Philips HQ9140 Manuale utente

ENGLISH 4

DEUTSCH 17

FRANÇAIS 31

NEDERLANDS 44

ESPAÑOL 58

ITALIANO 72

PORTUGUÊS 86

TÜRKÇE 100

HQ9140

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the powerplug supplied.

◗The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

◗The powerplug contains a transformer. Do

not cut off the powerplug to replace it with

another plug, as this will cause a hazardous

situation.

◗Do not use a damaged powerplug.

◗If the powerplug is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

C◗Make sure the powerplug does not get wet.

◗Charge and store the appliance at a

temperature between 5cC and 35cC.

C◗Never immerse the charging stand in water

nor rinse it under the tap.

◗Do not recharge the shaver in a closed pouch.

◗Always unplug the shaver before cleaning it

under the tap.

C◗The appliance complies with the

internationally approved IEC safety regulations

and can be safely cleaned under the tap.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

ENGLISH4

Charging

Make sure the appliance is switched off before

you start charging it.

Charging normally takes approx. 1 hour.

You can also shave without charging by

connecting the shaver to the mains.

Charge indications

Charging

C◗When the shaver is being charged, the plug

indicator burns continuously.

Battery fully charged

C◗When the battery has been fully charged, the

battery indicator starts to blink.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 30 days.

ENGLISH 5

Charging the appliance

C1Put the appliance plug in the shaver.

2Put the powerplug in the wall socket.

3Remove the powerplug from the wall

socket and pull the appliance plug out of

the shaver when the battery has been fully

charged.

Charging stand

You can also charge the appliance by placing it in

the charging stand, if provided.

C◗Place the shaver properly in the plugged-in

charging stand.

C◗Lift the shaver from the stand without tilting

it.

Removing and inserting the clock

C1Turn the clock anticlockwise (1) ('click')

and pull it out (2).

ENGLISH6

C2Insert the clock (1) and turn it clockwise

(2) ('click').

Setting the time

C◗Set the time by pressing the small button at

the back of the clock.

The time can only be set forward.

Replacing the battery

C1Remove the cap.Then remove the battery

by means of a miniature screwdriver.

C2Insert a new battery and put the cap back

into place.

ENGLISH 7

Using the appliance

Personal Comfort Control

C◗The Personal Comfort Control system allows

you to adapt the shaver to your skin type.

- You can set the shaver to 'Normal' for a fast

and comfortable close shave.

- You can set the shaver to 'Sensitive' for a

comfortable close shave with optimal skin

comfort.

C◗The 'S' position is best suited for sensitive

skin.

C◗The 'N' position is best suited for normal

skin.

◗The in-between positions are suitable for skin

types between normal and sensitive.

Shaving

1Switch the shaver on by pressing the on/off

button once.

C2Move the shaving heads quickly over your

skin, making both straight and circular

movements.

- Shaving on a dry face gives the best results.

- Your skin may need 2 or 3 weeks to get

accustomed to the Philips system.

ENGLISH8

3Switch the shaver off by pressing the on/off

button once.

C4Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

downwards.

The trimmer can be activated while the motor is

running.

C2Close the trimmer with your index finger.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit and the hair

chamber with hot water every time you have

used the shaver.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

ENGLISH 9

Every day: shaving unit and hair chamber

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button to open the

shaving unit.

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

for some time.

Make sure the inside of the shaving unit and the

hair chamber have been cleaned properly.

C4Rinse the outside of the appliance.

5Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue

as this may damage the shaving heads.

C6Open the shaving unit again and leave it

open to let the appliance dry completely.

You can also clean the hair chamber without

water by using the brush supplied.

ENGLISH10

Every six months: shaving heads

C1Open the shaving unit, turn the lock

anticlockwise (1) and remove the retaining

frame (2).

2Clean the cutters and guards with the

brush supplied.

Do not clean more than one cutter and guard at

a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it may

take several weeks before optimal shaving

performance is restored.

3Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit and turn it clockwise.

4Close the shaving unit.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

ENGLISH 11

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Charging stand

Never immerse the charging stand in water nor

rinse it under the tap.

You can clean the charging stand with a moist cloth.

Storage

C◗Put the protection cap on the shaver to

prevent damage.

C◗Store the appliance in the luxury pouch or

place the appliance in the stand.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with

HQ9 Philips shaving heads only.

ENGLISH12
