Philips HQ5801/33 Manuale utente

HQ5802,5801

ENGLISH 4

FRANÇAIS 11

ESPAÑOL 18

PORTUGUÊS 25

á«Hô©dGá«Hô©dG

Important

C◗Make sure the appliance and the cord do not

get wet.

◗Only use the cord supplied.

Charge indications

C◗Charging

As soon as you start charging the empty shaver,

the green pilot light will go on.

A fully charged shaver has a cordless shaving time

of up to 45 minutes.

Charging

Recharge and keep the appliance at a

temperature between 5cC and 35cC.

The appliance is suitable for mains voltages

ranging from 100 to 240V.

You can also shave without charging by

connecting the shaver to the mains.

To extend the lifetime of the battery,remove the

powerplug from the wall socket and pull the

appliance plug out of the shaver when the battery

has been fully charged.

C1Put the appliance plug in the shaver.

2Put the powerplug in the wall socket.

Do not recharge the shaver in a closed pouch.

ENGLISH4

3When charging for the first time or after a

long period of disuse:leave the shaver to

charge continuously for 12 hours.

Charging normally takes approx.8 hours.

4Remove the powerplug from the socket

and pull the appliance plug out of the

shaver when the battery has been fully

charged.

Shaving

1Switch the appliance on by sliding the

on/off button upwards.

C2Move the shaving heads quickly over your

skin,making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philishave system.

3Switch the shaver off.

C4Put the protection cap on the shaver to

prevent damage.

Replace the shaving heads (type HQ5 Reflex

Action) every 2 years for optimal shaving results.

ENGLISH 5

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning

◗Regular cleaning guarantees better shaving

performance.

C◗For easy and optimal cleaning,the Philishave

Action Clean (shaving head cleaner,type

HQ100) is available.Ask your Philishave dealer

for information.

You can also clean the shaver in the following

way:

Every week:shaving unit

1Switch the shaver off,remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Clean the top of the appliance first,using

the brush supplied.

C3Press the release button and remove the

shaving unit.

ENGLISH6

C4Clean the inside of the shaving unit and the

hair chamber with the brush.

C5Put the shaving unit back onto the shaver.

Every two months:shaving heads

1Switch the shaver off,remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button and remove the

shaving unit.

C3Turn the wheel anticlockwise and remove

the retaining frame.

C4Remove and clean the shaving heads

(cutters and guards) one by one.

Do not mix up the cutters and the guards.

This is essential since each cutter has been

ground with its corresponding guard for optimal

performance.If you accidentally mix the sets up,it

could take several weeks before optimal shaving

performance is restored.

ENGLISH 7

C5Clean the cutter with the short-bristled

side of the brush.

Brush carefully in the direction of the arrow.

C6Brush the guard.

If necessary,you can clean the shaving unit with a

degreasing liquid (e.g.alcohol).Remember to

lubricate the central point of the guards with a

drop of sewing machine oil after cleaning.

C7Reassemble the shaving unit by replacing

the retaining frame.Press the wheel and

turn it clockwise.

8Put the shaving unit back onto the shaver.

Trimmer

1Switch the shaver off,remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

2Clean the trimmer every time you have

used it.

3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

ENGLISH8

Disposal of the battery

Remove the battery when you discard the

appliance.Do not throw the battery away with

the normal household waste,but hand it in at an

official collection point.You can also take the

battery to a Philips Service Centre,which will

dispose of it in an environmentally safe way.

Only remove the battery if it is completely empty.

1Remove the powerplug from the wall

socket and pull the appliance plug out of

the shaver.

C2Let the shaver run until it stops,undo the

screws and open the shaver.

3Remove the battery.

Do not connect the shaver to the mains again

after the battery has been removed.

Troubleshooting

◗Problem:The shaver does not work after the

on/off button has been slided upwards.

BSolution:Recharge the battery.

If the shaver still does not work,see 'Guarantee &

service'.

ENGLISH 9

Guarantee & service

If you need information or if you have a problem,

please visit the PhilipsWeb site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet).If there is no Customer Care Centre in

your country,turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

ENGLISH10

Important

C◗Veillez à ce que l'appareil et le cordon

d'alimentation ne soient pas exposés à

l'humidité.

◗Utilisez exclusivement le cordon

d'alimentation fourni avec l'appareil.

Indications de charge

C◗Charge

Dès que vous commencez à charger le rasoir

vide,le témoin vert s'allume.

A pleine charge,le rasoir possède

approximativement 45 minutes d'autonomie.

Charge

Chargez et maintenez l'appareil à une

température comprise entre 5cC et 35cC.

Ce rasoir fonctionne sur une tension secteur de

100 à 240~volts.

Vous pouvez également vous raser directement

sans charger préalablement l'appareil en

raccordant directement l'appareil à la tension du

réseau.

Pour prolonger la durabilité des accumulateurs

enlevez le chargeur de la prise de courant,et tirez

la fiche hors du rasoir.

C1Enfoncez la fiche dans le rasoir.

FRANÇAIS 11

2Mettez le chargeur dans la prise de

courant.

Ne chargez jamais l'appareil dans un étui fermé.

3Lorsque vous chargez l'appareil pour la

première fois,ou si l'appareil n'a pas été

utilisé pendant une longue période:

chargez-le pendant 12 heures sans

interruption.

Une charge normale dure 8 heures environ.

4Lorsque le rasoir est complètement

rechargé,retirez d'abord le chargeur de la

prise de courant puis la fiche du rasoir.

Rasage

1Mettez l'appareil en marche en faisant

glisser le bouton marche/arrêt vers le haut.

C2Déplacez rapidement les têtes de rasage

sur la peau en effectuant des mouvements

rectilignes et circulaires.

Les meilleurs résultats de rasage sont obtenus sur

peau sèche.

Votre peau peut avoir besoin de 2-3 semaines

pour s'habituer au système de coupe Philishave.

3Arrêtez le rasoir.

C4Remettez le capot protecteur sur le rasoir

pour éviter tout dommage.

FRANÇAIS12
