Philips DC185/05 Manuale utente

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

User Manual

Quick Start Guide

User Manual

Quick Start Guide

DC185

AC power cord

3 X iPod dock doors

Line-in Cable

DC185_12_QSG_Eng 2008.4.29, 3:08 PM1

Tip

– See the User Manual for how to connect other

equipment to this system.

– Use the supplied AC power cable only! Using any

other power connection device may damage your

main set!

Connect the AC power cable of the system.

Before plugging your player in the dock, select a suitable dock door.

3 iPod dock doors are included. Each door has indication to match

different iPod types.

Push the dock to eject it.

Align the slots of the dock and latches of the dock door, then

slide in the door.

Align the connectors of on the dock and iPod, and then push

the iPod gently to install your iPod to the dock connector.

Hold the iPod carefully and pull it out slowly.

Turn the wheel of the dock support to adjust the height to

different iPod types.

To take out the iPod, push the dock to eject it.

Push the dock door to close it.

DC185_12_QSG_Eng 2008.4.29, 3:08 PM2

Enjoy

Insert the USB device’s USB plug into the socket on the top of the system.

Press SOURCE repeatedly to select USB.

Play the available audio files using playback buttons on the set (such as

2;, S/T).

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1)

Programming and tuning to radio stations

Press SOURCE repeatedly to select the tuner source (FM).

Press MODE for more than two seconds to program all available

stations in order of waveband.

Press PRESET +/- until the desired preset station is displayed.

DC185_12_QSG_Eng 2008.4.29, 3:08 PM3

Enjoy

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

CRoyal Philips Electronics N.V. 2008

PDCC-ZYL-0810 GB

Playing Apple iPod using DC185

Correctly place the compatible iPod player into the dock.

Press SOURCE on the system repeatedly to select the iPod source.

Power on your iPod player.

Select and play your favourite songs stored in the iPod player.

Note:

Some keys on DC185 correspond to different keys of an iPod. For

detailed functions in different modes, please see the table in supplied

user manual.

Notes for remote control:

–Select the source you wish to control by pressing one of the source select

keys on the remote control (for example iPod, TUNER).

–Then select the desired function (for exampleÉÅ).

DC185_12_QSG_Eng 2008.4.29, 3:08 PM4
