery is fully charged*

Battery outline flashing (see Troubleshooting page 51).

* Keeping the mobile plugged to the charger when the battery is fully charged does

not damage the phone.

1Press bottom of battery lightly

against battery latch.

2Lift bottom of battery and slide it

out of the phone.

3Unplug the connector from its slot.

1Plug the connector into the

right socket at the base of the

phone.

2Plug the transformer unit into

an easily accessible AC

power socket.
