User manual

Always there to help you

AJ3200

Question?

Contact

Philips

1EN

Contents

1 Important 2

2 Your clock radio 2

Introduction 2

What's in the box 2

Overview of the clock radio 3

3 Get started 4

Install battery 4

Connect power 4

Turn on 4

Set time 4

4 Listen to FM radio 5

Tune to FM radio stations 5

Store FM radio stations in memory 5

Select a preset radio station 5

Adjust volume 5

5 Other features 6

Charge your mobile devices 6

Set alarm timer 7

Set sleep timer 7

6 Product information 8

Specications 8

7 Troubleshooting 9

8 Notice 9

2EN

1 Important

Warning

• Never remove the casing of this clock radio.

• Never lubricate any part of this clock radio.

• Never place this clock radio on other electrical

equipment.

• Keep this clock radio away from direct sunlight, naked

amesorheat.

• Make sure that you always have easy access to the

power cord, plug or adaptor to disconnect the clock

radio from the power.

• Make sure that there is enough free space

around the product for ventilation.

• Battery usage CAUTION – To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

clock radio:

• Install the battery correctly, + and - as

marked on the clock radio.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove the battery when the clock

radio is not used for a long time.

• The battery shall not be exposed to

excessiveheatsuchassunshine,reor

the like.

• Use only power supplies listed in the user

manual.

• The clock radio shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

clockradio(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

2 Your clock radio

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this clock radio, you can

• listen to FM radio;

• charge your mobile devices; and

• set two alarms to ring at different time.

What's in the box

Check and identify the contents of your

package. (Fig. 1)

3EN

Overview of the clock radio

a Dock for charging mobile devices

b SOURCE

• Turn on the clock radio.

• Switch the clock radio to standby

mode.

• Select FM radio source.

c PRESET/SET TIME

• Store radio stations in memory.

• Select a preset radio station.

• Set time.

d AL1/AL2/- VOLUME +

• Set alarm.

• Adjust volume.

e HR/MIN/- TUNE +

• Tune to FM radio stations.

• Set hour and minute.

f SNOOZE/SLEEP

• Snooze alarm.

• Set the sleep timer.

g Display panel

• Display current status.

4EN

3 Get started

Always follow the instructions in this chapter in

sequence.

Install battery

The batteries can only back up clock and alarm

settings when AC power is disconnected.

Caution

• The batteries contain chemical substances, so they

should be disposed of properly.

1 Open the battery compartment.

2 Insert 2 AA batteries with correct polarity

(+/-) as illustrated.

3 Close the battery compartment.

Tip

• The display backlight is off when AC power is

disconnected.

Connect power

Caution

• Risk of product damage! Make sure that the power

voltage corresponds to the voltage printed on the back

or underside of the clock radio.

• Risk of electric shock! When you unplug the AC adapter,

always pull the plug from the socket. Never pull the cord.

Connect the AC power adaptor to the wall

socket.

Turn on

Press to turn on the clock radio.

» The clock radio enters FM radio mode.

• Press again to switch the product to

standby mode.

Set time

Note

• You can only set time in standby mode.

1 Press and hold SET TIME for two seconds

to activate clock setting mode.

» The hour and minute digits blink.

2 Press HR repeatedly to set hour.

3 Press MIN repeatedly to set minute.

4 Press SET TIMEagaintoconrm.

» The set time is displayed.

5EN

4 Listen to FM

radio

Note

• Keep the clock radio away from other electronic

devices to avoid radio interference.

• For better reception, fully extend and adjust the

position of the FM antenna.

Tune to FM radio stations

1 Press SOURCE to turn on FM radio.

2 Press and hold TUNE - or TUNE + for 2

seconds.

» The clock radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more radio

stations.

To tune to a station manually:

In tuner mode, press TUNE - or TUNE +

repeatedly to select a frequency.

Store FM radio stations in

memory

You can store up to 10 FM radio stations.

1 Tune to an FM radio station.

2 Press and hold PRESET for two seconds.

» The preset number begins to blink.

3 Press TUNE - or TUNE + to select a

number.

4 Press PRESETagaintoconrm.

5 Repeat steps 1 to 4 to store other stations.

Tip

• To remove a pre-stored station, store another station

in its place.

Select a preset radio station

In tuner mode, press PRESET repeatedly to

select a preset station.

Adjust volume

While listening, press - VOLUME + to adjust

volume.

6EN

5 Other features

Charge your mobile devices

With this clock radio, you can charge your

Android-powered mobile phone with a micro

USB socket and Apple devices with a lightning

or 30-pin connector.

1 Connect the clock radio with your mobile

device.

• For Android-powered mobile device

with a micro USB socket: use the

supplied cable to connect the product

with the mobile device as illustrated;

• For Apple devices with a lightning or

30-pin connector: use the charging

cable of the Apple device (not

supplied) to connect the product with

the mobile device as illustrated;

2 Connect the clock radio to AC power.

» The mobile device begins to charge.

Note

• Gibson Innovations does not guarantee the

compatibility of this product with all devices.

7EN

Set alarm timer

You can set two alarms to ring at different time.

Note

• You can only set the alarm in standby mode.

• Make sure that you have set the clock correctly.

1 Press and hold AL1 or AL2 for two

seconds to activate alarm setting mode.

» The hour and minute digits blink.

2 Press HR repeatedly to set the hour.

3 Press MIN repeatedly to set the minute.

4 Press AL1 or AL2toconrm.

Tip

• The clock radio exits alarm setting mode when being

idle for 10 seconds.

Activate or deactivate the alarm timer

Press AL1 or AL2 repeatedly to activate or

deactivate the alarm timer.

» If the alarm timer is activated, the

alarm indicator for FM tuner or buzzer

is displayed.

» If the alarm timer is deactivated, the

alarm indicator disappears.

• To stop the ringing alarm, press the

corresponding AL1/AL2.

» The alarm repeats ringing for the next

day.

Note

• If FM tuner is selected and you are listening to radio

when alarm time comes, buzzer is activated automatically.

• If buzzer is selected as alarm source, the alarm volume

remains at a default level.

• If FM tuner is selected as alarm source, the alarm

volume increases gradually and cannot be adjusted.

Alarm source Alarm

duration

AC power FM tuner/Buzzer 30 minutes

Snooze the alarm

When alarm sounds, press SNOOZE.

» The alarm snoozes and repeats ringing

nine minutes later.

Set sleep timer

1 Turn on the product..

2 Press SLEEP repeatedly to select a period

(in minutes).

» The clock radio switches to standby

mode automatically after the preset

period.

To deactivate the sleep timer:

• Press SLEEP repeatedly until [OFF]

(off) appears.

120 90 60 30 15

OFF

8EN

6 Product

information

Note

• Product information is subject to change without prior

notice.

Specications

Amplier

Total Output Power 500 mW

Tuner (FM)

Tuning Range 87.5-108

MHz

Tuning Grid 50 KHz

Sensitivity

- Mono, 26 dB S/N Ratio <22 dBf

Total Harmonic Distortion <3%

Signal to Noise Ratio >50 dBA

General information

AC Power

(Power Adapter)

Brand name: Philips;

Model: S012B0551500B;

Input: 100-240V~ 50/60Hz

max. 300mA

Output: 5.5 V 1500mA

USB Port 5 V 1 A

Operation Power

Consumption

9 W

Standby Power

Consumption

<1 W

Dimensions:

- Main Unit

(W x H x D) 112 x 101 x 125 mm

Weight:

- Main Unit 0.4 kg
