Philips SGP6031BB/27 Manuale utente

SGP6031BB/27

Manuel de l’utilisateur

User manual

ES Manual de usuario

EN Contents

3 Introduction

3 Features

4 Installation

5 Operation

6 FCC Information

7 Warranty

8 Technical Support

Thank you for your purchase of the Philips

Blasting Dock. With the combination of

dynamic neodymium speakers, a fold down

subwoofer,and 3D sound processor,your PSP

experience will not be complete without it.

Features and Specications

• Total Continuous Power:

12W RMS (6W+3Wx2)

• Satellite Speakers:

3 Watts/Channel @4 ohms

• Sub Woofer: 6 Watts @4 ohms

• Frequency Response: 100HZ~20kHz

• Signal to Noise Ratio:

@ 1 kHz input > 60db

• Speaker Drivers:Two full range neodymium

Micro Drivers + 3” Speaker

Introduction

Installation

1. Install the AC adapter into the power

socket on the Blasting Dock or install 4 x

AAA batteries (not included) as indicated

in the diagram.

2. Press the button on the side of the Blasting

Dock to unlock the subwoofer.

3. Fold down the subwoofer.

4. Connect the 3.5mm mini connection cable

to the PSP, then to the line in (PSP without

docking, connect the longer 3.5mm play

away cable).

5. Turn PSP on and then install onto the dock

and adjust volume on PSP.

Installation

Operation

Speaker Controls

Power On / Off:Push the button once on the

Blasting Dock. The blue LED will illuminate

when the Blasting Dock is turned on. Push

again to turn off.

Volume Controls: Press the up or down

arrows on the Blasting Dock to adjust the

sound level.

3D Button: Press this button to enrich

sound for 3D effect. Note:Volume may need

adjustment to avoid distortion. Push 3D

button again to return to normal.

Line-In

The Blasting Dock has a built in line-in jack

that can also allow the use of other portable

audio devices such as MP3,MiniDisc, Portable

CD Players. Connect the 3.5mm play away

cable to both the line in on the Blasting Dock

and headset output on your device.

Operation

FCC Warning:

This equipment has been tested and found

to comply with the limits for a Class B digital

device pursuant to Part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful interference

to radio communications. However, there is

no guarantee that interference to radio or

television reception, which can be determined

by turning the equipment off and on,the user is

encouraged to try and correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the

equipment and receiver.

• Connect the equipment into an outlet on

a circuit different form that to which the

receiver is connected.

• Consult the dealer on an experienced

radio/TV technician for help.

Caution: Any changes or modications not

expressly approved by the guarantee of this

device could void the users authority to

operate the equipment.

FCC Information

Limited one-year warranty

Philips warrants that this product shall be free

from defects in material, workmanship and

assembly, under normal use, in accordance

with the specications and warnings, for

one year from the date of your purchase of

this product. This warranty extends only to

the original purchaser of the product, and

is not transferable. To exercise your rights

under this warranty, you must provide proof

of purchase in the form of an original sales

receipt that shows the product name and the

date of purchase. For customer support or

to obtain warranty service, please call 1-919-

573-7862. THEREARE NO OTHER EXPRESS

OR IMPLIED WARRANTIES. Philips’ liability

is limited to repair or, at its sole option,

replacement of the product. Incidental,special

and consequential damages are disclaimed

where permitted by law. This warranty gives

you specic legal rights. You may also have

other rights that vary from state to state.

PSP™ is a registered trademark of Sony®

Computer Entertainment. It is not endorsed,

sponsored or manufactured by the companies

mentioned herein.

Warranty

Technical Support

For Technical Support send an email with the

model number of the product and a detailed

description of your problem to:

Email: accessorysupport@philips.com

Accessories Service Center

Philips Accessories and

Computer Peripherals,

Ledgewood, NJ 07852 USA

Made In China

Technical Support

10 Introduction

10 Caractéristiques

et che technique

11 Installation

12 Opération

13 Averissement FCC

14 Garantie

15 Assistance technique

Contenu

Nous vous remercions de votre achat d’un

Philips Blasting Dock. Grâce à des hauts-

parleurs dynamiques en neodymium, un

caisson de basse rabattable et un processeur

de son 3D, vous obtiendrez la PSP dont vous

avez toujours rêvé.

Caractéristiques

et che technique

• Alimentation totale continue:

12W RMS (6W+3WX2)

• Enceintes satellite:

3 Watts/Chaîne de 4 ohms

• Caisson de basse: 6Watts de 4 ohms

• Réponse de fréquence: 100HZ-20kHz

• Rapport signal/bruit: 1kHz entrée > 60db

• Circuits d’attaque du haut-parleur:

Deux Micro Drivers à gamme étendue

en neodymium + Haut-parleur de 7,62 cm

Introduction
