Philips CD180 Manuale utente
Quick start guide
CD180
Important safety instructions
• Use only the power adapter listed in the technical data.
• Do not allow the product to come into contact with liquids.
• Risk of explosion if battery is replaced by an incorrect type.
• Dispose of used batteries according to the instructions. (Refer to the user manual online)
Overview
• Find handsets.
• Register additional
handsets.
Earpiece
Microphone
In call In idle mode In menu
MENU/OK Enter the option
menu
Enter the option
menu
Conrmselection
REDIAL/C Enter the redial list Enter the redial list Cancel operation
Increase the volume Enter the
phonebook
Scroll up
Decrease the
volume
Enter the call log Scroll down
Make and receive
calls
End calls Turn handset on/off
(press and hold)
Exit menu/operation
Mute/unmute the
microphone
RRecall key*
*network dependent
It displays the connection between
the handset and the base.The more
the bars are shown, the better the
connection is.
It indicates a received call in the call log.
It indicates an outgoing call in the
redial list.
Itasheswhenthereisanewmissed
call.
It remains steadily on when browsing
the missed calls in call log.
Itasheswhenreceivingincomingcall.
It remains steadily on during a call.
The ringer is off.
If you are using a voice mailbox from
yourprovider,thisiconasheswhen
there is a new message.
It remains steadily on when the voice
messages are already viewed in the
call log.
The icon is not shown when there is
no voice message.
* This is network dependent
It displays when you scroll up/down
a list or increase and decrease the
volume.
There are more digits on the right.
Press REDIAL/C to read.
Connect the base station
Telephone
socket
Power
socket
Power
adapter
Power
socket
Extra
handset
charger
Telephone
base station
2 1 3
1 Connect each end of the power adapter to:
• the DC input jack at the bottom of the base station;
• the power socket on the wall.
2 Connect each end of the line cord to:
• the telephone socket at the bottom of the base station;
• the telephone socket on the wall.
For multi-handset version only:
3 Connect each end of the power adapter to:
• the DC input jack at the bottom of the extra handset charger.
• the power socket on the wall.
1Connect
2Get started
Congure your phone
1 The batteries are pre-installed in the handset. Pull the battery tape off
from the battery door before charging.
2 Whenusingyourphoneforthersttime,youseeawelcome
message (country dependent).
After the welcome message, press MENU/OK.
3 Please set the country and language if prompted.
4 Set the date and time.
• If the time is in 12-hour format, press / key to select [AM] or
[PM].
Charge your phone
Charge 8 hours
Place the handset on the base station to charge the handset.When
the handset is placed correctly on the base station, you hear a docking
sound.
»The handset starts charging.
NoteChargethebatteriesfor8hoursbeforerstuse.
Check the battery level
When the handset is off the base station/charger, the bars
indicate the battery level (full, medium and low).
When the handset is on the base station/charger, the bars
ashuntilchargingcompletes.
Theemptybatteryiconashesandyouhearanalerttone.
The battery is low and needs recharging.
3Enjoy
Call
• To make a call, press and dial the
phone number.
• To answer a call, press when the
phone rings.
• To end a call, press .
Earpiece volume
Press or to adjust the volume
during a call.
Phonebook
Add record
1 Press MENU/OK, then select
[PHONEBOOK] > [ADD NEW],
then press MENU/OKtoconrm.
2 Enter the name, then press
MENU/OKtoconrm.
3 Enter the number, then press
MENU/OKtoconrm.
Call from the phonebook
1 Press or, press MENU/OK >
[PHONEBOOK] > [VIEW] to
access the phonebook list.
2 Select a contact.
3 Press to make the call.
Direct access memory
You have 2 direct access memories
(Keys 1 and 2).To dial the saved phone
number automatically, press and hold
on the keys in idle mode.
Depending on your country, Keys 1
and 2 are preset to [1_VOICEMAIL]
(voice mail number) and [2_INFO
SVC] (information service number)
of your network operator respectively
(network dependent).
Call log
1 Press and select a record.
To make a call
2 Press .
To view more details
2 Press MENU/OK.
3 Select [VIEW].
To save a call record to the
phonebook
2 Press MENU/OK.
3 Select [SAVE NUMBER].
4 Press MENU/OKtoconrm.
5 Enter the name.
6 Press MENU/OKtoconrm.
7 Press MENU/OK to save.
To delete a call record
2 Press MENU/OK.
3
Select
[DELETE]
or
[DELETE ALL]
.
4 Press MENU/OKtoconrm.
Redial list
1 Press REDIAL/C and select a record.
To make a call
2 Press .
To save a call record to the
phonebook
2 Press MENU/OK.
3 Select [SAVE NUMBER].
4 Press MENU/OKtoconrm.
5 Enter the name.
6 Press MENU/OKtoconrm.
7 Press MENU/OK to save.
To delete a call record
2 Press MENU/OK.
3
Select
[DELETE]
or
[DELETE ALL]
.
4 Press MENU/OKtoconrm.
Register the handsets
You can register additional handsets to
the base station.The base station can
register up to 4 handsets.
1 Press MENU/OK on the handset.
2 Select [SERVICES] > [REGISTER],
then press MENU/OKtoconrm.
3 Press and hold on the base
station for 5 seconds.
4
Enter the system PIN (0000).
5
Press
MENU/OKtoconrmthePIN.
»Registration is completed in less
than 2 minutes.
Technical data
Battery
• CORUN: 2 x AAA NiMH 1.2V Rechargeable 500mAh
batteries
• SANIK: 2 x AAA NiMH 1.2V Rechargeable 500mAh
batteries
Power adapter
Base and charger:
• Philips:
SSW-1920EU-2/SSW-1920UK-2/S003PV0600050/
S003PB0600050:
Input: 100-240V 50/60Hz 0.2A;
Output: 6V 500mA
Note Hereby Philips Consumer Lifestyle, declares that the
CD180 is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.You can
ndtheDeclarationofConformityonwww.p4c.philips.com.
Restore default settings
You can reset your phone settings to the original factory
settings.
1 Press MENU/OK.
2 Select [SERVICES] > [RESET], then press MENU/OK
toconrm.
»Thehandsetdisplaysaconrmationrequest.
3 Press MENU/OKtoconrm.
»All settings are reset
»The welcome screen displays.
