Philips CD280 Manuale utente

Quick start guide

CD280/CD285

Note

*In multi-handset packs, there

are additional handsets,

chargers and power adapters.

** In some countries, you have

to connect the line adapter to

the line cord, then plug the line

cord to the telephone socket.

Caution

• Use only the supplied batteries

and power adapter.

What’s in the box

Handset*

Base station (CD285) Base station (CD280)

Charger*Power adapter*Line cord**

User manual

Quick start guide

Guarantee

Connect the base station

Telephone

socket

Power

socket

Power

adapter

Power

socket

Extra

handset

charger

Telephone

base station

2 1 3

Connect each end of the power adapter to:

• the DC input jack at the bottom of the base station;

• the power socket on the wall.

Connect each end of the line cord to:

• the telephone socket at the bottom of the base station;

• the telephone socket on the wall.

For multi-handset version only:

Connect each end of the power adapter to:

• the DC input jack at the bottom of the extra handset charger.

• the power socket on the wall.

1Connect

2Get started

Congure your phone

The batteries are pre-installed in the handset. Pull the battery

tape off from the battery door before charging.

Whenusingyourphoneforthersttime,youseeawelcome

message (country dependent).

After the welcome message, press

[OK]

Please set the country and language if prompted.

Set the date and time.

• If the time is in 12-hour format, press / key to select

[AM]

[PM]

Charge your phone

Charge

8 hours

Place the handset on the base station to charge the handset.

When the handset is placed correctly on the base station, you

hear a docking sound.

»The handset starts charging.

NoteChargethebatteriesfor8hoursbeforerstuse.

Check the battery level

When the handset is off the base station/charger, the

bars indicate the battery level (full, medium and low).

When the handset is on the base station/charger, the

barsashuntilchargingcompletes.

Theemptybatteryiconashesandyouhearanalert

tone.

The battery is low and needs recharging.

3Enjoy

Call

• To make a call, press and dial the phone number.

• To answer a call, press when the phone rings.

• To end a call, press .

Adjust the earpiece volume

Press or to adjust the volume during a call.

Add a contact in the phonebook

Press

[Menu]

Select

[Phonebook]

[Add new]

, then press

[OK]

toconrm.

Enter the name then press

[OK]

toconrm.

Enter the number, then press

[Save]

toconrm.

Record an announcement

(for CD285 only)

Press

[Menu]

Select

[Answ. machine]

[Announcement]

, then

press

[OK]

toconrm.

Select

[Answer only]

[Record also]

, then press

[OK]

toconrm.

Select

[Record]

, then press

[OK]

toconrm.

Start recording close to the microphone after the beep.

Press

[OK]

to stop recording.

»You can listen to the newly recorded

announcement on the handset.

Listen to messages recorded on the answering machine (for CD285 only)

a Switch on/off the answering machine: Press .

b Start/Stop listening to the recorded messages: Press .

c Adjust the volume: Press / .

d Skip backward:

When you listen to the messages, press to listen to the

message from the beginning.

Duringtherstsecondofthecurrentmessage,press to listen

to the previous message.

e Skip forward: Press to skip to the next message.

f Delete the current message: Press .

Note For more information, see the Telephone answering machine

section in the user manual.

Need help?

User manual

Refer to the user manual that came with your new phone.

Online help

www.philips.com/support

Welcome to Philips

When this crossed-out wheeled bin symbol is attached to a

product it means that the product is covered by the European

Directive 2002/96/EC.

2014 © WOOX Innovations Limited.

Philips and the Philips’ Shield Emblem are registered trademarks

of Koninklijke Philips N.V. and are used by WOOX Innovations

Limited under license from Koninklijke Philips N.V.

QSG_CD280-285_GB_EN_V3.0

WK14034

0168
