Philips AJ3400/05 Manuale utente
User manual
Register your product and get support at
AJ3400/05
www.philips.com/support
Always there to help you
Question?
Contact
Philips
2
Contents
1 Important 3
2 Your clock radio 4
What's in the box 4
3 Get started 4
Install battery 4
Connect power 5
Set time 5
4 Listen to FM radio 6
Tune to FM radio stations 6
Store FM radio stations manually 6
Select a preset radio station 6
Adjust volume 6
5 Other features 7
Set alarm timer 7
Set sleep timer 8
Adjust brightness 8
6 Product information 8
Specications 8
7 Troubleshooting 9
8 Notice 10
EN
3EN
1 Important
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
otherapparatus(includingampliers)that
produce heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the clock radio.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this clock radio during lightning
storms or when unused for long periods
of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when
the clock radio has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the clock radio, the
clock radio has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
clock radio:
• Install the battery correctly, + and - as
marked on the clock radio.
• Remove the battery when the clock
radio is not used for a long time.
• The battery shall not be exposed to
excessiveheatsuchassunshine,reor
the like.
• This clock radio shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
clockradio(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
4EN
2 Your clock radio
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
What's in the box
(Fig. )
a
3 Get started
Always follow the instructions in this chapter in
sequence.
Install battery
If there is power interruption, the clock
memory backup allows your alarm and clock
settings to be stored for up to a day.The display
backlight will be off.
Caution
• Risk of explosion! Keep the battery away from heat,
sunshineorre.Neverdiscardbatteryinre.
• The battery contains chemical substances, so it should
be disposed of properly.
Insert2x1.5VAAAbattery(notsupplied)with
correctpolarity(+/-)asillustrated.(Fig. )
b
5EN
Connect power
Caution
• Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the clock radio.
• Risk of electric shock! When you unplug the power
adapter, always pull the plug from the socket. Never
pull the cord.
Note
• The type plate is located at the bottom of the clock
radio.
(Fig. )
c
Set time
Note
• You can only set time in standby mode.
(Fig. )
1
2 sec
2
34
d
PRESET/
SET TIME
PRESET/
SET TIME
HOUR
MIN
6EN
4 Listen to FM
radio
Note
• Keep the clock radio away from other electronic
devices to avoid radio interference.
• For better reception, fully extend and adjust the
position of the FM antenna.
Tune to FM radio stations
(Fig. )
e
2 sec
2
RADIO
ON/OFF
1
MIN
TUNING
2 sec
HOUR
TUNING
34
- VOLUME +
Store FM radio stations
manually
You can store up to 10 FM radio stations.
1 Tune to an FM radio station.
2 Press and hold PRESET for two seconds.
» The preset number begins to blink.
3 Press TUNING repeatedly to select a
number.
4 Press PRESETagaintoconrm.
5 Repeat steps 1 to 4 to store other stations.
Tip
• To remove a pre-stored station, store another station
in its place.
Select a preset radio station
In tuner mode, press PRESET repeatedly to
select a preset number.
Adjust volume
While listening, press - VOLUME + to adjust
volume.
» Thevolumelevel(1~15)showsinthe
display.
7EN
5 Other features
Set alarm timer
Set alarm
Note
• You can only set the alarm in standby mode.
• When alarm sounds, volume rises gradually.You cannot
adjust the alarm volume manually.
• Make sure that you have set the clock correctly.
Followtheillustrationtosettherstalarm.(Fig.
)
• AL1:settherstalarm.
• AL2: set the second alarm.
f
2 sec
AL1
1
HOUR
2
MIN
3
AL1
4
Tip
• The clock radio exits alarm setting mode when being
idle for 10 seconds.
Select alarm source
You can select FM radio or buzzer as the alarm
source. (Fig. )
» The corresponding alarm icon lights up.
• The AL2 setting is the same as AL1.
Activate/deactivate alarm timer
Press AL1 or AL2 repeatedly to activate or
deactivate the alarm timer.
» If the alarm timer is deactivated, the
alarm indicator turns off.
» The alarm repeats ringing for the next
day.
AL1FM
AL
1
g
AL1
8EN
Snooze alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing
nine minutes later.
Set sleep timer
This clock radio can switch to standby mode
automatically after a preset period. (Fig. )
To deactivate the sleep timer:
• Press SLEEP repeatedly until [OFF]
(off)appears.
Adjust brightness
Press BRIGHTNESS repeatly to adjust display
brightness.
h
120 90 60 30 15
OFF
SLEEP
i
BRIGHTNESS
6 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Total Output Power 0.4W RMS
Tuner (FM)
Tuning range 87.5-108
MHz
Tuning grid 50 KHz
Sensitivity
- Mono, 26 dB S/N Ratio
- Stereo, 46 dB S/N Ratio
<22 dBf
<49.5 dBf
Total Harmonic Distortion <2%
Signal to Noise Ratio >50 dBA
General information
AC power (power
adapter)
Brand name: Philips;
Model: AS030-050-
EI050;
Input: 100-240 V~,
50/60 Hz; 0.15 A;
Output: 5.0 V 0.5 A
Operation Power
Consumption
1.2 W
Standby Power
Consumption
<1 W
9EN
Dimensions:
Main Unit
(WxHxD) 191 x 104 x 69 mm
Weight:
-Main Unit 0.33 kg
7 Troubleshooting
Warning
• Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/welcome).Whenyoucontact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.
No power
•Ensure that the AC power plug of the unit
is connected properly.
•Ensure that there is power at the AC
outlet.
No sound
•Adjust the volume.
No response from the unit
•Disconnect and reconnect the AC power
plug, then turn on the unit again.
Poor radio reception
•Increase the distance between the unit and
your TV or VCR.
•Fully extend the FM antenna.
Alarm does not work
•Set the clock/alarm correctly.
Clock/alarm setting erased
•Power has been interrupted or the power
plug has been disconnected.
•Reset the clock/alarm.
10EN
8 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Gibson Innovations may void the user’s
authority to operate the equipment.
Hereby, Gibson Innovations declares that this
product is in compliance with the essential
requirements and other relevant provisions
ofDirective2014/53/EU.Youcanndthe
Declaration of Conformity on www.philips.com/
support.
Disposal of your old product
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
This symbol on a product means that the
product is covered by European Directive
2012/19/EU. Inform yourself about the local
separate collection system for electrical and
electronic products. Follow local rules and never
dispose of the product with normal household
waste. Correct disposal of old products
helps prevent negative consequences for the
environment and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene
(bags,protectivefoamsheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
