Philips HQ7780 Manuale utente

ENGLISH 4

SLOVENSKY 28

EESTI 52

LATVISKI 75

LIETUVIŠKAI 99

БЪЛГАРСКИ 123

SRPSKI 150

HQ7782, HQ7780

Introduction

The shaver comes with two different kinds of

NIVEA FOR MEN cartridges: Extra Fresh Shaving

Gel for a fresh sensation during and after shaving

and Moisturising Shaving Lotion for sensitive skin.

This gives you the opportunity to try them out

and discover which one suits your skin type best.

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the powerplug and the charging

stand supplied.

◗The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

◗The powerplug contains a transformer. Do

not cut off the powerplug to replace it with

another plug, as this will cause a hazardous

situation.

◗Do not use a damaged powerplug or charging

stand.

◗If the powerplug or charging stand is

damaged, always have it replaced by one of the

original type in order to avoid a hazard.

◗Charge, store and use the appliance at a

temperature between 5cC and 35cC.

C◗Make sure the powerplug does not get wet.

◗Never immerse the charging stand in water

nor rinse it under the tap.

◗Do not leave the shaver in the plugged-in

charging stand for more than 24 hours.

ENGLISH4

C◗The appliance is watertight and can be

cleaned under the tap.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

C◗The appliance complies with the

internationally approved IEC safety regulations

and can be safely used in the bath or shower.

◗Check if the gel and lotion supplied with the

appliance contain ingredients (see back of

cartridge) to which you are allergic before

you start using the appliance. Do not use the

gel and/or lotion if you are allergic to one or

more ingredients.

◗Noise level: Lc = 63 dB [A]

The display

Living Light Display

This model features the unique Living Light

display.This 3D colour LED display gives you all

the information you need with special 'living light'

effects.

◗Remove any sticker or protective foil from

the Living Light Display.

ENGLISH 5

Demonstration program

The appliance has a unique demonstration

program.

1Press the on/off button for 7 seconds.

The demonstration will start automatically.

◗When the demonstration starts, all indications

light up at the same time.Then all indications

of the shaver are shown separately for 3

seconds in the following order:

„Charging/Battery full indication

ÊShaving

±Shaving gel indication

ÂCleaning reminder/„Battery capacity

ÊShaving

±Shaving gel indication

„Battery low indication

ÂCleaning reminder/„Battery low indication

ŒShaving head check indication

‰Travel lock indication

BThe whole demonstration program lasts approx.

1 minute (including intervals).

2You can stop the demonstration by

pressing the on/off button.

ENGLISH6

Indications during use

All indications mentioned below are shown

during every shaving session and they are always

displayed in the same order, which makes it very

easy for you to maintain a regular shaving ritual

As a result, some symbols will light up even when

you have already taken the appropriate action.

BWhen you switch the appliance on, the battery

capacity indication appears briefly. After this, the

shaving gel indication blinks three times. If you

have already applied enough shaving gel or lotion,

you can ignore this indication.

BWhen you switch the appliance off, the cleaning

reminder is displayed.This cleaning reminder

consists of a green tap (lights up) and a green

water jet (blinks). If you have already cleaned the

shaver before switching it off, you can ignore the

cleaning reminder.

After the cleaning reminder has been displayed,

the battery capacity indication appears briefly.

Charging

When you charge the shaver for the first time or

after a long period of disuse, let it charge

continuously for 4 hours. Charging normally takes

approx. 1 hour.

Do not leave the shaver in the plugged-in

charging stand for more than 24 hours.

ENGLISH 7

Charge indications

Battery running low

C◗When the battery is running low, the bottom

battery light burns red during shaving.

◗When you switch the shaver off while the

battery is nearly empty, the bottom battery

light blinks red twice.This will happen four

times with brief pauses in between.

◗When you start charging the shaver while the

battery is running low, the bottom battery

light blinks red for max. 3 minutes.

Battery fully charged

◗During charging the three battery lights blink

green until the shaver is fully charged (approx.

1 hour).

C◗The three battery lights burn green

continuously when the battery is fully

charged.

Battery indications during shaving

The three battery lights show the remaining

battery capacity for 5 seconds after you switch

the shaver on or off.

- The lower two battery lights burn green:

66% of the entire battery capacity is left.

- The bottom battery light burns green: 33% of

the battery capacity is left.

- The bottom battery light burns red: the battery

is almost empty (see also section 'Battery

running low').

ENGLISH8

Charging the appliance

Charge the shaver before using it for the first time

and when the shaver indicates that the battery is

running low.

1Insert the small plug into the charging

stand and put the powerplug in the wall

socket.

C2Place the shaver in the charging stand.

The shaver automatically switches off when it is

placed in the charging stand.

3Remove the powerplug from the wall

socket and pull the small plug out of the

charging stand when the battery has been

fully charged.You can then leave the

appliance in the charging stand.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 55 minutes.

Cartridges

Cartridges with NIVEA FOR MEN shaving

gel/lotion are available in boxes containing five

cartridges and one small plastic pump.

The NIVEA FOR MEN shaving gel/lotion in the

cartridges will keep for 32 months when stored

at temperatures between 0cC and +40cC.

ENGLISH 9

Only use Philips NIVEA FOR MEN Cool Skin

(HQ170 and HQ171) cartridges.

One Philips NIVEA FOR MEN Cool Skin

cartridge contains enough gel/lotion for approx.

10 shaves.

For hygienic reasons, we advise you to insert a

new pump when you start using a new set of five

cartridges.

Do not throw the pump away when you replace

an empty cartridge.You will need it for all five

cartridges.

Remove the shaving gel/lotion cartridge from the

appliance when you are not going to use the

shaver for more than one week.

When you have run out of shaving gel/lotion

cartridges and you do not know where to buy

them, contact the Customer Care Centre in your

country (see 'Guarantee & service').

Inserting cartridges

C1When you start using a new set of

cartridges, take the pump out of its bag

and push it into a cartridge until it locks

into position with a click.

ENGLISH10

C2Press the release button and open the

cover of the cartridge compartment.

C3Slide the cartridge with the pump into the

shaver. It only fits properly if the white side

of the pump is pointing upwards.

4Close the cover (you will hear a click).

5Press the yellow pump button a few times

until the NIVEA FOR MEN shaving

gel/lotion appears.The shaver is now ready

for use.

Replacing cartridges

Do not throw the pump away when you replace

an empty cartridge.You will need it for the other

cartridges.

C1Press the release button and open the

cover of the cartridge compartment.

2Remove the empty cartridge and pull out

the pump.

C3Push the pump into a new cartridge until it

locks into position with a click.

ENGLISH 11

C4Slide the cartridge with the pump into the

shaver. It only fits properly if the white side

of the pump is pointing upwards. Close the

cover.

Storing cartridges

C◗You can conveniently store the other

cartridges by attaching them to the wall

holder supplied.The holder has suction caps

which allow you to attach it to the wall easily.

In this way you always have the cartridges

close at hand, which is very convenient,

especially when you shave in the shower.

NB:The wall holder is only suitable for storing

cartridges. Never hang or place the shaver on the

wall holder. If you do, the shaver may fall!

Using the appliance

Shaving

Switching the shaver on

1Switch the shaver on by pressing the on/off

button once.

After the battery capacity has been shown briefly,

the yellow teardrop-shaped shaving gel light ±

blinks 3 times to indicate that shaving gel/lotion

can be applied.

If the shaver does not go on when you press the

ENGLISH12
