Philips 21HT3411Z Manuale utente
Philips
professional TV
53 cm (21")
real flat
21HT3411Z
SmartLoader Real Flat TV
with Advanced Hotel Mode
This specially designed TV offers a dynamic picture and sound performance with the best
in class Advanced Hotel Mode features aimed at maximising management efficiency while
guaranteeing the perfect convenience for guests.
Best total cost of ownership
• Wireless SmartLoader for fast cloning
• Installation menu locking
• Front Controls Locking
• ESP™ (Energy Savings Programmability)
• Battery Low Detection for Remote Control
• External loudspeaker connector
• Consumer TV Convertible
Maximum guest comfort
• Welcome message on screen display
• Volume limitation
• Switch On Channel Programming
Great viewing experience and guest comfort
• Real Flat picture tube technology brings you lifelike images
21HT3411Z/93
Highlights
Professional TV
53 cm (21") real flat
Wireless SmartLoader
Provides the ability to copy easy and wireless
all programmming settings from one TV set
into other TV sets in less then a minute. The
feature ensures uniformity between TV sets
and significantly reduces installation time and
costs.
Installation menu locking
Prevents unauthorized access to installation
and configuration settings, to ensure maximum
guest convenience and avoid unnecessary
reprogramming costs.
Front Controls Locking
Prevents unauthorised access to TV functions
ESP™
Feature can be selected in the set-up menu.
The TV can be switched off automatically after
a specified period of use saving energy and
provide extended product life time. The
selectable range is from 0 to 99 hours.
Battery Low Detection
This feature informs of the need to replace the
remote control batteries preventing nuisance
calls and unneccessary replacement of
batteries.
External loudspeaker connector
Amplified audio connector for easy installation
of external speakers (like for bathrooms),
eliminating the need for investments in
external equipment
Consumer TV Convertible
Easily converts the TV from Commercial
operation to Consumer settings for after-
market sales.
Welcome message
A welcome greeting is displayed each time the
TV set is switched on.
Volume limitation
This feature predefines the volume range with
which the TV set is allowed to operate,
preventing excessive volume adjustments and
avoiding disturbance of next door guests.
Switch On Channel Programming
Perfect for in-house advertising or information
channels as it allows to show a predefined
channel when the TV is turned on.
Real Flat picture tube
The flatter tube provides a wider viewing angle
while minimizing reflections for the best
picture possible.
Issue date 2011-06-07
Version: 1.0.5
12 NC: 8670 000 24023
EAN: 87 10895 95247 7
© 2011 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
21HT3411Z/93
Specifications
Professional TV
53 cm (21") real flat
Picture/Display
• Display screen type: Real Flat picture tube
• Diagonal screen size: 21 inch / 53 cm
• Aspect ratio: 4:3
• Picture processing: 50 Hz
Sound
• Output power (RMS): 2 x 3W
•SoundSystem:Mono
• Sound Enhancement: Auto Volume Leveller
Loudspeakers
• Built-in speakers: 2
Tuner/Reception/Transmission
• Tuner bands: UVSH
• TV system: PAL B/G, PAL D/K, PAL I, SECAM B/G,
SECAM D/K, NTSC
• Video Playback: PAL, SECAM, NTSC
• Aerial Input: 75 ohm coaxial (IEC75)
• Number of Preset Channels: 125
Connectivity
• AV 1: CVBS in, Audio L/R in
• AV 2: CVBS, Y/C, Audio L/R in
• Other connections: Monitor out
Convenience
• Ease of Installation: Automatic Tuning System
(ATS), Fine Tuning, Cloning of TV settings,
Advanced Hotel Mode, Program Name
• Ease of Use: Smart Picture
• On-Screen Display languages: English, Malay,
Simplified Chinese
• Comfort: Hotel Guest features
• Clock: On main display, Sleep Timer
• Remote Control: TV
• Remote control type: RC2887
Power
• Mains power: AC 220V, 50/60Hz
• Power consumption: Normal Operation 78 (+/-
10%) W
Dimensions
• Set weight: 23.5 kg
• Weight incl. Packaging: 27 kg
• Set dimensions (W x H x D): 478 x 470 x 532 mm
•Boxdimensions(Wx H x D):
578x 570 x 628 mm
Accessories
• Included accessories: Remote Control, Batteries
for remote control
• Optional accessories: Set up Remote RC2573GR,
Wireless SmartLoader 22AV1120
•
