Important

Read these instructions for use carefully before

you use the appliances and save them for future

reference.

Only use the powerplug supplied.

The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

The powerplug contains a transformer. Do not

cut off the powerplug to replace it with another

plug, as this causes a hazardous situation.

Do not use a damaged powerplug.

If the powerplug is damaged, always have it

replaced by one of the original type in order to

avoid a hazard.

Make sure the powerplug does not get wet.

Charge, use and store the shaver at a

temperature between 5°C and 35°C.

Do not recharge the shaver in a closed pouch.

Always unplug the shaver before you clean it

under the tap.

The shaver complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

Be careful with hot water.Always check if the

water is not too hot, to prevent your hands

from getting burnt.

This washable shaver is not suitable for shaving

in the shower.

Do not immerse the shaver in water.

Water may leak from the socket at the bottom

of the shaver when you rinse it.This is normal

and not dangerous because all electronics are

enclosed in a sealed power unit inside the shaver.

Only use the washing machine with the original

HQ200 Cleaning Fluid.

ENGLISH

Empty the cleaning chamber and rinse it

thoroughly with hot tap water every 15 days.

The washing machine thoroughly cleans but does

not disinfect your shaver, therefore do not share

the shaver with others.

Never immerse the washing machine in water

nor rinse it under the tap.

Keep the washing machine out of the reach of

children.

Use and store the washing machine at a

temperature between 5°C and 35°C.

Always place the washing machine on a stable,

level and horizontal surface to prevent leakage.

When the washing machine is ready for use, do

not move it to prevent leakage of cleaning ﬂuid.

Charging

Make sure the shaver is switched off before

you charge it.

Charging takes approx. 1 hour.

You can also shave without charging by connecting

the shaver to the mains.

A fully charged shaver has a cordless shaving time of

up to 55 minutes.

1 Charge the shaver when the bottom light

burns or blinks red.

Charge indications

Charging

When you start to charge the empty shaver,

the bottom light blinks red.When the battery

contains enough power for one shave, all lights

blink green sequentially.

ENGLISH 5

Battery fully charged

When the battery is fully charged, all lights burn

green.

A few hours after charging, all lights go out.

Remaining battery capacity

The number of lights that are on show how

much power is left in the battery.The battery

capacity is only shown when you switch the

shaver on or off.

When all lights burn green, the battery is 100%

charged.

When the bottom light burns green, 20% of the

battery capacity is left.

Battery running low

When the battery is running low, the bottom

light turns red.

When you switch off the shaver, this light blinks a

few times.

Charging with the powerplug

Do not recharge the shaver in a closed pouch.

1 Put the appliance plug in the shaver.

2 Put the powerplug in the wall socket.

3 Remove the powerplug from the wall socket

and pull the appliance plug out of the shaver

when the battery is fully charged.

ENGLISH6

Charging in the washing machine

1 Place the shaver in the holder and push the

lever down completely to lock the shaver into

place.

The charging light on the washing machine blinks to

indicate that the shaver is charging.

When the charging light starts to burn

continuously (after approx. 1 hour), the shaver is

fully charged.

2 Move the lever upwards until it does not go

any further (1) and remove the shaver from the

washing machine (2).

The charging light goes out.

Using the appliance

Shaving

1 Press the on/off button once to switch on the

shaver.

The blue light ring round the on/off button goes on

to indicate that the motor is running.

Note:When you switch on the shaver, all lights go on

and then the remaining battery capacity is shown for a

few seconds.

ENGLISH 7

2 Move the shaving heads quickly over your skin.

Make both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

3 Press the on/off button once to switch off the

shaver.

The blue light ring round the on/off button goes out.

4 Clean the shaver (see chapter ‘Cleaning and

maintenance’).

5 Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

You can use the trimmer to groom your sideburns

and moustache.

1 Push the slide downwards to open the

trimmer.

You can activate the trimmer while the motor is

running.

2 Close the trimmer (‘click’).

Cleaning and maintenance

The best and most hygienic way to clean the

shaver is in the washing machine.You can also

clean the shaver by rinsing it under the tap or

with the brush supplied.

ENGLISH8

Regular cleaning guarantees better shaving

performance.

Cleaning the shaver in the washing machine

supplied

Preparing the washing machine for use

Fill the cleaning chamber before ﬁrst use and when

the cleaning light blinks to indicate that the ﬂuid

level is too low.When the ﬂuid level drops below

the minimum level, the cleaning light starts to blink

with intervals and the holder returns to its starting

position.

If you use the washing machine to clean the shaver

every day, reﬁll the cleaning chamber approx. every

15 days.

1 Simultaneously press the release buttons on

both sides of the cleaning chamber (1) and lift

the washing machine off the cleaning chamber

(2).

The cleaning chamber remains behind.

2 Unscrew the dosing cap from the bottle with

HQ200 Cleaning Fluid and remove the airtight

seal.

3 Fill the cleaning chamber with cleaning ﬂuid up

to the MAX indication.

4 Place the washing machine back onto the

cleaning chamber.

Make sure the release buttons snap back into place.

5 Put the appliance plug in the washing machine

and put the powerplug in the wall socket.

The holder automatically moves to the highest

position.

ENGLISH 9

The washing machine is now ready for use.

Using the washing machine

1 Place the shaver in the holder and push the

lever down completely to lock the shaver into

place.

The charging light on the washing machine blinks to

indicate that the shaver is being charged.

2 Press the start button to start the cleaning

program.

The cleaning light starts to blink and the shaver is

automatically lowered into the cleaning ﬂuid.

During the cleaning program, which takes

approx. 1 hour, the cleaning light blinks

continuously.

During the ﬁrst phase of the cleaning program,

the shaver automatically switches on and off

several times and is put in different positions.

During the second phase of the cleaning

program, the shaver is placed in the drying

position. It stays in this position until the

end of the program.The cleaning light burns

continuously.

After the cleaning program, the shaver

automatically returns to its starting position and

the charging program is started.The charging

light blinks.

Note:If you press the start button or open the lever

during cleaning, the cleaning program is aborted and

reset. In this case, the cleaning light stops blinking and

the holder returns to its starting position.

Note:If the powerplug is removed from the wall socket

during cleaning, the cleaning program is aborted.

The holder remains in its current position.When

ENGLISH10

the powerplug is put back into the wall socket, the

holder moves to the highest position.

Note:If the ﬂuid volume in the cleaning chamber drops

below the minimum level during the cleaning program,

the program is aborted.The cleaning light blinks with

intervals and the holder returns to its starting position.

Cleaning the washing machine

The cleaning chamber is not dishwasher-proof.

Clean the cleaning chamber every two weeks.

1 Simultaneously press the buttons on both sides

of the washing machine (1) and lift the washing

machine off the cleaning chamber (2).

The cleaning chamber remains behind.

2 Pour any remaining cleaning ﬂuid out of the

cleaning chamber.

You can simply pour the cleaning ﬂuid down the sink.

3 Rinse the cleaning chamber under the tap.

4 Place the washing machine back onto the

cleaning chamber.

Make sure the release buttons snap back into place.

5 Clean the washing machine with a moist cloth.

Cleaning the shaver under the tap

Be careful with hot water.Always check if the

water is not too hot, to prevent your hands from

getting burnt.

ENGLISH 11

1 Switch off the shaver, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

2 Press the release button to open the shaving

unit.

3 Rinse the shaving unit and the hair

chamber under a hot tap for some time.

Make sure you clean the inside as well as the

outside of the shaving unit.

4 Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue,

as this may damage the shaving heads.

5 Open the shaving unit again and leave it open

to let the appliance dry completely.

You can also clean the hair chamber without water

with the brush supplied.

Cleaning the shaver with the brush supplied

Shaving heads

1 Open the shaving unit, turn the lock

anticlockwise (1) and remove the retaining

frame (2).

ENGLISH12

Indice

Lingue:

Altri manuali Philips Rasoio elettrico

Philips

Philips Aquagenic Quadra HQ7405 Manuale utente

Philips

Philips Norelco Beardtrimmer 7500 Series Manuale di istruzioni

Philips

Philips PT729CC Manuale utente

Philips

Philips S5088 Manuale utente

Philips

Philips HQ5800/16 Manuale utente

Philips

Philips HQ6696 Manuale utente

Philips

Philips OneBlade QP2630/30 Manuale utente

Philips

Philips Norelco S1570 Manuale utente

Philips

Philips HQ6640 Manuale utente

Philips

Philips HQ7760 Manuale utente

Philips

Philips QP6520 Manuale utente

Philips

Philips Norelco SW9700 Manuale utente

Philips

Philips S5000 series Manuale utente

Philips

Philips BT7205/15 Manuale utente

Philips

Philips BT1005 Manuale utente

Philips

Philips OneBlade QP6610 Manuale utente

Philips

Philips Philishave C242 Manuale utente

Philips

Philips HQ8150/16 Manuale utente

Philips

Philips Ladyshave HP6306 Manuale utente

Philips

Philips 9000 series Manuale utente

Philips

Philips HC9490 Manuale utente

Philips

Philips RQ1076 Manuale utente

Philips

Philips Luxury A6 BW Manuale utente

Philips

Philips S5000 series Manuale utente

Manuali Rasoio elettrico popolari di altre marche

Norelco

Norelco Quadra 7610X Manuale utente

Braun

Braun WaterFlex WF2s Manuale utente

Daga

Daga MT-400 Manuale

Remington

Remington BHT100 Manuale utente

Kompernass

Kompernass KH 5537 Manuale utente

Remington

Remington BHT6100 Manuale utente

MIA

MIA Aqua Body Manuale utente

Matheo

Matheo MLR 15 Manuale utente

CTC Union

CTC Union Clatronic HSM 3441 NE Manuale utente

Remington

Remington XR7000 Manuale utente

Eldom

Eldom G47 Manuale utente

Braun

Braun silk-epil 5 Manuale utente

SEVERIN

SEVERIN SÉRIE E700 0533 Guida utente

Remington

Remington PR1355 Manuale utente

Aurora

Aurora AU 3543 Manuale utente

Braun

Braun InterFace 3614 Manuale utente

Wahl

Wahl 8061 5-STAR Manuale utente

Norelco

Norelco 4404LC Manuale utente
