Philips DC200/93 Manuale utente

DC200

www.philips.com/welcome

Clock Radio

User Manual

P-01

AL1

840

T001

English

Congratulations on your purchase and welcome to Philips!

To fully benefit from the support that Philips offers,register

your product at www.philips.com/welcome.

SUPPLIED ACCESSORIES

– 1X certified AC/DC 9V adaptor

(Brand name: PHILIPS, Model No.: AS140-090-DA,

Input: 100-240V ~ 50/60Hz 0.7A, Output: 9.0V 1.56A)

– 4X dock adaptors (for different iPod types)

– 1X AUX-IN cable

CONTROLS

(See 1)

1SOURCE

–

selects iPod/TUNER/USB/NATURE/AUX mode

2POWER

–

switches the system on or to standby mode

–

stops active alarm for 24 hours

–

deactivates the sleep function

SLEEP

–

activates/

deactivates

the sleep function

4iPod MENU

–

enters the iPod menu

5PROG / SET TIME

–

activates/confirms clock time setting

3/ 4

/ 1/ 2

for iPod .............navigates in iPod menu

ALBUM/PRESET -/+

1/ 2

–

selects a preset radio station

–

selects albums in USB mode

–

selects time zone in clock mode

VOLUME

3/ 4

–

adjusts the sound level

for iPod

..............

confirms menu selection.

7Dock connector

–

connects iPod player

8USB jack

–

connects an external USB mass storage device

REPEAT

ALARM /

b r i g h t n e s s c o n t r o l

–

switches off the alarm for a 9 minute period

–

changes the brightness of the display illumination

0TUNING

¡1 / 2™

–

adjusts clock/alarm time

–

tunes to radio stations

–

selects previous/next tracks in the iPod/USB mode

–

fast searches forward/backward in the iPod/USB mode

MODE

–

selects different play modes: e.g. REPEAT or SHUFFLE (random order).

–

starts/pauses playback in the iPod/USB mode

–

stops playback in the iPod/USB mode

ALM

2 ALM

–

activates/confirm alarm 1/alarm 2 time setting

–displays alarm 1/

alarm

2 time

–switches off alarm 1/

alarm

2 time

@DISPLAY

–

shows clock/alarm times and status of the set

#AUX IN jack (3.5 mm)

–

connects to external audio source

$POWER jack

–

socket for AC/DC 9V adaptor

Pigtail

–

improves FM reception

POWER SUPPLY

Mains adaptor

Connect the mains adaptor to the set's DC 9V socket and to the

power socket.

Helpful hints: To avoid damage to the set, use only the adaptor supplied!

The power rating is located on the bottom of the set.

SELF-POWERED BACK-UP

The self-powered back-up conveniently allows your alarm and clock time set-

tings to be stored for up to 10 minutes when there is a power interruption

e.g. AC power failure.The complete clock radio and backlight illumination will

be switched off.

If power supply returns after 10 minutes and the display shows:

• clocktimeblinking-indicatesyouneedtore-adjusttheclocktime.

BASIC OPERATION.

Switching on the system

• PressPOWER.

™

The system will switch to the last selected source.

Switching the system to standby mode

• Inanysourcemode,pressPOWER.

Illumination brightness

Press REPEAT

ALARM /

BRIGHTNESS CONTROL once or more.

•

The brightness of the display can be adjusted:

Bright ➟Low ➟Off ➟Bright

SETTING THE CLOCK

1In standby mode, press and hold PROG/SET TIME until clock digits flashes.

Hold down or press ¡1 / 2™ repeatedly to set and adjust the hours.

3Press PROG/SET TIME

to confirm.

™

The clock digits for the minutes flash.

Hold down or press ¡1 / 2™ repeatedly to set and adjust the minutes.

5Press PROG/SET TIME

to confirm.

In clock mode, press ALBUM/PRESET -/+ 1/2to set your time zone.

To zoom in/out the clock display, press

MODE

in clock mode.

TUNER

Press

SOURCE

repeatedly to switch on the radio (FM only).

™

Display shows the radio frequency of the last selected waveband.

Your preset station is also shown if you are listening to a preset. (See 2)

Adjust the sound using VOLUME 3/4

To select preset stations, press ALBUM/PRESET -/+ 1/2once or repeatedly.

TUNING TO RADIO STATIONS

1Press and hold

¡1 / 2™

until the frequency in the display starts changing.

™ After the system tunes to a station of sufficient reception, display shows

its frequency.

• Totunetoaweakstation,press

¡1 / 2™

briefly and repeatedly until an

optimal reception is found.

To improve reception (FM):

Extend and position the pigtail fully to obtain optimum reception.

STORING AND USING PRESET STATIONS

You can store up to 20 FM radio stations in the memory.

1Tune to your desired station (see TUNINGTO RADIO STATIONS).

Press

PROG to activate the programming, and then press ALBUM/

PRESET -/+

1/ 2

to select a desired preset number

Press

PROG again to confirm.

Press

ALBUM/PRESET -/+

1/ 2

to listen to a preset station.

AUTOSTORE: Automatic programming

Press and hold

PROG for more than two seconds.

™Available radio stations will be automatically stored.

CAUTION

High voltage! Do not open.You run the risk of getting an electric

shock.The machine does not contain any user-serviceable parts.

Modification of the product could result in hazardous radiation

of EMC or other unsafe operation.

USING THE ALARM

GENERAL

Two different alarm times can be set.This can be useful when you need to

be woken up at a different time e.g. during the week and at the weekend,

and you can set different wake-up modes:

• Tunermode.

• iPod/USBmode.

• Naturesoundmode.

• Buzzermode.Thegentlewakebuzzeralarmincreasesitsbeeptonefre-

quency within seconds.

SETTING THE ALARM TIME AND MODE

(See 3)

1In any mode, press and hold 1 ALM or 2 ALM for two seconds.

™

AL1

AL2

icon and the hour digits flash.

Hold down or press ¡1 / 2™ repeatedly to set and adjust the hours.

3Press 1 ALM or 2 ALM

to confirm.

™

AL1

AL2

icon and the minutes digits flash.

Hold down or press ¡1 / 2™ repeatedly to set and adjust the mintues.

5Press 1 ALM or 2 ALM

to confirm.

™

The icon for the current alarm mode flashes.

Press ¡1 2™ / SOURCE repeatedly to select your desired alarm mode.

• ForNaturesoundmode,pressALBUM/PRESET -/+

1/ 2

to select

your desired nature sound track.

™

At the set alarm time, the selected sound source or buzzer will

switch on automatically.

Helpful hints:

–

If you have selected TUNER alarm mode,make sure you have properly tuned to

a station before turning off the set.

–

If you have selected iPod/USB alarm mode,make sure you have connected

the compatible iPod player or USB device, or the buzzer mode will be selected

automatically.

–

To check the alarm time setting for AL1 or AL2,press 1 ALM or 2 ALM.

SWITCHING OFFTHE ALARM

There are three ways of switching off the alarm. Unless you cancel the

alarm completely, the 24-hour ALARM RESET will be automatically

selected after 59 minutes from the time your alarm first goes off.

24 HOUR ALARM RESET

If you want the alarm mode to be stopped immediately but also wish to

retain the same alarm setting for the following day:

•

Press

POWER

or 1

ALM /

ALM

REPEAT ALARM

This repeats your alarm call at 9 minute intervals.

• Duringthealarmcall,pressREPEAT ALARM / BRIGHTNESS

CONTROL.

™

Display shows

AL1

AL2

flashing during a repeat alarm.

•

Repeat if desired (up to a maximum of 6 times).

CANCELING THE ALARM COMPLETELY

•

Press 1

ALM

or 2

ALM

button once or more until

AL1

AL2

disappears.

DOCK

(See 4)

By connecting the iPod to your DC200, you can listen to the music stored

in iPod player through the powerful speakers of the set.

COMPATIBLE PORTABLE PLAYERS

•

Most Apple iPod models with 30-pin dock connector as follows:

iPod Touch 8GB, 16GB, iPod Photo 20GB/30GB/40GB/60GB, iPod

Video 30GB/60GB/80GB, iPod Classic 80GB/160GB, Mini and Nano.

DOCK ADAPTORS

Before plugging your player in the dock, snap the suitable dock adaptor

into the dock to provide a snug fit for the player to be docked.

Selecting the correct dock adaptor

• FortheiPoddock,4dockadaptorsofdifferenttype,asindicatedatthe

back of the adaptor, are included to fit the following iPod:

iPod Touch 4GB/8GB, 20GB, 40GB, iPod Photo

20GB/30GB/40GB/60GB, iPod Video 30GB/60GB/80GB, iPod Classic

80GB/160GB, Mini and Nano.

PLAYING iPod USING DC200

Remove the top cover of dock.

Snap the compatible iPod into the dock connector.

Press SOURCE repeatedly to switch on the iPod mode.

•

Make sure that you have powered on Apple iPod before selecting iPod

source.

™

On the DC200’s display, “iPod” is displayed when iPod is connected.

he connected iPod player will play automatically.

Notes:

–

By using the buttons ( 2;, ¡1, 2™ and VOLUME ) on the DC200, the follow-

ing playback features are available: Play/Pause, selecting next/previous track, fast

forwarding/rewinding and changing volume.

–

The buttons ( 2;, ¡1, 2™ and VOLUME ) on the DC200 can work only with

playback of the audio contents stored on the docked player.

– To navigate the iPod menu, you may use iPod MENU, 34 and OK buttons

on the set.

– When you press iPod MENU in iPod mode, 1234 and OK buttons first

perform the navigation function, and then restore the original functions.

– For iPod operations and features, refer to the user manual of your iPod player.

– This set does not support iPod video output.

Using USB connectivity

• DC200isfittedwithaUSBportonthetoppanel,offeringaplugandplay

feature which allows you to play, from your DC200, digital music and audio

contents stored on a USB mass storage device.

• UsingaUSBmassstoragedevice,youcanalsoenjoyallthefeaturesoffered

by DC200.

Compatible USB mass storage devices:

With the DC200, you can use
