Philips AJ3110/12 Manuale utente

Clock Radio AJ3110

User manual

Manuel d'utilisation

Gebruikershandleidingen

Important notes for users in the U.K.

Mains plug

This apparatus is fitted with an approved 13 Amp plug. To change a fuse

in this type of plug proceed as follows:

1. Remove fuse cover and fuse.

2. Fix new fuse which should be a BS1362 3 Amp, A.S.T.A. or BSI

approved type.

3. Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be cut

off and an appropriate plug fitted in its place. If the mains plug con-

tains a fuse, this should have a value of 3 Amp. If a plug without a

fuse is used, the fuse at the distribution board should not be greater

than 3 Amp.

Note: The severed plug must be disposed of to avoid a possible shock

hazard should it be inserted into a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with the following code: blue

= neutral (N), brown = live (L). As these colours may not correspond

with the colour markings identifying the terminals in your plug, pro-

ceed as follows: (To continue on the next page)

• Connect the blue wire to the terminal marked N or coloured

black.

• Connect the brown wire to the terminal marked L or coloured red.

• Do not connect either wire to the earth terminal in the plug,

marked E (or e) or coloured green (or green and yellow).

Before replacing the plug cover, make certain that the cord grip is

clamped over the sheath of the lead - not simply over the two wires.

Recording and playback of material may require consent. See Copyright

Act 1956 and The Performer’s Protection Acts 1958 to 1972.

ENVIROMENTAL INFORMATION

All unnecessary packaging material has been omitted. The packaging can

be easily separated into three materials: cardboard, polystyrene and

plastic.

Your set consists of materials which can be recycled if disas-

sembled by a specialized company. Please observe the local

regulations regarding the disposal of packaging, dead batteries

and old equipment.

Disposal of your old product

Your product is designed and manufactured with high quality

materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a

product it means the product is covered by the European

Directive 2002/96/EC.

Please inform yourself about the local separate collection sys-

tem for electrical and electronic products.

Please act according to your local rules and do not dispose of your old

products with your normal household waste. The correct disposal of your

old product will help prevent potential negative consequences for the

environment and human health.

English

CONTROLS

1SET TIME - sets the clock time

2SLEEP -

activates the radio for sleep function

3ALARM SET/OFF -

sets the alarm time

- stops the active alarm for 24 hours

4ALARM indicator -

lights up when alarm is activated

5DISPLAY - shows the clock/ alarm time and status of the set

6Frequency indicator - shows the radio frequency of your selected waveband

7HOUR/MINUTE -

adjusts the hours/minutes for the clock and alarm time

8REPEAT ALARM/SLEEP OFF

- switches off the active alarm for a 8-9 minute period

- switches off the radio sleep function

9VOLUME - adjusts the sound level

0BAND - selects FM/AM waveband

!TUNING - tunes to radio stations

@RADIO/ALARM

–RADIO

ON switches on the radio

–

OFF switches off the radio/alarm

–ALARM -

RADIO activates the radio for alarm

–ALARM -

BUZZER activates the buzzer for alarm

#Battery door -

opens to store a 9 volt 6F22 type battery (not included) for

clock memory backup

$Power cord -

connects to wall outlet

%Pigtail -

FM antenna to improve FM reception

CAUTION

Use of controls or adjustments or performance of procedures other than

herein may result in unsafe operation.

This set complies with the radio interference requirements of the

European Community.

INSTALLATION

POWER SUPPLY

Check if the power supply, as shown on the type plate located on the bot-

tom of the set, corresponds to your local power supply. If it does not, consult

your dealer or service center.

Connect the power cord to the wall outlet.

To disconnect the set from the power supply completely, remove the

plug from the wall outlet.

CLOCK MEMORY BACKUP

The clock memory backup allows your alarm and clock time settings to be stored

for up to a day when there is a power interruption e.g. power failure. The com-

plete clock radio and display illumination will be switched off. As soon as the

power supply returns, the display will indicate the correct time.

Remove the battery door to insert a 9 volt 6F22 type battery (not included) for

backup.

Replace the battery door.

NOTE:

If no backup battery is installed or the power interruption is prolonged, you

will need to set the clock and alarm time again.

For users in the U.K., please follow the boxed instructions ‘Important

notes...’ on this sheet.

Batteries contain chemical substances, so they should be disposed

of properly.

Standby power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1W

RADIO

You can use this set solely as a radio!

Adjust RADIO/ALARM to

RADIO

ON to switch on the radio.

Select your waveband by adjusting the BAND switch

Adjust TUNING to tune to your desired station

Turn the VOLUME control to adjust the volume level

Adjust RADIO/ALARM to OFF to switch off the radio.

To improve reception:

FM:

Extend and position the pigtail fully to obtain optimal reception.

MW:

Uses a built-in antenna inside the set. Direct the antenna by adjusting

the position of your set

SETTING THE CLOCK AND ALARM TIME

The time is displayed using the 24-hour clock.

Press and hold SET TIME or ALARM SET/OFF.

Press HOUR or MINUTE repeatedly, or hold down on the respective button to

adjust the hours and minutes.

Release SET TIME or ALARM SET/OFF, and HOUR/MINUTE when you

reach the correct setting.

™

The set clock time will show on the display and start to run.

SELECTING THE ALARM MODE

GENERAL

If you wish to use the alarm, you must set the alarm time first. You can choose

from two different alarm modes to wake you up: by radio or buzzer.

•

Select your choice of alarm mode by adjusting RADIO/ALARM to

ALARM -

RADIO or

ALARM -

BUZZER.

™

The Alarm indicator lights up.

Helpful hints:

•

If you have selected the radio mode, make sure you have adjusted the

volume loud enough to wake you.

•

The buzzer is set at a fixed volume and cannot be adjusted.

SWITCHING OFF THE ALARM

There are three ways of switching off the alarm. Unless you cancel the alarm

completely, the 24 hour alarm reset option will be automatically selected after

1 hour and 59 minutes, from the time your alarm time first goes off.

24 HOUR ALARM RESET

If you want the alarm mode to be stopped immediately but also wish to retain the

same alarm setting for the following day:

•

Press ALARM SET/OFF during the alarm call.

™

The Alarm indicator remains on.

CANCELING THE ALARM COMPLETELY

To cancel the set alarm time before it goes off, or during the alarm call:

•

Adjust RADIO/ALARM to OFF position.

™

The Alarm indicator turns off.

REPEAT ALARM

This repeats your alarm call at 8-9-minute intervals.

During the alarm call, press

REPEAT ALARM/SLEEP OFF

Repeat if desired for up to 1 hour and 59 minutes. To deactivate it, press

ALARM SET/OFF, or adjust RADIO/ALARM to OFF position.

SLEEP

About Sleep

This set has a built-in timer which enables the set to be automatically switched

off during radio playback after a set period of 1 hour and 59 minutes. This allows

you to lie back, listen and fall asleep. The maximum sleep time is 1 hour and 59

minutes.

Setting SLEEP

Set RADIO/ALARM to OFF position.

2Set the sleep time to activate the sleep function by selecting one of the following

ways:

•

Simply press SLEEP to set your sleep time to 59 mintues.

• Hold down SLEEP, then press MINUTE repeatedly to adjust sleep time from 59

minutes downward.

• Hold down SLEEP and press HOUR to get one more hour sleep time (1:59 hours).

™

To cancel sleep, press

REPEAT ALARM/SLEEP OFF

SAFETY & MAINTENANCE

•

Install the unit near the AC outlet and where the AC power plug can be easily

reached.

•

The apparatus shall not be exposed to dripping or splashing.

•

If you do not intend to use the set for a long time, withdraw the power plug

from the wall outlet. In addition to this, it is advisable to remove the battery

from the clock radio. This will prevent any danger of leakage and the clock

radio will not be damaged.

•

Do not expose the set to humidity, rain, sand or excessive heat caused by

heating equipment or direct sunlight.

•

To clean the set, use a soft, slightly dampened chamois leather. Do not use

any cleaning agents containing alcohol, ammonia, benzene or abrasives as

these may harm the housing.
