Philips HQ6640 Manuale utente

ENGLISH 4

DEUTSCH 12

FRANÇAIS 21

NEDERLANDS 30

ESPAÑOL 39

ITALIANO 48

PORTUGUÊS 57

TÜRKÇE 66

HQ6646, HQ6645, HQ6640

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the mains cord supplied.

◗Do not use a damaged mains cord.

◗If the mains cord is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

◗The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages ranging from 100 to 240 volts.

◗Store and use the appliance at a temperature

between 5cC and 35cC.

C◗Keep the appliance and the mains cord dry.

Using the appliance

Shaving

C1Put the appliance plug in the shaver.

2Put the mains plug in the wall socket.

3Switch the shaver on by pushing the on/off

slide to position I.

C4Move the shaving heads quickly over your

skin, making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

ENGLISH4

5Switch the shaver off by pushing the on/off

slide to position 0.

C6Put the protection cap on the shaver every

time you have used it, to prevent damage

to the shaving heads.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

2Close the trimmer ('click').

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

C◗For easy and optimal cleaning, the Philips

Shaving Head Cleaner (type HQ100) is

available.Ask your Philips dealer for

information.

The Philips Shaving Head Cleaner may not be

available in all countries. Contact the Customer

Care Centre in your country about the availability

of this accessory.

ENGLISH 5

You can also clean the shaver in the following

way:

Every week: shaving unit and hair chamber

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the top of the appliance first, using

the brush supplied.

C3Press the release button (1) and remove

the shaving unit (2).

C4Clean the inside of the shaving unit and the

hair chamber with the brush.

C5Put the shaving unit back onto the shaver.

ENGLISH6

Every two months: shaving heads

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove the cutters and guards and clean

them with the brush supplied.

Do not clean more than one cutter and guard at

a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it may

take several weeks before optimal shaving

performance is restored.

C5Clean the cutter with the short-bristled

side of the brush.

Brush carefully in the direction of the arrow.

C6Brush the guard.

ENGLISH 7

C7Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

8Put the shaving unit back onto the shaver.

For extra thorough cleaning, clean the shaving

heads by putting them in a degreasing liquid (e.g.

alcohol) every six months.To remove the shaving

heads, follow steps 1 to 4 described above. After

cleaning, lubricate the central point on the inside

of the guards with a drop of sewing machine oil

to prevent wear of the shaving heads.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

ENGLISH8

Storage

C◗Put the protection cap on the shaver to

prevent damage.

Replacement

Replace the shaving heads every two years for

optimal shaving results. Replace damaged or worn

shaving heads with HQ55 Philips Shaving Heads

only.

1Switch the shaver off, remove the mains

plug from the wall socket and pull the

appliance plug out of the shaver.

C2Press the release button (1) and remove

the shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove the shaving heads and place new

ones in the shaving unit.

ENGLISH 9

C5Put the retaining frame back into the

shaving unit (1) and turn the wheel

clockwise (2).

6Put the shaving unit back onto the shaver.

Environment

C◗Do not throw the appliance away with the

normal household waste at the end of its life,

but hand it in at an official collection point for

recycling. By doing this you will help to

preserve the environment.

Accessories

The following accessories are available:

- HQ55 Philips Shaving Heads.

- HQ100 Philips Shaving Head Cleaner.

- HQ101 Philips Shaving Head Cleaning Fluid.

- HQ110 Philips Shaving Head Cleaning Spray.

Guarantee & service

If you need information or if you have a problem,

please visit the Philips website at www.philips.com

or contact the Philips Customer Care Centre in

your country (you will find its phone number in

the worldwide guarantee leaflet). If there is no

Customer Care Centre in your country, turn to

your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and

Personal Care BV.

ENGLISH10

Troubleshooting

1Reduced shaving performance

BCause 1: the shaving heads are dirty.

BThe shaver has not been cleaned well enough or

has not been cleaned for a long time.

◗Clean the shaver thoroughly before you

continue shaving. See chapter 'Cleaning and

maintenance'.

BCause 2: long hairs are obstructing the shaving

heads.

◗Clean the cutters and guards with the brush

supplied. See chapter 'Cleaning and

maintenance', section 'Every two months:

shaving heads'.

BCause 3: the shaving heads are damaged or worn.

◗Replace the shaving heads. See chapter

'Replacement'.

2The shaver does not work when the on/off

slide is pushed to position I.

BCause: the shaver is not connected to the mains.

◗Put the mains plug in the wall socket.

ENGLISH 11

Wichtig

Lesen Sie diese Bedienungsanleitung vor dem

ersten Gebrauch des Geräts sorgfältig durch, und

bewahren Sie sie für eine spätereVerwendung

auf.

◗Verwenden Sie ausschließlich das mitgelieferte

Netzkabel.

◗Verwenden Sie auf keinen Fall ein beschädigtes

Netzkabel.

◗Wenn das Netzkabel defekt oder beschädigt

ist, darf es nur durch ein Original-Ersatzkabel

ausgetauscht werden, um Gefährdungen zu

vermeiden.

◗Das Gerät hat eine automatische

Spannungsanpassung und eignet sich für

Netzspannungen von 100 bis 240 Volt.

◗Verwenden Sie das Gerät nur bei

Temperaturen zwischen 5cC und 35cC.

Bewahren Sie es auch in diesem

Temperaturbereich auf.

C◗Halten Sie das Gerät und das Netzkabel stets

trocken.

Das Gerät verwenden

Rasieren

C1Stecken Sie den Gerätestecker in den

Rasierer.

2Verbinden Sie das Netzteil mit einer

Steckdose.

DEUTSCH12
