Philips 7FF1CME Manuale utente
User manual
Manuel d’utilisation | Benutzerhandbuch | Manual del usuario
Gebruikershandleiding | Manuale per l'utent | Manual do usuário
Användar-handbok
7FF1PhotoFrame™
Modern
Classic
7FF1M4
7FF1CME 7FF1CWO 7FF1CMI
•
Packing list
•Initial setup
•Specification
Getting started
Packing List
Digital PhotoFrame™ PhotoFrame™ Stand
Quick start guide User manual CD
Power adaptor
USB Cable to PC
(male A type plug)
What else you'll need
Power outlet Digital Photos, memory card or PC
RETURN TO TOP OF THE PAGE
©2005 Koninklijke Philips Electronics NV
A
ll rights reserved. Reproduction, copying, use, modification, hiring, renting, public performance,
transmission and/or broadcasting in whole or in part is prohibited without written consent of Philips
Electronics NV
•
Packing list
•Initial setup
•Specification
Getting started
Initial setup
Philips digital PhotoFrame™ can be placed either vertically or horizontally to
fit the photos on display. Its internal rechargeable battery provides you the
freedom to pass it around and show photos without the power cord. Or, you
can place it somewhere in the room for constant PhotoFrame™ by connecting
it to the main.
A. Removing the protective bag/film on parts
B. Attaching the PhotoFrame™ stand
•Place head of stand into socket
•Rotate clockwise until stand locks in-place
C. Connecting to a power source
•
Connect the supplied power cable from PhotoFrame™ to a power outlet .
The internal battery will start charging and the battery LED turn orange.
Locate control keys
•Use your PhotoFrame™ by pressing the control keys in the back.
RETURN TO TOP OF THE PAGE
•LCD display also shows the function icon for each key at the same position.
Previous/Left Switch view Setup
Next/ Right Show/ Hide icon Photo setting
Up Copy Confirm
Down Delete Escape
C. Turning on PhotoFrame™
•Slide the power switch up to the ON position.
The power LED will be green and the Startup screen will appear.
D. Choose your preferred language
•Press the key (the 3rd key from the left on the rear of PhotoFrame™)
A menu with general settings for PhotoFrame™ will appear.
•Use the or key to highlight Language and press the key to
select.
•Use the or key to choose your preferred language. Press to
confirm your selection. The new setting will be effective immediately.
•Press again to leave the Language menu.
•Packing list
•Initial setup
•Specification
Getting started
Specification
Picture/Display
-Effective display area: 137 x 91 mm (5.4" x 3.6"), 6.5" diagonal
-Vertical dot pitch: 0.1905 mm
-Horizontal dot pitch: 0.1905 mm
-Resolution: 720 x 480 pixels
-Brightness: 200 nits
-Viewing angle (CR>5): Horizontal (-85°~85°), Vertical (-85°~85°)
-Backlight Half-Life time: 20,000 hours
Connectivity
- Card reader: Built-in Secure digital (SD), Multimedia card (MMC), Memory stick
(MS, MS Pro), Compact flash (CF) type I only.
Convenience
Photo format supported: Up to 12M pixels, JPEG photos following EXIF and DCF
standards
Memory size: 50 photos or more
Placement supported: Landscape, Portrait
Control buttons: 6 buttons
Display mode Automatic slideshow, Full-Screen browse, Thumbnail browse
Setup menu:
Photo menu:
OSD languages: English, French, German, Italian, Spanish, Simplified Chinese,
Russian, Japanese
Plug & Play compatibility: Windows 2000/XP or later, Mac OS X or later, Linux
Accessories
- Included accessories: AC power adaptor (AC 100~240V 50/60 Hz 0.36A-->DC 5V
2.5A), USB cables, Quick start guide
- User manual: Yes (in CD-ROM)
Power
- Power LED indicator Green (power on), Off (power off)
- Battery LED indicator Orange (charging), Off (not charging)
- Power mode supported Battery powered, AC powered
RETURN TO TOP OF THE PAGE
•Viewing
photos
•
Copying
photos
•Viewing
slideshows
•Deleting
and
Rotating
photos
Enjoying photos
Viewing Photos
When there is no memory card in PhotoFrame™, it displays photos stored in local memory.
When a memory card is inserted to PhotoFrame™, it will display photos from most recently
connected media in a "Last-in, First-display" order.
You can choose from three PhotoFrame™ viewing modes. Press ( the 1st key
from the left on the rear of PhotoFrame™) to toggle among the three viewing
modes; use to view the previous photo and to view the next photo. ( and
are the first two keys from the right on the rear of PhotoFrame™. )
THUMBNAIL-List of photos.
AEach icon represents the function of the corresponding
key in the rear of PhotoFrame™.
BSource of photos on screen
Memory stick Compact flash
SD, MMC PhotoFrame™
CCurrent Photo
DCurrent Photo number
ESlideshow icon
(If shown, this photo will be shown in slideshow.)
FCurrent photo number, same as D
GTotal photo count
HResolution of current photo (in pixels).
IDate current photo was taken
JSource of displayed photos.
SLIDESHOW- Automatic, Rotating display of photos.
BROWSE—Manual viewing of photos one-by-one. (Displays size and date)
Each icon represents the function of the corresponding key in the rear of PhotoFrame™.
AEach icon represents the function of the corresponding
key in the rear of PhotoFrame™.
BSource of photos on screen
Memory stick Compact flash
SD, MMC PhotoFrame™
CCurrent Photo number
D
Total photo count
EResolution of current photo (in pixels)
FDate current photo was taken
Viewing photos on PhotoFrame™
•Remove any memory card from PhotoFrame™.
Photos stored in the PhotoFrame™ will appear.
Viewing digital camera photos from a memory card
•Insert the memory card into the slot in the frame:
•For Compact Flash card, firmly slide card in the larger slot end first and face DOWN.
•For SD, MMC, or Memory Stick card, slide card in the smaller slot end first and face UP
until it locks in-place.
After a few seconds photos on the memory card will display.
How to remove a memory card:
•To remove Compact Flash card, pull out the card slowly.
•To remove SD, MMC, or Memory Stick card, push the card again to unlock and then pull
out the card.
RETURN TO TOP OF THE PAGE
