Philips KEY010/00 Manuale utente
user manual
manuel d’utilisation | benutzerhandbuch | manual del usuario
gebruikershandleiding | manuale per l'utente | manual do usuário
användar-handbok
wearable digital camera
key10 manual cover 1 2/2/04 15:54 Page 1
System requirements:
Système requise:
Systemanforderungen:
Requisitos sistema:
Systeemvereisten:
Requisiti del sistema:
Requisitos do sistema:
System krav:
· Windows 98SE / 2000 / ME / XP
· Mac OS9 and 10
key10 manual cover 1 2/2/04 15:54 Page 2
We hope you enjoy your wearable digital camera
Please visit:
www.philips.com/support
and enter your product name to view:
· FAQ, Frequently Asked Questions
· Latest user manuals
· Latest PC software downloads
The model and production numbers can be found next to the USB port
(please remove the USB cover to see)
1
ENGLISH 1
FRANÇAIS 13
DEUTSCH 25
CONTENTS
ESPAÑOL 35
NEDERLANDS 45
ITALIANO 55
PORTUGUÊS 65
SVENSKA 75
key10_eng .qxd 28/1/04 15:17 Page 1
2
key10_eng .qxd 28/1/04 15:17 Page 2
Name of parts
1Shutter button:tests light, memory capacity and power conditions and takes pictures
2Strap hole: attaches supplied neck strap
3Viewfinder:frames picture subject
4Lens
5Lens cap and Power On / Off dial:protects lens and switches camera on / off
6Grip: positions thumb to power on / off
7USB port: connects to PC
8USB cover: protects USB port
9Light level indicator: provides light information
0Power level indicator:provides battery information
!Memory capacity level indicator: provides memory capacity information
3
ENGLISH
key10_eng .qxd 28/1/04 15:17 Page 3
IMPORTANT!
WINDOWS 98SE users:
DO NOT CONNECT your camera to the PC BEFORE driver installation. Please insert
the by-packed CD into your CDROM drive and follow on screen instructions to complete
driver and software installation.
MAC users:
DO NOT CONNECT your camera to your keyboard's USB port. It doesn't have sufficient
power to detect your camera.
4
Preparation
Attaching the neck strap
Thread the neck strap through the hole as shown in the picture.
Your camera has a built-in USB rechargeable battery. To charge
your camera, switch on your computer. Detach the USB cover.
Connect your camera to your computer's USB port. Charge
your camera until the POWER indicator lights up and stop
blinking (approximately 4 hours).
Power Supply
key10_eng .qxd 28/1/04 15:17 Page 4
➔
5
ENGLISH
Taking pictures
Turn Power on / off dial clockwise to power ON.
Hold the camera upright in your hand.
Make sure the lens is not obstructed / covered when you take pictures.
Look through the viewfinder to frame your subject.
Keep the camera steady and press the shutter halfway down to
test picture conditions.
For best results, check the status of all 3 indicators on the camera
when you take a picture. (See Indicators on your Camera, page 6)
Press the shutter button fully down to take your pictures.Your
camera beeps after you take a picture.
TIP
Your camera automatically powers off if there is no operation within 60
seconds.Turn the Power on / off dial anti-clockwise to power OFF and
clockwise to power ON again.
key10_eng .qxd 28/1/04 15:17 Page 5
Indicators on your camera
Your camera tells you various information by LEDs and beeps:
6
User action Signal Meaning
USB Connection Double beep Camera charging
Green LED blinks Camera charging
Green LED on Camera fully charged
Powering on Double beep Camera on
All LEDs blink Wrong file format detected. Camera will
auto format and be ready for use in 5
seconds. (See page 7 for more information)
Taking picture Single beep Picture taken
(Lighting level) Red LED blinks External light low
Red LED on External light too dark
(Battery level) Green LED on Battery full
Green LED blinks Battery low
Green LED off Insufficient battery
(Memory capacity level) Yellow LED on Sufficient camera memory capacity for
new pictures
Yellow LED blinks Almost insufficient camera memory
capacity for new pictures
Yellow LED off Insufficient camera memory capacity for new
pictures
key10_eng .qxd 28/1/04 15:17 Page 6
USB Connection
Using your camera as a mass storage
You can use your camera as a mass storage for any data files. Your camera will appear as a
new USB mass storage in Windows Explorer on PC or Finder on Mac when USB connected.
Viewing your pictures
Connect your camera to your computer's USB port. From Windows Explorer or Finder,
click on the mass storage folder and then the DCIM folder. You can view your pictures from
the subfolder 100PHDSC.
Transferring files and pictures
Click and highlight one or more files or pictures to transfer between your camera and your
computer. Use drag and drop actions to complete your transfer.
Disconnect camera safely from your PC by clicking on the task bar to avoid file error.
(WINDOWS 98SE users: there is no icon. Simply disconnect camera after file transfer
completes. MAC users: drag and drop to .)
Formatting your camera
Only format your camera with FAT16 file system.Your camera will auto-format during power
ON when wrong file system is used. Data files and pictures saved on your camera will be
erased after auto-format.
IMPORTANT! RETAINYOUR ORIGINAL FILES!
Please ensure that you retain the original files transferred to your camera. Philips is not
responsible for any loss of content in the case if the product becomes damaged or the mass
storage not readable.
7
ENGLISH
key10_eng .qxd 28/1/04 15:17 Page 7
Troubleshooting
If a fault occurs,first check the points listed. For further help and other troubleshooting
tips, please also check out FAQ for your camera at www.philips.com/support. If you are
unable to find a solution from these hints, consult your dealer or service center.
WARNING:
Under no circumstances should you try to repair the set yourself, as this will invalidate the
warranty.
8
Problem Cause Solution
Cannot take picture Battery drained Charge the battery (see step 1, page 2)
Insufficient camera Copy pictures from your camera to your
memory capacity computer and delete the original to free up
memory space for more new pictures.
(see page 7)
Poor light condition Check light conditions
USB doesn't work Loose connection Check connection
Wrong OS version Your operation system must be later than
Windows 98 or Mac OS 9
USB driver not installed Windows 98 user only: install the USB
driver provided in by-packed CD
Camera connected Connect your camera to another USB
to Mac keyboard port
key10_eng .qxd 28/1/04 15:17 Page 8
