Philips SPF5010/75 Manuale utente

PhotoFrame

Get started

Play

Setup

SPF5008

SPF5208

SPF5010

SPF5210

SPF7008

SPF7208

SPF7010

SPF7210

Quick start guide

What you also need

What’s in the box

Philips Digital PhotoFrame

AC power socket

AC-DC power adaptor

Memory card / USB

Stand

Computer

CD-ROM, including

• Digital User Manual

• (SPF7008/SPF7208/

SPF7010/SPF7210) Philips

PhotoFrame Manager

(Software and User

Manual)

USB cable

(not supplied to

SPF5010/SPF5210)

Quick Start Guide

Quick start guide

SPH8008

SPF2107

SPA2007

Connect

Install

Enjoy

Eng

PhotoFrame

Install the stand

1 Insert the stand into the PhotoFrame.

2 Position the indication on the stand to the

position.

3 (SPF5008/SPF5208) Turn the stand anti-

clockwise 45 degrees to the position and

lock it to the PhotoFrame ﬁrmly.

(• SPF5010/SPF5210/SPF7008/SPF7208/

SPF7010/SPF7210) Turn the stand clockwise

45 degrees to the position and lock it to the

PhotoFrame ﬁrmly.

1 Get started

Control buttons

Turn on/off the PhotoFrame•

Access the home screen•

Access the quick menu•

Access option menu•

d Zoom in/out

•

Zoom in an image

Switch modes: Album mode →thumbnail

mode →slideshow mode →zoom in 2

times →zoom in 4 times

•

Zoom out an image

Switch modes: Album mode ←thumbnail

mode ←slideshow mode ←zoom out 2

times ←zoom out 4 times

e Up/down slider

Scroll up/down at high speed

•

Select the upper item

Increase the volume

•

Select the item below

Decrease the volume

f OK

Display slideshow

•

Play/Pause slideshow/video•

Conﬁrm a selection•

g Left/right slider

Scroll left/right at high speed

•

Select the left item

•

Select the right item

For other times when the on screen language is

selected:

1 Press and hold for more than 1 second.

The home screen is displayed.»

To turn off the PhotoFrame, press and hold

•

for about 2 seconds.

Transfer photos/music or video

ﬁles from an SD card

Caution

Do not remove a storage device from the PhotoFrame•

when ﬁles are transferring from or to the storage

device.

For details on other applicable storage device, refer to

the User Manual of your PhotoFrame in the supplied

CD-ROM.

1 Insert an SD card or other storage device into

the PhotoFrame ﬁrmly.

SPF5008/SPF5208•

Connect power

1 Connect the supplied power cord to the DC

socket of the PhotoFrame.

• SPF5008/SPF5208

• SPF5010/SFP5210/SPF7008/SPF7208/

SPF7010/SPF7210

2 Connect the power cord to a power supply

socket.

Turn on/off the PhotoFrame

Note

You can only turn off the PhotoFrame after all copy•

and save actions are complete.

For the ﬁrst time use:

1 Press and hold for more than 1 second.

The language selection menu is displayed.»

2 Select a language, and then tap OK to conﬁrm.

The home screen is displayed.»

Transfer by Philips PhotoFrame

Manager (SPF7008/SPF7208/

SPF7010/SPF7210)

Recommended way for SPF7008/SPF7208/

SPF7010/SPF7210.

Caution

Do not disconnect the PhotoFrame from the PC when•

ﬁles are transferring between the PhotoFrame and

the PC.

Note

Ensure that Philips PhotoFrame Manager is installed•

on your PC.

1 Connect the supplied USB cable to the

PhotoFrame and to a PC.

Philips PhotoFrame Manager starts»

automatically.

SPF5010/SPF5210/SPF7008/SPF7208/•

SPF7010/SPF7210

An option menu is displayed.•

2 Select [Transfer], and then tap OK to conﬁrm.

A conﬁrmation message is displayed.»

3 To select all photos or video/music ﬁles, select

[Yes] and then tap OK to conﬁrm.

To select some of photos or video/•

music ﬁles, select [No] and then tap OK

to conﬁrm. Tap / / / and OK

to select photos or video/music ﬁles,

and then tap to continue the transfer

operation.

4 Select a destination album on the PhotoFrame,

and then tap OK to conﬁrm.

Photos/video ﬁles are transferred to the»

PhotoFrame.

To remove a storage device, pull it out from

•

the PhotoFrame.

2 Select [Transfer Photos] / [Tranfer Music] /

[Transfer Video].

3 Under [My frame photos] / [My frame music] /

[My frame videos], select a destination album/

folder.

4 Under [My computer photos] / [My computer

music] / [My computer videos], select photos

or video/music ﬁles.

5 Click the icon to start transfer.

6 After all transfer actions are complete,

disconnect the USB cable from the PC and the

PhotoFrame.

Tip

If Philips PhotoFrame Manager does not start•

automatically, you can double click its icon on the

desktop of your PC to start it.

You can also drag and drop photos from the

•

PhotoFrame to a PC.

2 Play

Browse photos/video ﬁles in

album mode

1 In the home screen, select [Browse] and then

tap OK to conﬁrm.

Photos/video ﬁles are displayed in album»

mode.

2 Select an album, and then tap to access the

album.

3 Tap / / / to browse photos/video ﬁles in

the album.

Tip

If you select an album and then tap• OK, photos/video

ﬁles in the selected album are displayed in slideshow.

Play photos/video ﬁles

Note

With the PhotoFrame, you can play JPEG/progressive•

JPEG photos and most video clips of a digital still

camera in M-JPEG (*.avi/*.mov), MPEG-1 (*.mpg),

MPEG-4 (*.avi/*.mov/*.mp4), H.263 (*.avi/*.mov)

format. Some video clips might have compatibility

issues when played on your PhotoFrame. Before

playing, ensure that these video clips are compatible

with your PhotoFrame.

Some video clips in a format which is not compatible

•

well with your PhotoFrame, like *.3gp/*.3g2 and some

others, may be played with no audio output. When a

video clip is played with no audio output, the icon is

displayed on the screen.

In album/thumbnail/ﬁlmstrip mode, a video ﬁle is

•

displayed with the icon on the left top corner.

1 In the home screen, select [Play] and then tap

OK to conﬁrm.

Photos/video ﬁles are displayed in slideshow»

mode.

During play:

To view the album in which the slideshow

•

image/video is saved, tap twice.

To adjust volume, tap• /

To pause/resume play, tap• OK.

To play the previous/next ﬁle, tap• / .

Play background music

Note

Only MP3 (MPEG Audio Layer III) music ﬁles can be•

played on the PhotoFrame.

1 During photo display, tap .

An option menu is displayed.»

2 Tap repeatedly to select [Play Background

Music], and then tap OK to conﬁrm.

3 Select [Set Music], and then tap OK to

conﬁrm.

4 Select a folder.

5 To play all music ﬁles in the folder, tap OK to

conﬁrm.

To play a single music ﬁle, tap• to access

the folder, select a music ﬁle, and then

tap OK to conﬁrm.

If you have set music before:

In• [Play Background Music] menu, select

[Turn On] and then tap OK to conﬁrm.

Selected music ﬁles are played.•

To stop music play:

In• [Play Background Music] menu, select

[Turn Off] and then tap OK to conﬁrm.

Tip

After a music ﬁle is selected, you can tap• to access

the option menu to copy/delete it.

Display a theme clock (SPF5008/

SPF5208/SPF7008/SPF7208/

SPF7010/SPF7210)

Note

Ensure that you have installed a theme clock in your•

PhotoFrame.

You can also download latest theme clocks from www.

•

philips.com/support, in the coming future.

1 In the home screen, select [Theme Clock] and

then tap OK to conﬁrm.

2 Select [Show Current], and then tap OK to

conﬁrm.

To select and install another theme clock:

1 Download a theme clock and save it in an SD

card before you install it.

2 Insert the SD card into the PhotoFrame.

3 In [Theme Clock] menu, select [Select Other]

and then tap OK to conﬁrm.

4 Select a theme clock, and then tap OK to

conﬁrm.

After the theme clock is installed, it is»

displayed automatically.

3 Setup

Bluetooth (SPF7008/SPF7208/

SPF7010/SPF7210)

Note

Bluetooth connectivity is available only on SPF7008/•

SPF7208/SPF7010/SPF7210.

Set up Bluetooth connection

With the PhotoFrame, you can set up Bluetooth

connection with a device like a mobile phone. Once a

device is recognized, it is automatically accepted when

it tries to connect with the PhotoFrame.

1 In the home screen, select [Settings] and then

tap OK to conﬁrm.

2 Select [Bluetooth], and then tap OK to

conﬁrm.

3 Select [Setup], and then tap OK to conﬁrm.

4 Select [Bluetooth On], and then tap OK to

conﬁrm.

To set off• Bluetooth connection, select

[Bluetooth Off] and then tap OK to

conﬁrm.

Tip

If• Bluetooth connection on your PhotoFrame is

enabled, the Bluetooth icon is displayed on the top-

right corner of the screen.

Photos obtained via

• Bluetooth connection are saved

in the Bluetooth album. You can access or manage the

Bluetooth album the same way you access or manage

other albums on the PhotoFrame.

Set Bluetooth pin code

To keep security, you can set a pin code (from 1 to

16 digits) on the PhotoFrame.The default pin code

is 0000.

1 In the home screen, select [Settings] and then

tap OK to conﬁrm.

2 Select [Bluetooth], and then tap OK to

conﬁrm.

3 Select [Security], and then tap OK to conﬁrm.

4 Select [Pin Code], and then tap OK to

conﬁrm.

A key pad is displayed.»

5 Select a number, and then tap OK to conﬁrm.

6 Repeat Step 5 until the pin code is complete.

7 Select [Enter], and then tap OK to conﬁrm.

8 To set the pin code on, select [Pin Code On]

and then tap OK to conﬁrm.

To set the pin code off, select

• [Pin Code

Off] and then tap OK to conﬁrm.

Send photos via Bluetooth

connection by your mobile

phone

Note

Ensure that• Bluetooth connection on your mobile

phone is enabled.

Ensure that

• Bluetooth connection on your

PhotoFrame is enabled.

Detailed operation procedure may vary based on

•

different mobile phones.

On your mobile phone:

1 Select photos to be sent to the PhotoFrame.

2 Select [Send] > [Bluetooth], and then conﬁrm

the selection.

Your Philips PhotoFrame is searched.»

3 If a pin code is required, enter the pin code

(0000 by default ) of the PhotoFrame.

4 Select [Send], and then conﬁrm the selection.

Selected photos are sent to and saved in»

the Bluetooth album on the PhotoFrame.

Altri manuali per SPF5010/75

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Philips Cornice digitale

Philips

Philips SPF1207/10 Manuale utente

Philips

Philips 10FF3CMI Manuale utente

Philips

Philips 10FF3CDW Manuale utente

Philips

Philips 9FF2CME - annexe 2 Manuale utente

Philips

Philips 10FF2CMW/27 Manuale utente

Philips

Philips 7FF1M4 Manuale utente

Philips

Philips SPF2527/93 Manuale utente

Philips

Philips SPF7208 Manuale utente

Philips

Philips SPH8208/12 Manuale utente

Philips

Philips SPF1137/93 Manuale utente

Philips

Philips 7FF1WD/05 Manuale utente

Philips

Philips SPF4308 Manuale utente

Philips

Philips SPF1528/05 Manuale utente

Philips

Philips 10FF2 Series Manuale di installazione e funzionamento

Philips

Philips SPF2017 Manuale utente

Philips

Philips SPF2007/12 Manuale utente

Philips

Philips SPF3400/G7 Manuale utente

Philips

Philips 8FF3FPB Manuale utente

Philips

Philips SPF2007 Manuale utente

Philips

Philips Home Essentials SPF3480X Manuale utente

Philips

Philips SPF1207/77 Manuale utente

Philips

Philips SPF3410/G7 Manuale utente

Philips

Philips SPF1207/77 Manuale utente

Philips

Philips 7FF2M4/27 Manuale utente

Manuali Cornice digitale popolari di altre marche

LENCO

LENCO DF-830 Manuale utente

NIX

NIX Advance X10G Manuale utente

Nextar

Nextar N7S-100 Manuale utente

Sungale

Sungale TD350A Manuale utente

texet

texet DPF-830 Istruzioni per il montaggio

Digital Spectrum

Digital Spectrum MemoryVue MV-1500 Manuale utente

ViewSonic

ViewSonic VFM1042-52 Manuale utente

YURAKU

YURAKU YUR.PHOTO 7B4C Manuale utente

Denver

Denver PFF-710WHITE MK2 Manuale utente

Pandigital

Pandigital PAN8000DWPCF1 Manuale utente

Rekam

Rekam Deja View HD-850 Manuale utente

Majestic

Majestic DF 918HD MP3 Manuale utente

ViewSonic

ViewSonic DPF8-CAM Manuale utente

Digital Foci

Digital Foci Image Moments IMT-063 Manuale utente

Nokia

Nokia SU-4 Manuale utente

Hama

Hama 118564 Manuale utente

Sungale

Sungale CD352LD Manuale utente

Kodak

Kodak W1020 - GUIA COMPLETO DO USUÁRIO FOR FIRMWARE VERSIONS EARLIER THAN... Manuale utente
