AJB7038D

www.philips.com/welcome

User manual

2EN

Contents

1 Important 3

Safety 3

2 Your DAB Docking System 4

Introduction 4

What's in the box 4

Overview of the main unit 4

3 Get started 6

Prepare FM/DAB antenna 6

Connect power 6

Turn on 7

Set time 7

4 Play from iPod/iPhone 7

Compatible iPod/iPhone 7

Listen to audio from iPod/iPhone 7

Charge the iPod/iPhone 8

Adjust volume 8

Remove the iPod/iPhone 8

5 Listen to DAB radio 8

Tune to DAB radio stations 8

Scan DAB radio stations automatically 9

Store DAB radio stations manually 9

Select a preset DAB radio station 9

Display DAB information 9

Use DAB menu 9

6 Listen to FM radio 10

Tune to FM radio stations 10

Scan FM radio stations automatically 10

Store FM radio stations manually 10

Select a preset FM radio station 11

Display RDS information 11

Use FM menu 11

7 Other features 12

Set alarm timer 12

Set sleep timer 12

Play from an external device 12

Adjust display brightness 13

8 Product information 13

Specications 13

9 Troubleshooting 14

10 Notice 15

3EN

1 Important

Safety

• Heed all warnings.

• Follow all instructions.

• Do not use the device near water.

• Clean only with dry cloth.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or other

devices(includingampliers)thatproduce

heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the device.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Unplug the device during lightning storms

or when unused for long periods of time.

• Referallservicingtoqualiedservice

personnel. Servicing is required when the

device has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the device, the device has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• The device shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on

thedevice(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this device.

•Never lubricate any part of this device.

•Never place this device on other electrical equipment.

•Keep this device away from direct sunlight, naked

amesorheat.

•Toreducetheriskofreorelectricshock,donot

expose this device to rain or moisture.

•Ensure that you always have easy access to the power

cord, plug or adapter to disconnect this device from

the power.

4EN

2 Your DAB

Docking System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Introduction

With this device, you can:

• listen to FM/DAB radio;

• enjoy audio from iPod/iPhone or an

external device;

• know the time;

• be waken up by buzzer alarm, DAB/FM

radio, or audio in iPod/iPhone.

What's in the box

Check and identify the contents of your

package:

• Main unit

• 2xchangeableplugs(EU&UK)

• User Manual

Overview of the main unit

5EN

a TUNING /

• Tune to an FM/DAB radio station.

• Set time.

b SLEEP

• Set sleep timer.

c AL1/AL2

• Set alarm.

• Activate/deactivate alarm timer.

d SNOOZE/BRIGHTNESS

• Snooze alarm.

• Adjust display brightness.

e Display panel

• Show current status.

f PRESET +/-

• Select a preset radio station.

g SELECT

• Select an option.

h Dock for iPod/iPhone

i VOL

• Adjust volume.

j SOURCE

• Switch the device to standby mode.

• Select a source: iPod/iPhone, DAB/FM

tuner, or MP3 link.

k INFO/MENU

• Display DAB or RDS information, and

enter into DAB/FM menu.

6EN

l PROG/AUTOSCAN

• Program radio stations.

m FM ANTENNA

• Improve FM reception.

n MP3 LINK

• Connect an external audio device.

o FOR SOFTWARE UPGRADE ONLY

• Socket for software upgrade.

p Power cord

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Prepare FM/DAB antenna

For better reception, fully extend and adjust the

position of the FM/DAB antenna.

Note

•To prevent interference, position the antenna as far as

possible fromTV,VCR, or other radiation source.

Connect power

Caution

•Risk of product damage! Ensure that the power voltage

corresponds to the voltage printed on the back or

underside of the unit.

•Risk of electric shock! When you unplug the power

adapter, always pull the plug from the socket. Never

pull the cord.

•Before connecting the power adapter, ensure that you

have completed all other connections.

•Use the supplied power adapter only.

Insert the power plug into the wall outlet.

7EN

Turn on

Press to turn on your device.

» The device switches to the last

selected source.

Switch to standby mode

Press and hold for 3 seconds to switch the

device to standby mode.

» Theclock(ifset)appearsonthe

display panel.

Set time

Note

•You only can set time in DAB or FM mode.

1 Press SOURCE repeatedly to select DAB/

FM mode.

2 Press and hold INFO/MENU to access the

DAB/FM menu.

3 Press / repeatedly to select [System]

(system),andpressSELECTtoconrm.

» [Time] (time)isdisplayed.

4 Press SELECT again to enter time setting

mode.

• [Set time/Date](settime/date)

• [Auto update](autoupdate)

• [Set 12/24 hour](set12/24hour)

• [Set date format](setdateformat)

5 Press / repeatedly to select an item,

and then press SELECTtoconrm.

6 Press INFO/MENU to return to DAB/FM

home menu.

4 Play from iPod/

iPhone

You can enjoy audio from iPod/iPhone through

this device.

Compatible iPod/iPhone

The device supports the following models:

Made for.

• iPod classic

• iPod touch (1st, 2nd, 3rd, and 4th

generation)

• iPod nano (1st, 2nd, 3rd, 4th, 5th, and 6th

generation)

• iPhone 4S

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

Listen to audio from iPod/

iPhone

1 Press SOURCE repeatedly to select iPod

mode.

2 Insert the iPod/iPhone into the dock.

8EN

3 Start to play audio from the iPod/iPhone.

» The music streams from this device

automatically.

Charge the iPod/iPhone

When the device is connected to power,

the docked iPod/iPhone begins to charge

automatically.

Adjust volume

During play, you can rotate the knob to adjust

volume.

Tip

•You can also adjust the volume through your iPod/

iPhone.

Remove the iPod/iPhone

Pull the iPod/iPhone out of the dock.

5 Listen to DAB

radio

DigitalAudioBroadcasting(DAB)isaway

of broadcasting radio digitally through a

network of transmitters. It provides you with

more choice, better sound quality, and more

information.

Tune to DAB radio stations

Note

•Make sure that the antenna is fulled extended.

1 Press SOURCE repeatedly to select DAB

mode.

» [Full SCAN](fullscan)isdisplayed.

2 Press SELECT to start full scan.

» The unit stores all the DAB radio

stations automatically and then

broadcaststherstavailablestation.

» The station list is memorized in the

unit. Next time when you turn on the

unit, the station scan does not take

place.

» If no DAB station is found, [No DAB

Station](noDABstation)appears,

then [FULL SCAN](fullscan)is

displayed.

To tune to a station from the available station

list:

1 In DAB mode, press / to navigate

through the available DAB stations.

2 Press SELECTtoconrm.

9EN

Scan DAB radio stations

automatically

Note

•New stations and services will be added in the DAB

broadcast.To make new DAB stations and services

available, perform full scan regularly.

1 In DAB mode, press and hold INFO/

MENU to access the DAB menu.

2 Press / repeatedly to display [Full

scan](fullscan).

3 Press SELECTtoconrm.

» The unit scans all DAB radio stations

andbroadcaststherstavailable

station.

» If no DAB station is available, [No DAB

Station](noDABstation)isdisplayed.

Store DAB radio stations

manually

Note

•You can store up to 20 DAB radio stations.

1 Tune to a DAB radio station.

2 Press PROG/AUTOSCAN to activate the

storing mode.

3 Press PRESET +/- to select a preset

number.

4 Press SELECTtoconrm.

5 Repeat steps 1 to 4 to store more DAB

stations.

Note

•To overwrite a preset station, store another station in

its place.

Select a preset DAB radio

station

In DAB mode, press PRESET +/- repeatedly to

select a preset DAB radio station.

Display DAB information

1 Tune to a DAB radio station.

2 Press INFO/MENU repeatedly to scroll

through the following information (if

available):

» DynamicLabelSegment(DLS)

» Signal strength

» ProgramType(PTY)

» Ensemble name

» Channel and frequency

» Signal error rate

» Bit rate and audio status

Use DAB menu

1 In DAB mode, press and hold INFO/

MENU to access the DAB menu.

2 Press / repeatedly to display the menu

options:

• [Full scan](fullscan):scanallavailable

DAB radio stations.

• [Manual tune](manualtune):tuneto

aspecicchannel/frequencymanually

and add it to the station list.

• [DRC](DRC)

• [Prune](prune):removeunavailable

stations from the station list.

• [System](system):adjustsystem

settings.

3 To select an option, press SELECT.

4 Repeat steps 2-3 if sub-option is available

under one option.

[DRC](DRC)

10EN

Dynamicrangecompression(DRC)addsor

removes a degree of compensation for the

differences in the dynamic range between radio

stations.

• [DRC high](DRChigh):setDRCinhigh

level.

• [DRC low](DRClow):setDRCinlow

level.

• [DRC off](DRCoff):turnoffDRC.

Note

•DRC only works if it is enabled by the broadcaster for

aspecicstation.

[System](system)

• [Time](time):settimeanddate.(Referto

thepartof"Settime".)

• [Backlight](backlight):selectonlevelfor

the backlight.

• [Factory Reset](factoryreset):resetall

settings to factory default.

• [Software Upgrade](softwareupgrade):

upgrade software through USB socket if

available.

• [SW version](softwareversion):knowthe

software version of this digital radio.

Note

•If no button is pressed within 15 seconds, the menu

exits.

6 Listen to FM

radio

Tune to FM radio stations

1 Press SOURCE repeatedly to select FM

mode.

2 Press / repeatedly to tune to a radio

station.

Scan FM radio stations

automatically

In FM mode, press and hold PROG/

AUTOSCAN for 3 seconds.

» All available stations are programmed.

» Therstprogrammedradiostationis

broadcast automatically.

Store FM radio stations

manually

Note

•You can store up to 20 FM radio stations.

1 Tune to an FM radio station.

2 Press PROG/AUTOSCAN to activate

storing mode.

3 Press PRESET +/- repeatedly to select a

preset number.

4 Press SELECTtoconrm.

5 Repeat steps 1-4 to store more FM

stations.

Tip

•To overwrite a preset station, store another station in

its place.

Altri manuali per AJB7038D

Indice

Altri manuali Philips Stazione di attracco

Philips

Philips Fidelio Docking speaker DS 3000 Manuale utente

Philips

Philips SB4B1928 Manuale utente

Philips

Philips FWM200D/37 Manuale utente

Philips

Philips AS351/12 Manuale utente

Philips

Philips AJ7041D Manuale utente

Philips

Philips DC220 Manuale utente

Philips

Philips DCP850 Manuale utente

Philips

Philips DCM250/12 Manuale utente

Philips

Philips DLA99901/10 Manuale utente

Philips

Philips DC320 Manuale utente

Philips

Philips AJ7260D Scheda informativa del prodotto

Philips

Philips BTM630/37B Manuale utente

Philips

Philips Streamium WACS7500/05 Manuale utente

Philips

Philips DC276 Manuale utente

Philips

Philips DC200 Manuale utente

Philips

Philips DS3480 Scheda informativa del prodotto

Philips

Philips DC185/05 Manuale utente

Philips

Philips DC6210/37 Manuale utente

Philips

Philips DCP852/37B Manuale utente

Philips

Philips DC190 Manuale utente

Philips

Philips DS8550V37 Manuale utente

Philips

Philips AJ301DB/79 Manuale utente

Philips

Philips DC390/05 Manuale utente

Philips

Philips iBoom Home DLA77082/79 Manuale utente

Manuali Stazione di attracco popolari di altre marche

Sony

Sony Dream Machine XDR-DS12iP Manuale utente

Acer

Acer USB Type-C Dock II Manuale utente

ATEN

ATEN UC-2000 Manuale utente

Xcellon

Xcellon HDD-202 Manuale utente

Dok

Dok CR09 Manuale utente

IOGear

IOGear Travel Pro GUD3C09 Manuale utente

RKI

RKI SDM-E2 Manuale utente

iHome

iHome iP15 Manuale utente

VITURE ONE

VITURE ONE MOBILE DOCK Manuale utente

Lindy

Lindy 42984 Manuale utente

CipherLab

CipherLab 8001 Manuale utente

Pyle

Pyle PIPDSP2 Manuale utente

Avol

Avol AS2350 Manuale utente

Datalogic

Datalogic JoyaTouch Manuale utente

Targus

Targus DOCK315EUZ Manuale utente

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manuale utente

Sirius Satellite Radio

Sirius Satellite Radio SUBX2082808a Manuale utente

OWC

OWC Thunderbolt Dock Manuale utente
