Philips DCM230/05 Manuale utente

iPod

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

User Manual

FM antenna MW antenna Remote Control

Quick Start Guide

User manual

Quick Start Guide

DCM230

Pull out the plastic

protective sheet

before use.

AC power adaptor 4 X iPod dock adaptors

DCM230 QUGG_Eng 8/29/08, 16:321

AC power adaptor

MW loop

antenna

FM wire antenna

Connect the MW and FM antennas.

Connect the AC power adaptor of the system.

Tip

– See the User Manual for how to

connect other equipment to this system.

– Use the supplied AC power adaptor

only! Using any other power connection

device may damage your main set!

Setting the clock

In standby mode, press PROG.

➜ SET CLOCK is displayed briefly.Then, 12HR or 24HR is displayed.

Press ALBUM/PRESET +/- (or ¡/ ™on the remote control) to select

clock mode.

➜The clock digits for the hours continue to flash.

Press ALBUM/PRESET +/- (or ¡/ ™on the remote control) to set the

hours.

Press PROG again.

➜The clock digits for the minutes flash.

Press ALBUM/PRESET +/- (or ¡/ ™on the remote control) to set the

minutes.

Press PROG to confirm the time.

TIMER

iPod

DCM230 QUGG_Eng 8/29/08, 16:322

Enjoy

Playing a disc

Insert a disc into the disc loader.

➜Make sure the label side is facing up.

Press ÉÅ to start playback.

To stop playback, press 9.

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more (or USB on the remote control) to select USB.

Play the USB’s audio files as you do with the albums/tracks on a CD.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Programming and tuning to radio stations

Press SOURCE repeatedly (or TUNER on the remote control) to

select the tuner source.

Press PROG for more than two seconds to program all available

stations in order of waveband.

Press ALBUM/PRESET +/- (or 3/ 4on the remote control)

until the desired preset station is displayed.

iPod

DCM230 QUGG_Eng 8/29/08, 16:323

Enjoy

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

CRoyal Philips Electronics N.V. 2008

PDCC-JH/ZYL-0835

Playing Apple iPod using DCM230

Select the correct dock adaptor, as indicated on each adaptor, then fit it in

the dock.

Correctly place the compatible iPod player into the dock.

Press SOURCE on the system repeatedly or iPod on the remote control

to select the iPod source.

Power on your iPod player.

Select and play your favourite songs stored in the iPod player.

Notes for remote control:

–First select the source you wish to control by pressing one of the

source select keys on the remote control (for example CD, FM).

–Then select the desired function (for example

ÉÅ

DCM230 QUGG_Eng 8/29/08, 16:324
