Philips HQ6640 Manuale utente

HQ6646, HQ6645, HQ6640

ENGLISH 4

 12

 20

 28

 35

 43

 51

 59

 66

 74

 82

 90

 98

 106

 113

 120

Important

Read these instructions for use carefully before using

the appliance and save them for future reference.

Only use the mains cord supplied.

Do not use a damaged mains cord.

If the mains cord is damaged, always have it

replaced by one of the original type in order to

avoid a hazard.

The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages ranging from 100 to 240 volts.

Store and use the appliance at a temperature

between 5 cC and 35 cC.

Keep the appliance and the mains cord dry.

Noise level: Lc = 60 dB [A]





1 Put the appliance plug in the shaver.

2 Put the mains plug in the wall socket.

3 Switch the shaver on by pushing the on/off

slide to position I.

4 Move the shaving heads quickly over your skin,

making both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get accustomed

to the Philips shaving system.

5 Switch the shaver off by pushing the on/off

slide to position 0.

ENGLISH

6 Put the protection cap on the shaver every

time you have used it, to prevent damage to

the shaving heads.



For grooming sideburns and moustache.

1 Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

2 Close the trimmer (‘click’).



Regular cleaning guarantees better shaving

performance.

For easy and optimal cleaning, the Philips Shaving

Head Cleaner (type HQ100) is available.Ask

your Philips dealer for information.

The Philips Shaving Head Cleaner may not be

available in all countries. Contact the Customer Care

Centre in your country about the availability of this

accessory.

You can also clean the shaver in the following way:



1 Switch the shaver off, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

ENGLISH 5

2 Cleanthetopoftheappliancerst,usingthe

brush supplied.

3 Press the release button (1) and remove the

shaving unit (2).

4 Clean the inside of the shaving unit and the

hair chamber with the brush.

5 Put the shaving unit back onto the shaver.



1 Switch the shaver off, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

ENGLISH6

2 Press the release button (1) and remove the

shaving unit (2).

3 Turn the wheel anticlockwise (1) and remove

the retaining frame (2).

4 Remove the cutters and guards and clean them

with the brush supplied.

Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it

may take several weeks before optimal shaving

performance is restored.

5 Clean the cutter with the short-bristled side of

the brush.

Brush carefully in the direction of the arrow.

6 Brush the guard.

ENGLISH 7

7 Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit (1) and turn the wheel clockwise

(2).

8 Put the shaving unit back onto the shaver.

For extra thorough cleaning, clean the shaving heads

by putting them in a degreasing liquid (e.g. alcohol)

every six months.To remove the shaving heads,

follow steps 1 to 4 described above. After cleaning,

lubricate the central point on the inside of the

guards with a drop of sewing machine oil to prevent

wear of the shaving heads.



Clean the trimmer every time you have used it.

1 Switch the shaver off, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.



Put the protection cap on the shaver to prevent

damage.

ENGLISH8



Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with HQ55

Philips Shaving Heads only.

1 Switch the shaver off, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

2 Press the release button (1) and remove the

shaving unit (2).

3 Turn the wheel anticlockwise (1) and remove

the retaining frame (2).

4 Remove the shaving heads and place new ones

in the shaving unit.

5 Put the retaining frame back into the shaving

unit (1) and turn the wheel clockwise (2).

6 Put the shaving unit back onto the shaver.

ENGLISH 9



Do not throw the appliance away with the

normal household waste at the end of its life,

buthanditinatanofcialcollectionpointfor

recycling. By doing this you will help to preserve

the environment.



The following accessories are available:

HQ55 Philips Shaving Heads.

HQ100 Philips Shaving Head Cleaner.

HQ101 Philips Shaving Head Cleaning Fluid.

HQ110 Philips Shaving Head Cleaning Spray.



If you need information or if you have a

problem, please visit the Philips website at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will nd its phone

number in the worldwide guarantee leaet). If there

is no Customer Care Centre in your country, turn

to your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and

Personal Care BV.

ENGLISH10



1 Reduced shaving performance

Cause 1: the shaving heads are dirty.

The shaver has not been cleaned well enough or has

not been cleaned for a long time.

Clean the shaver thoroughly before you continue

shaving. See chapter ‘Cleaning and maintenance’.

Cause 2: long hairs are obstructing the shaving heads.

Clean the cutters and guards with the brush

supplied. See chapter ‘Cleaning and maintenance’,

section ‘Every two months: shaving heads’.

Cause 3: the shaving heads are damaged or worn.

Replace the shaving heads. See chapter

‘Replacement’.

2 The shaver does not work when the on/off

slide is pushed to position I.

Cause: the shaver is not connected to the mains.

Put the mains plug in the wall socket.

ENGLISH 11



Преди да използвате уреда, прочетете

внимателно това ръководство за експлоатация и

го запазете за справка в бъдеще.

Използвайтесамодоставенияскомплекта

захранващкабел.

Неизползвайтеповредензахранващкабел.

Акозахранващияткабелеповреден,с

огледпредотвратяваненаопасноствинаги

заменяйтеповредениязахранващкабелсамо

соригиналентакъв.

Уредътесъоръженсавтоматиченселектор

нанапрежениеиеподходящзанапрежения

намрежатаот100до240Волта.

Съхранявайтеиизползвайтеуредапри

температурамежду5cCи35cC.

Пазетеуредаизахранващиякабелсухи.

Нивонашум:Lc=60dB[A]





1 Включетещекеранауредавгнездотому.

2 Включетещепселаназахранващиякабелв

контакта.

3 Включетесамобръсначкатаспреместванена

плъзгачавкл./изкл.вположениеI.

4 Движетебръснещитеглавибързопокожата

си,катоправитеправолинейниикръгови

движения.

Най-добри резултати се получават при бръснене

на суха кожа.


