Philips DCB146/05 Manuale utente

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

DCB146

Quick Start Guide

User Manual

Quick Start Guide User Manual

Remote Control

4 iPod Adaptors

DCB146_QSG_Eng 3/30/10, 12:411

Connection

Connect the speaker wires to the SPEAKERS terminals.

Connect the power cord of the system to the AC power outlet.

Tip:

It is unnecessary to connect the DAB/ FM antenna since it

is fixed to the main unit.

speaker

(right)

speaker

(left)

DAB/FM wire antenna

AC power cord

DCB146_QSG_Eng 3/30/10, 12:412

Setting the clock

In standby mode, press and hold

DISPLAY/CLOCK on the remote control

set for 2 seconds.

Playing a disc

Select CD source.

Lift the CD door on the top of the system to open the CD compartment.

Insert a disc with the printed side facing up and press down

on PULL TO OPEN to close the CD door.

PressÉÅto start playback.

Press 9to stop playback.

Press PROG to select 12-hour or 24-hour display.

Press DISPLAY/CLOCK to confirm.

➜The clock digits for the hours flash.

Press TUNING 4 ¢ (or 4 ¢ on the remote

control) to set the hours.

Press DISPLAY/CLOCK again.

➜The clock digits for the minutes flash.

Press TUNING 4 ¢ (or 4 ¢ on the remote control) to set

the minutes.

Press DISPLAY/CLOCK to confirm the time.

DCB146_QSG_Eng 3/30/10, 12:413

Press SOURCE (or DAB on the remote control)

to select DAB to start an automatic search of available DAB

stations.

Press 4 / ¢to change the DAB stations.

Tuning to DAB stations

Programming and tuning to FM

stations

Select FM TUNER source.

2Press SCAN for more than two seconds to program all

available stations (FM only).

Press PRESET +/- ( or 3/4on the remote control ) until the

desired preset station is displayed.

To access setup options, press MENU then use the navigation

control buttons to select.

3Press OK to confirm a selection.

4To perform a local scan (in UK ), press briefly SCAN.

To perform a full scan (outside UK ), press and hold SCAN.

DCB146_QSG_Eng 3/30/10, 12:414

http://www.philips.com DCB146_05_QSG_V2.0

Tip:

Detailed playback features and

additional functions are described in

the accompanied user manual.

Notes for the remote control:

– First, select the source you wish to

control by pressing one of the source select

keys on the remote control (DISC or AUX,

for example).

–Then select the desired function ( 2;,

4, ¢for example).

Press PUSH TO OPEN to open the dock.

Select the dock adaptor of the correct type and size, and snap it into the

dock.

➜Each iPod adaptor has its indication to fit a specific iPod.

Correctly place your iPod in the dock.

Playing iPod using the dock

MIC

PUSH TO OPEN

DOCK FOR iPOD

RO SYSTEM DCB146

SOURCE

DOCK

STANDBY-ON

CD/CD-R/CD -RW COMPATIBLE

PRESET

VOL

TUNING

Press SOURCE repeatedly or DOCK on the set (or iPOD

on the remote control) to select iPod source.

➜The connected player will play automatically.

➜The iPod battery will be charged in either normal standby mode or power-on mode.

DCB146_QSG_Eng 3/30/10, 12:415
