Philips DVP320F/17B Manuale operativo

COAXIAL VIDEO Y Pb Pr

MAINS

120V ~ 60HZ

Back of TV

(example only)

LEFTAUDIO IN

VIDEOIN

RIGHTAUDIO IN

LEFT AUDIO IN

VIDEO IN

RIGHT AUDIO IN

1Connect the supplied video cable (yellow) to the DVD Player’s yel-

low VIDEO Out jack and to the VIDEO IN jack on your TV.

2Connect the supplied audio cable (white and red) to the DVD

Player’s white/red AUDIO Out (left/right) jacks and to the left/right

AUDIO IN jacks on the TV. Match the cable colors to the jack colors.

3Connect the supplied power cord to the MAINS (AC Power) jack on

the rear of the DVD Player.

Plug the power cords of the Player and the TV into a power outlet.

4Press POWER on the Player to turn it on.

5Turn on the TV. Set it to the correct Video In channel.

Such channels may be called AUX or AUXILIARY IN,AUDIO/VIDEO or A/V

IN, EXT1 or EXT2 or External In, etc. Or, your TV’s remote control may have

a button or switch that selects a Video In mode. See your TV manual for

details. Or, select your lowest TV channel (01 or 02) and change TV channels

down until you see the blue DVD screen on the TV.

If your TV has a single Antenna In or RF In jack, you will need an RF

modulator. That will enable you to watch the DVD Player on your TV at

channel 3 or 4 (as with a VCR). See the owner’s manual for details.

There are many ways to connect your new DVD Player to your TV.

This Quick-Use Guide shows a common connection using the supplied cables.

Other options are explained in the accompanying owner’s manual.

Quick-Use Guide

1Press POWER on the

Player to turn it on.

Turn on your TV. Set it to

the correct Video In chan-

nel. You should see the blue

DVD screen on the TV.

2Press OPEN/CLOSE to

open the Disc compartment

on top of the Player.

Place the Disc on the Disc

hub,with the Disc label facing

up. Press the lid down to

close it.

3Play may start automati-

cally. If not, press PLAY. Or,

a DVD’s Disc menu may

appear. Press 3,4,1, or 2to

select an item, then press OK.

Or, follow the instructions in

the menu to start play.

4To stop play, press STOP.

Playable Discs

DVDs must be labeled for ALL

regions or Region 1 in order to

play on this Player. If one of these

logos appears on your DVD or its

case, it should play.

Recordings are made according to

a color system. Make sure the

Discs you play in this DVD Player

were recorded in NTSC or PAL

and your TV is NTSC or PAL

compatible. Look for the color

system on the DVD or its case. EL6565E001

3141 015 25271

Quick-Use Guide
