Philips CTW3500BK/94 Manuale utente
1
Your Phone
Philips continuously strives to improve its products. Due to software
upgrading, some contents in this user guide may be different from your
product.Philips reserves the rights to revise this user guide or withdraw it
at any time without prior notice. Please take your product as standard.
Touch screen
Back key
Side volume key
Headphone jack
Power key
/Lock key
Home key
Option key
Charger/Micro USB
port connector
2
Turn your phone on and off
1
Press and hold power key to turn on your phone.
2
To turn off your phone, press and hold power key and then select
Power off.
Note:
•
If you are turning on your phone for the first time, follow the on-screen instructions to
set up your device.
Lock/unlock the touch screen
You can lock the touch screen and keys to prevent any unwanted device
operations.
1
To lock, press power key.
2
To unlock, press the icon , and then flick your finger in any
direction.
Keys
Learn about the main keys.m
Key Definition Function
Power - Press and hold to power on/off.
- Press to turn on/off the screen display.
- Hold to access the Phone options, choose Silent or
Airplane mode.
MHome
key
- Return to the home screen.
- Hold to open the list of recent applications.
OMenu
key
- Open a list of options available on the current
screen.
- On the home screen, open the Wallpaper, Manage
applications and System settings.
BBack key - Return to the previous screen or exit.
- Hide the onscreen keyboard when it is opened.
Side
volume
key
-Adjust the ringer volume while in standby mode or
adjust the voice volume during a call.
-When receiving an incoming call, briefly press down
either volume key to mute the ringtone.
3
Use the touch screen
Learn basic actions to use the touch screen.
Customize home screen
You can customize the home screen to match your preferences.
Function Operation
Tap Touch once to select or launch a menu, option, or
application.
Tap and
hold
Tap an item and hold it for more than 2 seconds.
Drag Tap an item and move it to a new location.
Double-tap Tap an item twice quickly.
Flick Briskly scroll up, down, left, or right to move through lists
or screens.
Pinch Place two of your fingers far apart, and then pinch them
together. In some apps, like web browser, you can pinch
the screen using two fingers(for example, thumb and index
finger) to zoom in or zoom out when viewing a picture or
a web pages.
Function Operation
Add items Tap to enter into menu screen or widgets, tap and hold
an item, and then drag it to home screen.
Move items Tap and hold an item, and then drag it to a new location.
Remove
items
Tap and hold an item, the trash bin appears at the bottom
of the home screen. Drag the item to the trash bin.
When the item turns red, release the item.
Select a
wallpaper
In home screen, press O>Wallpaper or tap and hold the
blank area in home screen, select an image from options.
4
Home screen
From the Home screen, you can view your device’s status and access
applications.
The Home screen has multiple panels. Scroll left or right to view the
panels on the Home screen. There are 5 extended home screen, slide
your finger horizontally to the left and right to check each one. Tap M
to return to the center home screen.
You can add your favorite applications, shortcuts and widgets so they’re
always just a tap away.
Your phone’s home screen consists of the following areas:
Notifications panel
When you get a new notification, you can open the Notifications panel
to see what event notification or new information you have received.
-
To open the Notifications panel,press and hold the status bar, then
slide one finger downward. If you have several notifications, you can
scroll down the screen to see them all.
-
To hide the panel, drag the bottom of the panel upwards.
From the notifications panel, you can also view your phone's current
status and use the each options.
Status Bar
Shortcut icons
Search input
window
Widgets and
applications
Menu key：Tap
to enter into
applications
5
-
Open the notifications panel and then tap to open the
phone's status panel.
-
Place two fingers on the status bar, then slide your fingers down-
ward.
6
Icons and symbols
Learn about the icons and symbols on the screen.
Icons Function
Your phone will not ring when receiving a call.
Your phone will vibrate when receiving a call.
The bars indicate the battery level.
(Blue bars) normal charging.
(Blue bars) normal charging when the phone is turned off.
WLAN activated.
Your phone is connected to a GSM network. The more bars are
shown the better the reception is.
Your phone is connected to network.
Downloading data.
Uploading data.
Call in progress.
You have a missed call.
New SMS .
Connected to PC.
USB debugging connected.
Bluetooth is activated.
The headset is plugged into the phone.
The alarm clock is activated.
FM radio turned on in the background.
Music is playing in the background.
Error occurred or caution required.
7
Getting started
Congratulations on your purchase and welcome to Philips!
To get the most of your product and enjoy all Philips has to offer,
register your product at:
www. philips. com/mobilephones
More details about your product, please access:
www.philips.com/support
Note:
•
Please read the safety instructions in the “Safety & Precaution” section before use.
Assembling and Charge
Learn about installing USIM or SIM card and charging the battery for the
first use.
Insert SIM card
Follow the steps below to insert your USIM or SIM card. Remember to
turn off your mobile phone before removing the back cover.
1
Remove the back cover.
2
Take out the battery.
8
3
Insert the SIM card.
4
Install the battery.
5
Replace the back cover.
Charge the battery
The battery icon in the upper-right corner shows the battery level of
charging status.
1
2
9
Tips:
•
You can use the phone while it is charging.
•
Keeping the charger plugged to the mobile phone when the battery is fully charged will
not damage the battery.
•
If you do not intend to use your phone for several days, we recommend that you
remove the battery.
•
If a fully charged battery left unused, it will lost its charge over time.
•
If a battery is being used for the first time or the battery has not been used for a
prolonged period, it may take longer time to recharge.
Insert a Micro SD card (Memory card)
Insert a memory card
You can expand the memory of your phone and store more additional
multimedia files by adding a micro-SD card.
Your device accepts memory cards with maximum capacities of 32 GB.
1
Unlock the memory card cover.
2
Align your micro-SD card with the slot. Put it in place.
Remove the memory card
Ensure that the phone is not currently accessing the memory card.
Before removing a memory card, first unmount it for safe removal.
1
In Idle screen, select O> System settings> Storage >Unmount
SD card.
2
Push the memory card gently until it disengages from the phone.
3
Remove the memory card.
Note:
•
Do not remove a memory card while the device is transferring or accessing information
to prevent corrupting or damaging the files in the memory card.
10
Format the memory card
Formatting your memory card on a PC may cause incompatibilities with
your device. Format the memory card only on the device.
In Idle screen, select O> System settings> Storage >Erase SD
card.
Note:
•
Before formatting the memory card, remember to make backup copies of all important
data stored on your device.
Personalize your phone
Time and Date
In idle screen, tapO> System settings> Date&time to control how
time and date appears on your device.
•
Automatic date & time: Set to receive time information from the
network and update the time and date automatically.
•
Automatic time zone: Set to receive time zone information from
the network when you move across time zones.
•
Set date: Set the current date manually.
•
Set time: Set the current time manually.
•
Select time zone: Select a time zone.
•
Use 24-hour format: Set to show the time in 24-hour format or
12-hour format.
•
Choose date format: Select a date format.
Tips:
•
If the battery remains fully discharged, the time and date will be reset.
Set a screen lock
You can lock your device by activating the screen lock feature.
In idle screen, tapO>System settings>Security>Screen lock.
•
None: Disable the screen lock.
•
Slide: Choose slide to unlock the screen.
•
Voice Unlock:Set a voice recognition unlock.
•
Pattern: Draw a pattern to unlock the screen.
•
PIN: Unlock the screen by enter the PIN code.
