Philips DCM230 Manuale utente

Philips

Docking Entertainment

System with Dynamic Bass

Boost

DCM230

Enjoy iPod music in Hi-Fi

sound quality

Free your iPod music and enjoy it in superb sound on the Philips DCM230. Stylishly designed

with a cool metallic finish, the sleek system features smart functions and boasts total 30W

RMS power for truly dynamic sound.

Play your iPod content out loud at home

• Play and charge your iPod simultaneously

• USB Direct connection for portable USB MP3 players

• Play MP3/WMA-CD, CD and CD-RW

• Digital tuning for station presets

Rich and clear sound

• Dynamic Bass Boost for deep and dramatic sound

• Digital Sound Control for optimized music style settings

• 2x15W RMS/30W Total power

Design that blends into your interior

• Stylish desktop design with high-end metallic front panel

• Elegant design with super slim CD slot

• High quality remote control for comfortable use

DCM230/37

Highlights

Docking Entertainment System with Dynamic Bass Boost

Play and charge your iPod

Enjoy your favorite MP3 music while charging

your iPod! The dock lets you connect your iPod

directly to the Docking entertainment system so

you can listen to your favorite music in superb

sound. It also charges your iPod while it plays so

you can enjoy your music and not have to worry

about your iPod battery running out. Use the

remote control to navigate, select and playback

the music stored on your iPod. The Docking

entertainment system automatically charges

your iPod while it is docked.

USB Direct connection

With the USB Direct mode, you can simply

select the music on a USB device and playback all

your content. All you have to do is plug in your

USB device to playback music or export content

from the device.

Dynamic Bass Boost

Dynamic Bass Boost maximizes your music

enjoyment by emphasizing the bass content of

the music throughout the range of volume

settings - from low to high – at the touch of a

button! Bottom-end bass frequencies usually get

lost when the volume is set at a low level. To

counteract this, Dynamic Bass Boost can be

switched on to boost bass levels, so you can

enjoy consistent sound even when you turn

down the volume.

Digital Sound Control

Digital Sound Control offers you a choice of

pre-set Jazz, Rock, Pop and Classic controls you

can use to optimise the frequency ranges for

different musical styles. Each mode uses graphic

equalizing technology to automatically adjust the

sound balance and enhance the most important

sound frequencies in your chosen music style.

Ultimately, Digital Sound Control makes it easy

for you get the most out of your music by

precisely adjusting the sound balance to match

the type of music you are playing.

DCM230/37

Specifications

Docking Entertainment System with Dynamic Bass Boost

iPod compatibility

• Compatible with: iPod, iPod mini, iPod nano, iPod

with color display, iPod 5th Generation

Audio Playback

• Cradle playback mode: Charging iPod, Play and

Pause, Next and Previous track, Fast forward and

backward

• Loader Type: Motorised, Slot

• Playback Media: WMA-CD, MP3-CD, CD, CD-R,

CD-RW

• Disc Playback Modes: Fast Forward/Backward,

Next/Previous Track Search, Repeat Play, Shuffle

Play

• Programmable Tracks: 20

Sound

• Output power (RMS): 2x15 W

• Sound System: Stereo

• Loudspeaker types: Bass Reflex Speaker System

• Sound Enhancement: Dynamic Bass Boost

• Volume Control: Volume Control up/down

Tuner/Reception/Transmission

• Tuner Bands: FM, MW

• Auto digital tuning

• Antenna: FM Antenna

Connectivity

• USB: USB host

• Aux in

• Headphone: 3.5 mm

Convenience

• Display Type: LCD

• Backlight

• Remote Control: Multi-functional

• Alarms: Radio Alarm, Sleep timer

• Clock/Version: Digital

Power

• Mains power

Accessories

• Included accessories: AC Power Cord, User Manual,

Warranty certificate, Remote Control, World Wide

Warranty leaflet

Dimensions

• Product dimensions (W x H x D):

390 x 140.5 x 200.5 mm

•

Issue date 2011-01-06

Version: 2.0.7

12 NC: 8670 000 30731

UPC: 6 09585 13480 5

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com
