)$?)&5?%.BOOK0AGE&RID AY$ECEMBER0-

8VHUPDQXDO

ΣΕ435_ΙΦΥ_ΕΝ.βοοκ Παγε 3 Φριδαψ, ∆εχεµβερ 16, 2005 1:15 ΠΜ

4 Important Information

4 For your safety

4 Installation requirements

4 Need Help?

5 What’s in the box?

6 Your ID937

6 Overview of the handset

9 Overview of the base station

9 Main features of your ID937

11 Connect

12 Install

16 Call

20 Phonebook

25 Call log

27 SMS

35 Clock & Alarm

37 Personal Settings

42 Advanced Settings

48 Network Services

51 Games

52 Telephone Answering Machine (TAM)

58 Troubleshooting

61 Information

62 Index

Contents

ID937_IFU_EN.book Page 3 Thursday, December 21, 2006 11:36 AM

EN Important Information

For your safety

This equipment is not designed to make emergency calls in the event of a power failure. Alternative

arrangements should be made for access to emergency calls.

To avoid damage or malfunction:

- Do not allow the product to come into contact with liquid.

- Do not open it as you could be exposed to high voltages.

- Never use any battery type other than the one supplied.

- Do not hold the handset too close to your ear when the phone is ringing or when activating the

loudspeaker as it may damage your hearing.

- Do not expose the phone to excessive heat caused by heating equipment or direct sunlight.

- Do not drop your phone or allow objects to fall on your phone.

- Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these may harm the set.

- Active mobile phones in the vicinity may cause interference.

About operating and storage temperatures:

- Operate in a place where temperature is always between 0 and 35º C (32 to 95º F).

- Store in a place where temperature is always between -20 and 45º C (-4 to 113º F).

- Battery life may be shortened in low temperature conditions.

Installation requirements

This product requires an electrical supply of 220-240 volts, alternating monophased power, excluding IT

installations defined in standard EN 60-950. In case of power failure, the communication can be lost.

The electrical network is classified as hazardous according to criteria in the standard EN 60-950. The only way

to power down this product is to unplug the power supply unit from the electrical outlet. Ensure the electrical

outlet is located close to the apparatus and is always easily accessible.

The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages), as defined in the

standard EN 60-950.

Need Help?

For more information on troubleshooting:

Troubleshooting: page 58

Please refer to the following website for more information on Philips web support:

Online Support

www.philips.com/support

ID937_IFU_EN.book Page 4 Thursday, December 21, 2006 11:36 AM

What’s in the box?

The following accessories are included with your ID937:

Power supply for

base station

Line cord

User Guide Warranty card

The line adaptor may not be attached to the line cord. In this case, you have to connect the line adaptor

to the line cord first before plugging the line cord to the line socket.

In multihandset packs, you will find one or more additional handsets, chargers with power supply units

and additional rechargeable batteries.

Handset Base station

Quick Start

Guide

2 AAA

rechargeable

batteries

Splitter

ID937_IFU_EN.book Page 5 Thursday, December 21, 2006 11:36 AM

EN Your ID937

Overview of the handset

LCD Screen

Talk key

Keypad lock key

Up/Down Navigation keys

Earpiece

Right Soft key

Hang-up key

Alphanumeric keypad

Case key / Pause key /

Ringer off key

Intercom key

Loudspeaker key

Event LED

(top of the handset)

Left Soft key

Microphone

ID937_IFU_EN.book Page 6 Thursday, December 21, 2006 11:36 AM

Your ID937

Handset keys

Soft key

Press To

mEnter the main menu from stand-by mode.

Select the function displayed on the handset screen directly above it.

Activate mute function during a call.

Switch on the backlight.

>Go to redial list from stand-by mode.

Select the function displayed on the handset screen directly above it.

Initiate a second call, consult phonebook, call transfer or activate/deactivate HD Sound

mode during a call.

Switch on the backlight.

rAnswer an incoming external or internal call.

Insert R for operator services when on the line.

eHang up a call.

Return to stand-by mode.

Long press in stand-by mode to switch off the handset, short press to switch on the handset

again.

uAccess call log from stand-by mode.

Scroll up a menu list or go to the previous phonebook or call log record.

Increase earpiece volume during a call.

Go to the previous character in editing mode.

dAccess phonebook from stand-by mode.

Scroll down a menu list or go to the next phonebook or call log record.

Decrease earpiece volume during a call.

Go to the next character in editing mode.

cInitiate an internal call.

vAnswer an incoming call in handsfree mode.

Activate and deactivate the loudspeaker* during a call.

#Dial # in stand-by mode.

Long press to mute the ringer in stand-by mode.

Long press to insert a pause in dialling mode.

Long press to switch between upper and lower case in editing mode.

*Dial * in stand-by mode.

Long press to activate and deactivate keypad lock.

BACK Short press from menu browsing to return to the previous menu.

*WARNING Handsfree activation can suddenly increase the volume in the earpiece to a very high

level. Make sure the handset is not too close to your ear.

(Left soft key)

(Right soft key)

ID937_IFU_EN.book Page 7 Thursday, December 21, 2006 11:36 AM

EN Your ID937

Display icons & symbols

In stand-by mode, several icons & symbols may be displayed on the top row of the handset screen.

When there are new events, such as new missed calls, new SMS, voicemail or answering machine messages

received, the following icons, together with the number of occurrences are displayed in the middle of the

handset screen.

The handset is registered and within range of the base station. It blinks when the handset is

out of range or is searching for a base.

Battery symbol indicating 3 different battery levels.

The ringer volume is set to zero.

The keypad is locked.

There is an external incoming call, an external call is connected or an external call is held.

HD Sound mode is activated.

There is an internal incoming call, an internal call is connected or an internal call is held.

The loudspeaker is ON.

Alarm clock is activated.

SMS reception is activated. It blinks when the memory for SMS is full.

Telephone answering machine (TAM) is activated. It blinks when the memory for answer-

ing machine messages is full.

Do not Disturb mode is activated.

There are new SMS messages received. The number of new SMS messages received is

also displayed on the left of the icon.

There are new missed calls. The number of new missed calls is also displayed on the left of

the icon.

There are new voicemail messages received. The number of new voicemail messages

received is also displayed on the left of the icon.

There are new answering machine messages received. The number of new messages

received is also displayed on the left of the icon.

If you have not subscribed to Caller Line Identification service, there will not be any alerts for the

new events except for new messages recorded on the answering machine. Hence, no missed call,

SMS, or voicemail event icons will appear in the middle of the handset screen.

ID937_IFU_EN.book Page 8 Thursday, December 21, 2006 11:36 AM

Your ID937

Overview of the base station

Main features of your ID937

The following is an overview of the menu options that are available in your ID937. For detailed explanation of

the menu options, please refer to the corresponding sections in this User Guide.

Menu To Page

SMS Setup, write/read SMS, etc. 27

PHONEBOOK Add, edit, manage phonebook entries and copy phonebook

entries from SIM card.

CLOCK &

ALARM

Set date and time, alarm, alarm tone and Do not Disturb

mode.

PERSONAL SET Set Handset tone, Wallpaper, Contrast, Handset name, Auto

Pick-up/Hang-up, Languages, Babysit mode, Backlight time and

Theme Colour.

ADVANCED

SET

Set Recall time, Dial mode, Call barring, Baby call mode,

phone, Auto prefix, Conference mode, HD Sound and Demo

mode.

NET. SERVICE Set Call forwarding, Voice mail, Call back and Caller ID. 48

GAMES Play games 51

ANSWER

MACHINE

Setup, play, delete phone messages, record memo, etc. 52

Paging key

SIM card cover

ID937_IFU_EN.book Page 9 Thursday, December 21, 2006 11:36 AM

EN Your ID937

Menu navigation

The basic steps of navigating through the menus and options are as follows:

Task Action Illustration

Enter main menu/menu options Choose MENU by pressing the key

directly below it (left soft key

• Go to a specific menu/option

• Confirm your selection

1. Press :key to scroll to your

desired menu/option

2. Choose SELECT by pressing

the key directly below it (left

soft key m)

In this example, the alarm is On

Once.

• To change your selection

• To confirm your selection

• Return to previous menu level

or stand-by screen

1. Press :key to scroll to your

desired option

2. Choose SELECT by pressing

the key directly below it (left

soft key m)

3. Choose BACK by pressing the

key directly below it (right soft

key >)

Philips 1

08-08 18:00

MENU REDIAL

Off

On Once

On Daily

SELECT BACK

Alarm





ID937_IFU_EN.book Page 10 Thursday, December 21, 2006 11:36 AM
